Built-In Induction Range
Model # SR-181A
Part No: SR-181A
Operating voltage: 110-120v
Weight: 8.5 lbs.
Power cord: 6', 3 prong
Wood Induction Cabinet Model
Part No: SRC-181
Operating voltage: 110-120v
Weight: 16 lbs
Power cord: 6', 3 prong
Double Induction Wood Cabinet Model
Part No: SRC-2-181 Operating voltage: 110-120v
Weight: 37 lbs
Power cord: 6', 3 prong
Note: Specifications are subject to change without notice, please refer to website for the latest specifications
127 Ambassador Drive, Suite 147 Naperville, IL 60540-4079 • Phone 800-535-8974 • Fax 630-527-8677
Technical Data
Heating Power 1800W
Hz: 60
Approvals: FCC, ETL, ETL to NSF4, CETL
Accessories & Options
Heating Power 1800W
Hz: 60
Approvals: FCC, ETL, ETL to NSF4, CETL
Heating Power 1800W
Hz: 60
Approvals: FCC, ETL, ETL to NSF4, CETL
One-year warranty on parts and labor.
w w w . s p r i n g u s a . c o m
Model # SRC-181
Amperage: 15.0
Dimensions: 12-5/8" x 13-3/8" x 4-3/8"
NEMA Plug:5-20
Amperage: 15.0
Dimensions: 14-1/8" x 20-1/8" x 6"
NEMA Plug:5-20
Amperage: 15.0
Dimensions: 29-1/2" x 20-1/8" x 6"
NEMA Plug:5-20 Each Range
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Spring USA SR-181A
Summary of Contents for Spring USA SR-181A
- Page 1 Built-In Induction Range Model # SR-181A Model # SRC-181 Technical Data Part No: SR-181A Operating voltage: 110-120v Heating Power 1800W Hz: 60 Amperage: 15.0 Dimensions: 12-5/8” x 13-3/8” x 4-3/8” Weight: 8.5 lbs. Power cord: 6’, 3 prong Approvals: FCC, ETL, ETL to NSF4, CETL NEMA Plug:5-20 Accessories &...
- Page 2 5. Space at both sides of cooktop must be at least 4 inches. 6. Space beneath cooktop must be at least 7 inches. 7. SR-181A- This product’s electrical specifications are ..120v/60hz/1800w and each unit must independently use a 15 amp outlet. Absolutely do not use other appliances on the same 15 amp circuit.
