STANDARD FEATURES
• Flatware saver
• Flushing valve to pump-motor seal
• Flexible draw latches on hood
assembly
• Remote mounted control box with
overload indicator lights and circuit
breaker
• Removable, gasketless water
extractor door
• Start/stop switch mounted on
extractor
• Stainless steel tubular bulletfeet
legs 1-1/2" total adjustment
• Total stainless steel construction
Water level control
OPTIONS & ACCESSORIES
Recirculating pump
Multiple trough con gurations
Extractor ushing system
Spray Reel - 30ft. unmounted
Automatic shutdown timer
Deodorizer injector
Remote mounted start-stop station (unmounted)
Multiple trough con gurations (9" & 12")
Champion Industries, Inc.
2674 N. Service Road,
Jordan Station, Ontario, Canada L0R 1S0
Tel: 800/263-5798 Fax: 905/562-4618
(1M) 2/05 Printed in U.S.A.
Project
Item No.
Quantity
SPECIFIER STATEMENT
Speci ed unit will be Champion model P5-30 pulper waste
handling system.
Features include: 5 hp with 30" diameter slurry chamber,
atware saver, three stationary blocks with four cutting
surfaces each, two tool steel rotating shearing blades, large
water extractor chamber with removable gasketless door
and external drain handle. Contructed of Type 304 SST.
1 year parts and labor warranty.
P. O. Box 4149, Winston-Salem, NC 27115
P5-30
5 Hp - 30" Pulper
Waste Handling System
Champion Industries, Inc.
Tel: 800/532-8591 Fax: 336/661-1979
www.championindustries.com
Advertisement
Related Manuals for Champion P5-30
Summary of Contents for Champion P5-30
- Page 1 Project Item No. Quantity SPECIFIER STATEMENT Speci ed unit will be Champion model P5-30 pulper waste handling system. Features include: 5 hp with 30" diameter slurry chamber, atware saver, three stationary blocks with four cutting surfaces each, two tool steel rotating shearing blades, large water extractor chamber with removable gasketless door and external drain handle.
- Page 2 P5-30 with Optional Recirculating Pump Mounted on Rear of Water Extractor 57-3/4" 15-1/8" 18-1/4" 1-15/16" 60-5/16" 33" 25-15/16" 18-3/4" Front View Utilities 1 Electrical 2 Optional Recirculation Pump 3 Drain 1-1/2" NPT 4 Cold water 1/2" NPT cold water connection 12-1/4"...
- Page 3 240/60/3 480/60/3 Due to an ongoing value analysis program at Champion, specifications contained in this catalog are subject to change without notice. Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 800/532-8591 • Fax: 336/661-1979 • www.championindustries.com P5-30 with Optional 57-3/4"...
- Page 4 Front View Front View Due to an ongoing value analysis program at Champion, specifications contained in this catalog are subject to change without notice. Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 800/532-8591 • Fax: 336/661-1979 • www.championindustries.com For additional trough configurations and feed methods, contact Factory.
