Summary of Contents for Omron Sti H-T40M-P

  • Page 1 H-T40M-P Status Display Touchscreen Installation and Operating Manual...

  • Page 2: Table Of Contents

    H-T40M-P Installation & User Manual Table of Contents Section 1 - Important Message ..... page 3 Section 2 - Introduction......page 4 Section 3 - Safety Precautions.

  • Page 3: Section 1 - Important Message

    Omron Scientific Technologies Inc. may be used. OMRON Scientific Technologies Inc. shall not be liable to anyone for any direct, indirect, special, incidental or consequential damages resulting from the installation, use or repair of this equipment, whether arising in tort, contract, or otherwise.

  • Page 4: Section 2 - Introduction

    I N T R O D U C T I O N NTRODUC H-T40M-P is a status display touchscreen with a 3.3” STN Liquid Crystal Display, and is water- and dust-resistant according to IP65/ NEMA 4X (indoor use only.) H-T40M-P is CE-marked and is highly transient-resistant while in operation.
  • Page 5 3 . 4 . I NSTALLATION Communication cables must be separated from power cables for operational circuits. Only use shielded cables to avoid unpredictable problems. OMRON STI © 99885-0010 Rev.A...

  • Page 6: Section 4 - Package Contents

    P A C K A G E C O N T E N T S 3. 5. D UR I N G • Emergency stop and other safety functions may not be controlled from the status display touchscreen. • Do not use too much force or sharp objects when touching the keys, display, etc.
  • Page 7 A C K A G E O N T E N T S Figure 4-1 Status Display Touchscreen H-T40M-P Figure 4-2 Installation Fasteners Figure 4-3 Power connector OMRON STI 99885-0010 Rev.A ©...

  • Page 8: Section 5 - Specifications

    S P E C I F I C A T I O N S PECIFICATIONS 5. 1. T E C H N I CA L P E CI F I C A T I O NS Parameter H-T40M-P Front panel W x H x D 96.0 x 96.0 x 7.0 mm Mounting Depth 40.6 mm...
  • Page 9 Figure 5-1 H-T40M-P Mechanical Drawing 5 . 3 . E X T E R N A L A N D I M E N S I O N S Figure 5-2 External and Cut-out Dimensions OMRON STI © 99885-0010 Rev.A...

  • Page 10: Section 6 - Mounting Procedure

    M O U N T I N G P R O C E D U R E OUNTING ROCEDURE 1. Cut out the control front panel to match the dimensions (mm) specified in the External and Cut-out-Dimensions section. 2. Mount the status display touchscreen into the cut-out. Insert the fixtures to the holes on the unit and fasten the screws into the front of the panel.

  • Page 11: Section 7 - Grounding

    Use copper conductors only: Wire Gauge Stripped Type (AWG) Length Torque Solid 28-12 7-8mm 4.5 lb-in Stranded 30-12 7-8mm 4.5 lb-in Figure 8-1 Connector Wiring OMRON STI © 99885-0010 Rev.A...

  • Page 12: Section 9 - Dip Switches

    D I P S W I T C H E S WITCHES All the dipswitches are preset by the factory. Please leave the dipswitches in the default position. SW10 Table 9-1 Default Factory Position 10 C ONNECTION TO THE G9SP 1.

  • Page 13: Section 11 - Operation

    G9SP is powered up, has a program running, and the communication cable is correctly connected. No programming in the G9SP is required to view the safety inputs or safety outputs or their corresponding error codes. To use the reset functions see Reset Function section. OMRON STI © 99885-0010 Rev.A...

  • Page 14: Section 12 - Navigating The Screens

    N A V I G A T I N G T H E S C R E E N S 12 N AVIGATING THE CREENS 12 .1 . M A I N C R E E N E F A UL T SC RE EN Communicating Light: This light will blink when the status display touchscreen is connected to the G9SP.
  • Page 15 A light grey box represents an open signal (power removed from signal) i.e. light curtain blocked, e-stop pressed, door open. OMRON STI 99885-0010 Rev.A ©...
  • Page 16 N A V I G A T I N G T H E S C R E E N S Figure 12-4 Input Status The “Additional Inputs” button will display the status of Si10-Si19 (when using the G9SP-20S). Figure 12-5 Input Error Details To view any errors press the “Errors”...
  • Page 17 Using the reset function with the G9SP requires the programming of the optional communication input bits in the G9SP configurator software. The optional communication bits are located at the bottom left corner of the G9SP configurator software under the I/O Tag List, under Input Tag. OMRON STI 99885-0010 Rev.A ©...
  • Page 18 N A V I G A T I N G T H E S C R E E N S Note: The status display cannot be used to initiate any kind of machine safety stop since the communication between the G9SP and status display touchscreen is not control reliable.

  • Page 19: Section 13 - Screen Properties

    Press the up or down button and the display will change immediately. Press the S button on the right to save the setting. When done, press the Back button to return to the main menu. Figure 13-1 Safety Controller Screen Properties OMRON STI 99885-0010 Rev.A ©...

  • Page 20: Section 14 - Warranty & Additional Information

    Buyer indemnifies Omron against all related costs or expenses. rights of another party. 10. Force Majeure. Omron shall not be liable for any delay or failure in delivery 16. Property; Confidentiality. Any intellectual property in the Products is the exclu-...
  • Page 21 OMRON ELETRÔNICA DO BRASIL LTDA • HEAD OFFICE São Paulo, SP, Brasil • 55.11.2101.6300 • www.omron.com.br OMRON EUROPE B.V. • Wegalaan 67-69, NL-2132 JD, Hoofddorp, The Netherlands. • +31 (0) 23 568 13 00 • www.industrial.omron.eu Authorized Distributor: Automation Control Systems •...
