- Page 1 Installation Manual February 2008 ™ Opticom Infrared System Model 760 Card Rack...
-
Page 2: Table Of Contents
Installation Table of Contents 1 About This Manual ..........................1 1.1 Purpose of Manual ........................1 1.2 Manual Conventions ........................1 1.3 Manual Organization ........................1 2 Safety Information ..........................2 2.1 Intended Use ..........................2 2.2 Technical Support ........................2 2.3 Safety Messages and Safety Labels .................... -
Page 3: About This Manual
Installation 1 About This Manual Manual Organization 1.1 Purpose of Manual This manual is divided into five sections. Section 1. About This Manual This manual provides step-by-step instructions for Contains information about the organization and installing the Opticom™ Infrared System Model content of this manual. -
Page 4: Safety Information
If you have questions about the system, its use, or operation, please contact your dealer or call the The safety message is in this box. Global Traffic Technologies Technical Service department at 1-800-258-4610. CAUTION means you and/or someone else MAY be HURT or property damage may result if you do not follow these instructions. -
Page 5: Safety Label Format
Installation 2.3.2 Safety Label Format We include safety labels on the devices to help you protect your safety and the safety of others. Safety labels are designed to alert you to potential hazards associated with a piece of equipment that can cause personal injury to you or others. -
Page 6: Safety Label Location
Installation Work Zone Traffic Control Proper control of vehicle traffic is important during many procedures. When you switch the traffic controller to and from the flash mode we recommend that you have people trained in manual traffic control, such as police officers, assist you. -
Page 7: Description
Installation 3 Description The Model 760 card rack is usually required in N.E.M.A. type controller installations. The Model 760 card rack is also used when input file space is not available for Type 170 controller installations. Card slot X1 in the Model 760 card rack is dedicated to Opticom phase selectors and discriminators. -
Page 8: Installation
Installation Table 4-1. 9-Pin Harness Wiring 4 Installation This section describes the installation of the Wire Color Function Opticom™ Infrared System Model 760 Card Rack. Black 115 VAC (AC+) White AC return (AC–) WARNING Green Chassis ground This procedure may expose you to AC Not used voltage and the risk of electric shock or Gray/White... - Page 9 Installation Figure 4-1. 9-Pin Harness Wiring...
-
Page 10: Maintenance
