bathstore Transition H1690MM Installation, Care & Adjustment Instructions

Transition Range
Installation, Care & Adjustment Instructions
Introduction
The following instructions will enable you to complete the final assembly and adjustment of
your new furniture.
Each of the cabinets contains a Hardware box that contains all of the
So parts do not get mixed up, please keep it safe with the unit it came with.
Handle Fixing
The rear of the Doors and Drawer fronts are pin pricked with small holes to guide the
positioning of the handles
Of course, should you wish to place your handles elsewhere , or if you have chosen a
different model to the handle displayed then please ignore these positions and
choose your own.
To use the marked positions, simply drill through the fronts using a sharp 5mm
diameter pointed drill bit and drill into a scrap piece of timber paced on the front side
- this is to ensure that when the drill comes through the front the front surface it
does so cleanly and it will also help protect you from the drill bit.
Then simply attach the handle using the handle screws that are provided in the unit
hardware box.
1. Drilling for Handle Holes
Bathstore Transition Instructions - Issue 1.1
Hardware Box
fitments you need to complete the assembly of each unit.
If you need help or more information please visit us at www.bathstore.com
2. Fixing the Handle
