Revo 0211T4FD Quick Manual

Wi-fi kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Wi-Fi Kit
Quick Guide
V1.01

Advertisement

Table of Contents
loading

Summary of Contents for Revo 0211T4FD

  • Page 1 Wi-Fi Kit Quick Guide V1.01...

  • Page 2: Disk Installation

    Default IP, Username and Password IP address: 192.168.1.30 NOTE! For security, you are strongly recommended 192.168.1.13 to set a strong password of at least nine characters including all three elements: digits, letters and special characters. Username: admin Password: 123456 Disk Installation The illustrations are for reference only.
  • Page 3 (Optional) Install SD Card Some camera models support Micro SD card. You need to open the bottom cover to install the SD card. Do not hot plug the Micro SD card after it is inserted. Otherwise the camera or the SD card might be damaged. 1.

  • Page 4: Device Operation

    IPC Interfaces Antenna Power interface Network interface SD card Network Device Operation Startup and Shutdown Make sure the cables are connected correctly and the device is grounded properly. Use a power supply that meets requirements. 5.1.1 Startup Connect the devices to power to start up the devices. 5.1.2 Shutdown Click >...
  • Page 5  SSID: MAC address by default, you can change as needed.  Password: The default is the last eight digits of the serial number. You are strongly recommended to change into a strong password.  Region, Channel: Signal interference varies with region and channel. You are recommended to choose a channel with less signal interference.
  • Page 6 devices again. Choose one of the following methods as needed. NOTE! The following methods are also applicable if you pair a camera not in the kit with the NVR.  One-Click Pair Connect the camera and the NVR to the same switch (or connect the camera to the NVR with a network cable), and connect the devices to power.

  • Page 7: Install Devices

    Press the RESET button on the back of the camera to restore factory default settings. Right-click on the NVR and then choose Menu > Network > Wi-Fi AP. Click QR Code Pair, and follow the on-screen instructions to scan the QR code. Wait for the camera to get online.

  • Page 8: Install The Camera

    Installation with Weakest Signal Install the Camera The following part takes wall mount as an example. Make sure the wall is strong enough to support the weight of the camera. Please prepare hardware accessories in advance. 1. Paste positioning stickers on the 2.
  • Page 9 Playback In the preview page, select the desired window, then right click and select Playback to play the recording of the current day. NOTE!  A 7*24 recording schedule is enabled by default. To set a recording schedule manually, right click and select Menu > Storage > Recording and then set recording type and time based on your needs.

  • Page 10: Add Devices

    Add Devices After logging in to your account, tap > Devices > Add, then select a way to add devices. It’s recommended to choose Scan and scan the QR code on the device body. Live View/Playback > Live View/Playback. Tap in a window, then select a device to start live view or playback.

  • Page 11: Web Login

    Pair Camera and NVR Connect the camera to power, and connect your mobile phone to NVR’s Wi-Fi network. Press the RESET button on the back of the camera to restore factory default settings. > Local Config > Device Wi-Fi Configuration, enter the Wi-Fi password and tap Start to add the camera to the NVR.

  • Page 12: Copyright Statement

    People's Republic of China and the United States, and abides by relevant regulations relating to the export, re-export and transfer of hardware, software and technology. Regarding the product described in this manual, REVO asks you to fully understand and strictly abide by the applicable export laws and regulations worldwide.

  • Page 13: Network Security

     To the extent allowed by applicable law, in no event shall REVO’s total liability to you for all damages for the product described in this manual (other than as may be required by applicable law in cases involving personal injury) exceed the amount of money that you have paid for the product.
  • Page 14  Verify that the device is properly installed before connecting it to power.  Do not remove the seal from the device body without consulting REVO first. Do not attempt to service the product yourself. Contact a trained professional for maintenance.
  • Page 15 Compliance Information Statement refer to: http://en.REVO.com/Support/Download_Center/Product_Installation/Declaration/ Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
  • Page 16 no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna.
