CB3-5 / CB5-7
CB5-9 / CB9-15
C o u n t e r B a l a n c e r H a n g e r
OPERATIONS and MAINTAINANCE MANUAL
BEFORE OPERATING THIS DEVICE, ALL OPERATORS SHOULD READ AND
STUDY THIS MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY
WARNINGS AND INSTRUCTIONS. KEEP THESE INSTRUCTIONS WITH THE
DEVICE FOR FUTURE REFERENCE.
Everwin Pneumatic Corp.
19"/3/19
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Everwin CB3-5
- Page 1 CB3-5 / CB5-7 CB5-9 / CB9-15 C o u n t e r B a l a n c e r H a n g e r OPERATIONS and MAINTAINANCE MANUAL BEFORE OPERATING THIS DEVICE, ALL OPERATORS SHOULD READ AND STUDY THIS MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND INSTRUCTIONS.
-
Page 2: Table Of Contents
INDEX CE Declaration of Conformity ----------------------------------------------------------------------- aaaaa Safety Instructions -------------------------------------------------------------------------------------- Specifications and Technical Data ----------------------------------------------------------------- Installation ------------------------------------------------------------------------------------------------- Check Before Use --------------------------------------------------------------------------------------- CE DECLARATION OF CONFORMITY... -
Page 3: Aaaaa Safety Instructions
SAFETY INSTRUCTIONS CB3-5 CB5-7 Models CB5-9 CB9-15 Always attach a secondary support cable or chain. Do not fasten the hanger. ↷ Turn clockwise ( When the spring for increasing the breaks, the safe spring tension by pin pops out from allen key. - Page 4 SAFETY INSTRUCTIONS To avoid severe personal injury or property damage, READ and STUDY this manual before use of tool. Never stand under the counter balancer hanger. Do not disassemble or modify the product. Do not twist and rub the cordage with cable during travel.
- Page 5 SAFETY INSTRUCTIONS Detach tool while removing the counter balancer hanger to prevent the device from dropping. Make sure to detach counter balancer hanger and tool when not in use. Secondary support cable or chain Make sure to remove the counter balancer hanger and tool before setting up tension.
-
Page 6: Specifications And Technical Data
Weight Hanger Cable Model Cable Dia. Capacity Weight Length 3~5 kg 1.82 kg 130 cm 3.2 mm CB3-5 6.6~11 lbs. 4 lbs. 52 in 0.13 in 5~7 kg 1.85 kg 130 cm 3.2 mm CB5-7 11~15.5lbs. 4.1 lbs. 52 in... - Page 7 SPECIFICATIONS AND TECHNICAL DATA Ratchet Hook screw Casing Rubber stop Use the allen key to adjust the spindle Ratchet Cover Bottom hook Safe pin 6m/m Allen Weight Hanger Cable Model Cable Dia. Capacity Weight Length 5~9 kg 3.59 kg 130 cm 4.0 mm CB5-9 11~19.8 lbs.
-
Page 8: Installation
INSTALLATION: Attach the counter balancer hanger to a steady location. Attach a secondary support cable and install it to a steady location. Install tool within the weight capacity to the bottom hook. Adjust tension to appropriate level after tool installation. CHECK BEFORE USE: The hanger and bottom hook are steady and rotate smoothly.
