Page 1 SUNCORE SEEDLING HEATING MAT USER MANUAL...
Page 3 WELCOME Thank you for choosing AC Infinity. We are committed to product quality and friendly customer service. If you have any questions or suggestions, please don’t hesitate to contact us. Visit www.acinfinity.com and click contact for our contact information. EMAIL LOCATION support@acinfinity.com...
Page 4 MANUAL CODE SC2008X1 PRODUCT MODEL UPC-A SUNCORE A1 AC-SMA1 819137021167 SUNCORE A3 AC-SMA3 819137021174 SUNCORE A5 AC-SMA5 819137021181 SUNCORE A7 AC-SMA7 819137021198 SUNCORE T3 AC-SMT3 819137021211 SUNCORE T5 AC-SMT5 819137021218 SUNCORE T7 AC-SMT7 819137021235...
Page 5: Manual Index
Page 6 Key Features ................. Page 7 Product Contents ................Page 8 Installation ..................Page 9 Starter Guide ................. Page 13 Programming ................. Page 16 Other Settings ................Page 28 Other AC Infinity Products ............. Page 29 Warranty ..................Page 30...
Page 6: Product Warning
PRODUCT WARNING DO NOT SUBMERGE IN WATER. DO NOT place heated objects under this seedling mat. DO NOT puncture or tear open this seedling mat. DO NOT wrap or cover with insulated material. DO NOT use this mat outdoors. This mat is not recommended for use by children 12 years and under. Children should be supervised to ensure they do not play with this heating mat.
Page 7: Key Features
KEY FEATURES HEAT DISTRIBUTION STORAGE BAG WATER-RESISTANT MAT A water resistant bag made Improve germination and IP-67 rated heating pad using with nylon fabric and drawstring rooting, emitting a steady multiple layers of PVC matting stream of heat and insulating opening to easily store your providing high durability and your seed tray.
Page 8: Product Contents
PRODUCT CONTENTS SUNCORE SEEDLING MAT (Included in both Series) SEEDLING STORAGE PRODUCT MAT COVER MANUAL (x1) (x1) (x1) SUNCORE SEEDLING MAT (Included in T-Series ONLY) WALL HANG SENSOR WALL-HANG WIRE CABLE TIE CONTROLLER PROBE WOOD SCREWS MOUNT (x1) (x1) (x2)
Page 9: Installation
INSTALLATION ALL MODELS STEP 1 Unroll the seedling mat flat on to the ground. *Do not allow the mat to overlap on to itself. STEP 2 Connect the AC power plug to a power outlet to turn on the seedling mat. For T-series models, please continue to pages 10 to 12 to setting up the controller with the mat.
Page 10 INSTALLATION T-SERIES MODELS STEP 1 Locate the connector plug of the sensor probe and plug it into the sensor port at the bottom side of the controller. STEP 2 Position the corded sensor probe and secure it by using the included zip ties and tie mounts if needed.
Page 11 INSTALLATION T-SERIES MODELS STEP 3 To mount the controller, locate a spot free of obstruction. Secure the controller using the included mounting screw set. STEP 4 On the back end of the controller is an opening to hang the device.
Page 12 INSTALLATION T-SERIES MODELS STEP 5 Lastly, to power the controller, plug the outlet’s power cord into an AC power outlet. STEP 6 To power the seedling mat with the controller, plug it into of the two ac outlets located on the controller.
Page 13 STARTER GUIDE GROWING SEASONS Use this seedling mat to get a head start on the gardening season. Start the germination process during late winter or spring, especially if you are in a colder region. GERMINATION Different seeds require different temperatures to germinate.
Page 14 STARTER GUIDE HUMIDITY Humidity domes and plastic covered pots can be used alongside the seedling mat to introduce moisture, which help accelerate plant growth. SOWING SEEDS Sow 2-3 seeds per cell; not every seed will germinate. Cover the seeds completely with your grow media.
Page 15 STARTER GUIDE LIGHTING If you have a lot of light coming into your home, you may place the container by a bright, south-facing window. Rotate the tray daily. Be careful when using the seedling mat along with grow lights; this may dry out your soil and overheat your seedlings’...
Page 16: Mode Button
PROGRAMMING TIMER TO 1. MODE BUTTON This button cycles through each of the controller’s mode: OFF, ON, AUTO (4 triggers), TIMER TO ON, TIMER TO OFF, CYCLE (On and Off), and SCHEDULE (On and Off). 2. UP / DOWN BUTTON Adjusts the parameters of the mode that you are in.
Page 17: Probe Temperature
PROGRAMMING 5. PROBE TEMPERATURE Current temperature that the probe is detecting. Displays “--“ if no probe is plugged in. Includes a trend indicator that signals a rise, steady, or fall in temperature within the last hour. 6. PROBE HUMIDITY Current humidity that the probe is detecting. Displays “--“ if no probe is plugged in. Includes a trend indicator that signals a rise, steady, or fall in humidity within the last hour.
Page 18: Controller Modes
PROGRAMMING CONTROLLER MODES Pressing the mode button will cycle through the controller’s available programming modes: OFF, ON, AUTO (4 triggers), TIMER TO ON, TIMER TO OFF, CYCLE (On and Off), and SCHEDULE (On and Off). OFF MODE Your device will be off regardless of temperature humidity, and time-based triggers.
Page 19 PROGRAMMING AUTO MODE (HIGH TEMPERATURE TRIGGER) Pressing the up or down button sets the high temperature trigger. Your device will be turned on if the probe’s reading meets or exceeds this threshold. If the probe’s reading falls below this trigger point, your device will be turned off.
Page 20 PROGRAMMING AUTO MODE (HIGH HUMIDITY TRIGGER) Pressing the up or down button sets the high humidity trigger. Your device will be turned on if the probe’s reading meets or exceeds this threshold. If the probe’s reading falls below this trigger point, your device will be turned off.
Page 21 PROGRAMMING TIMER TO ON MODE TIMER TO In this mode, press the up or down button to set a countdown time. During the countdown, your device will be set to off. Once the countdown ends, your device will trigger to turn on. The countdown will begin if no buttons are pressed for 5 seconds.
Page 22 PROGRAMMING CYCLE MODE (ON AND OFF) CYCLE In this mode, set an on duration and an off duration for your device to cycle through continuously. Press the up or down button to first set a duration for your device to be on and then press the mode button again, to set a duration for device to be off.
Page 23 PROGRAMMING SCHEDULE MODE (ON AND OFF) SCHEDULE In this mode, set an on clock-time and an off clock- time schedule for your device to follow through daily. Press the up or down button to first set up an on clock-time for when your device will be on and then press the mode button again, to set an off clock-time for when your device will be off.
Page 24: Controller Settings
PROGRAMMING CONTROLLER SETTINGS Pressing the setting button will cycle through the controller’s available settings: DISPLAY, F/C, CLOCK, CALIBRATION TEMPERATURE, CALIBRATION HUMIDITY, BUFFER TEMPERATURE, and BUFFER HUMIDITY. DISPLAY SETTING In this setting, adjust the brightness of the display and DISPLAY auto-dimming. Press the up or down button to cycle through 1, 2, 3, A2 and A3.
Page 25: Clock Setting
PROGRAMMING CLOCK CLOCK SETTING In this setting, adjust the current clock time. Press the up or down button to increase or decrease the time. Once you cycle through 12:00 each time, the units will automatically change to AM or PM. The current clock time will be shown at the lower left corner of the display.
Page 26 PROGRAMMING BUFFER TEMPERATURE SETTING The buffer that used in auto mode temperature trigger can be adjusted to prevent the device from turning on and off too quickly due to variations in the BUFF. T° environment. For high temperature triggers, once your device is on, it will only turn off when the measured temperature falls below the set temperature by the buffer number you have set here.
Page 27 PROGRAMMING ALERT ICONS On the top left of the display is the alert icon section. Icons may flash when the controller wishes to alert you that a particular function or alarm is being triggered. TIMER TO TIMER ALERT This icon will flash when a countdown has completed for TIMER TO ON, TIMER TO OFF, CYCLE, or SCHEDULE Mode.
Page 28: Other Settings
OTHER SETTINGS FACTORY RESET To reset the controller back to factory settings, hold the mode button, the up button, and the down button simultaneously for four or more seconds. Resetting the controller will clear all user set parameters in every controller mode and settings. CONTROLLER LOCK To lock the controller to prevent settings to be changed accidentally, hold the settings button for two or more seconds.
Page 29 AC INFINITY PRODUCTS Inline Fans The CLOUDLINE series is a line of duct fans designed to quietly ventilate AV rooms and closets, as well as various DIY air circulation and exhaust projects. Features a thermal controller with intelligent programming that will automatically adjust duct fan speeds in response to changing temperatures.
Page 30: Warranty
WARRANTY This warranty program is our commitment to you, the product sold by AC Infinity will be free from defects in manufacturing for a period of two years from the date of purchase. If a product is found to have a defect in material or workmanship, we will take the appropriate actions defined in this warranty to resolve any issues.
Page 31 COPYRIGHT © 2020 AC INFINITY INC. ALL RIGHTS RESERVED No part of the materials including graphics or logos available in this booklet may be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine readable form, in whole or in part, without specific...
Page 32 www.acinfinity.com...
