ECM Manufacture P1061 Assembly Instructions

E61 Flow Profile Valve P1061: Assembly instructions
Important note: Unplug your machine from the power supply and let it cool down before assembling the ECM E61
FLOW PROFILE VALVE.
4
3
6
5
7
2
8
9
1. Unscrew the mushroom with an open-
2. Screw the new profiling valve P1025
3. Unscrew the screw with a 5 mm hex
1
4. Mount the pressure gauge P1027
5. Close the valve by rotating the bolt
6. Place the bushing to point in the
7. Screw the ball grip in and tighten it.
8. Unscrew the prebrew-cylinder at the
9. Exchange the spring to the supplied
10. Insert the valve spindle in the prebrew-
10
end wrench sized 36 mm across flats.
Caution:
Be careful to avoid scratches!
in, at the position of the Mushroom.
key.
where the hex key screw was inserted.
The Teflon seal of the screw has to be
reused. It is recommended to use
FDA-approved thread sealing too.
Caution:
Do not fasten the gauge to tight, to
avoid damaging to the thread.
clockwise completely.
desired direction for the closed
position onto the spindle.
lower brew group with an open-end
wrench sized 36 mm
P1029-spring
cylinder and reassemble it to the
lower brew group.
ENGLISH
