Asterisk AsReader ASR-023B Setup Manual

Scan module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Scan Module Setup
Manual
ASR-023B
AsReader® is registered trademarks of Asterisk Inc.
The contents of this manual are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AsReader ASR-023B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Asterisk AsReader ASR-023B

  • Page 1 Scan Module Setup Manual ASR-023B AsReader® is registered trademarks of Asterisk Inc. The contents of this manual are subject to change without notice.
  • Page 2 ASR-023B Scan Module Setup Manual Revision History VERSION DESCRIPTION REVISED BY DATE V1.0 Initial version Trinity Liu 2020/07/01 ASTERISK, INC.

  • Page 3: Table Of Contents

    Floodlight and Positioning Lights 14 3.1. Floodlight 14 3.2. Positioning Light 15 Output and Prompt 17 4.1. Transmit “No Read” Message 17 4.2. Letter Case Conversion 18 4.3. Data Encoding Format 19 Data Edit 20 5.1. Code ID 20 ASTERISK, INC.
  • Page 4 EAN-8 Additional Code Reading 38 6.11. EAN-13 39 6.12. EAN-13 Additional Codes 40 6.12.1. EAN-13 2 Additional Codes 40 6.12.2. EAN-13 5 Additional Codes 40 6.12.3. EAN-13 Additional Code Reading 41 6.13. CODE 128 41 6.14. GS1-128 42 6.15. ISBT-128 42 ASTERISK, INC.
  • Page 5 QR Code 56 6.31.1. Read Reverse CR Code 57 6.32. Data Matrix 57 6.32.1. Read Reverse Data Matrix 58 6.33. PDF 417 58 6.33.1. Read Reverse PDF417 59 6.34. Aztec Code 59 6.35. Maxi Code 60 6.36. Hanxin Code 60 ASTERISK, INC.
  • Page 6 ASR-023B Scan Module Setup Manual Appendix 1: Numeric Barcodes 62 Appendix 2: Cancel 64 Appendix 3: Code ID 65 Appendix 4: Character Comparison Table 66 ASTERISK, INC.

  • Page 7: Basic Information

    Factory default configuration Note: After scanning the "Factory Default Configuration" barcode, the device may not be able to scan. In this case, you need to scan the following four barcodes in turn to make the device work properly. ASTERISK, INC.

  • Page 8: Save Current Configuration As Default

    * 9600bps * No parity *1 stop bit 1.2. Save Current Configuration as Default The user can set the required configuration , and then scan the following barcode， Save current configuration as default Save current configuration as default ASTERISK, INC.

  • Page 9: Default Configuration

    Default configuration 1.4. Open/ Close the Parameter Code Note: When you want to set parameters by scanning parameter codes, please scan the following QR code “Open parameter code first to enable this function. *Open parameter code Close parameter code ASTERISK, INC.

  • Page 10: Trigger Mode

    The reading engine performs continuous work. Reading successfully or timeout will end the reading. Once reading successfully for timeout, it will automatically trigger the next reading not controlled by the trigger button. The interval time between two readings in continuous mode is 1 second. ASTERISK, INC.

  • Page 11: Automatic Induction Mode

    Scan stability of induction time setting code, then scan Numeric Barcodes 0 and2 Set stability of induction time is 1500ms Scan stability of induction time setting code, then scan Numeric Barcodes 1 and 5 Stability of induction time ASTERISK, INC.

  • Page 12: Sensitivity Level

    "0", "0" and "5" barcodes; to set an on time of 10.5 seconds, scan the barcode below, then scan the "1", "0" and "5" barcodes. To change the selection or cancel an incorrect entry, scan Cancel appendix. ASTERISK, INC.

  • Page 13: Output Interval Of The Same Code

    “0” and “5” barcodes. To change the selection or cancel an incorrect entry, scan Cancel in appendix. Output interval of the same code 2.6. Quick set for output Interval of The Same Code None ASTERISK, INC.
  • Page 14 ASR-023B Scan Module Setup Manual Delay 1s Delay 3s Delay 5s Delay 7s Delay forever ASTERISK, INC.

  • Page 15: Floodlight And Positioning Lights

    Always lighting: the floodlight will be on since the reading module is turned on. Always close: the floodlight does not light up under any circumstances. * Lighting when read Always lighting ASTERISK, INC.

  • Page 16: Positioning Light

    “Lighting when read" or "Always lighting". To set the positioning light to blink, you must first set it to “Lighting when read" or "Always lighting”. * Lighting when read Always lighting ASTERISK, INC.
  • Page 17 ASR-023B Scan Module Setup Manual Always close Blinking Non-blinking ASTERISK, INC.

  • Page 18: Output And Prompt

    When disabled, and a symbol cannot be decoded, no message is sent to the host. Note: After enabling the "No read" prompt function, this function will not take effect until a barcode has been successfully scanned. *Disable no read Enable no read ASTERISK, INC.

  • Page 19: Letter Case Conversion

    For example the barcode content is: ab123dE， if set to " All uppercase "， the output is: AB123DE；if set to "All lowercase", the output is: ab123de； if set to " Case inversion", the output is:AB123De. * Normal letter case All uppercase All lowercase Case inversion ASTERISK, INC.

  • Page 20: Data Encoding Format

    ASR-023B Scan Module Setup Manual 4.3. Data Encoding Format 0: Primitive Type 1: GBK(GB2312) 2: UTF-8 Note: For BLE and SPP mode, HID mode is not applicable. Used to decode barcodes encoded in different encoding types. Primitive type *GBK UTF-8 ASTERISK, INC.

  • Page 21: Data Edit

    ASR-023B Scan Module Setup Manual Data Edit 5.1. Code ID The user can identify different barcode types by CODE ID, and CODE ID USES a character to identify them. See Appendix 3: Code ID *Disable send code ID Enable send code ID ASTERISK, INC.

  • Page 22: Terminator

    A terminator is a character added after the decoded data. Format: Decode Data +Terminator. CR: carriage return LF: line feed Note: If you use any of the following "TAB", "CRCR", "CR LF CR", then all the setting codes in the product user manual will be invalid. *None CR LF ASTERISK, INC.

  • Page 23: Add Prefixes/ Suffixes

    ASR-023B Scan Module Setup Manual CRCR CR LF CR 5.3. Add Prefixes/ Suffixes One prefix or two suffixes can be attached to the scanned data for data editing. The operation steps are as follows: Choose Adding Prefixes/ Suffixes Prefix First Suffix ASTERISK, INC.
  • Page 24 Example: the letter A corresponds to a number of 1065, so you need to scan the barcode of 1, 0, 6, and 5 in sequence. Scan the barcode below to set the data format you want. *Barcode data only Prefix+data Data+Suffix1 Prefix+data+Suffix1 ASTERISK, INC.

  • Page 25: Add Multiple Prefixes/ Suffixes

    (2) The setting number corresponding to the prefixes can be found in Appendix 4 Character Comparison Table. Scan the Numeric Barcodes in turn to set prefixes. (3) Scan following barcode “Complete setup multiple prefixes/suffixes” Complete setup multiple prefixes/ suffixes ASTERISK, INC.
  • Page 26 Character Comparison Table. Scan the Numeric Barcodes in turn to set suffixes. (3) Scan following barcode” Complete setup multiple prefixes/suffixes” Complete set multiple prefixes/ suffixes Prefixes/ Suffixes Take Effect *Output decoding data only Data + Suffixes Prefixes + Data ASTERISK, INC.

  • Page 27: Hide Data

    *Disable Enable Set Hidden Length Range 1-255. Scan the following barcode, Next scan three Numeric Barcodes appendix. For example, if you need to hide 16 characters, scan three Numeric Barcodes in turn: 0 1 6 ASTERISK, INC.

  • Page 28: Hide Intermediate Data

    Sets the start position of hidden intermediate data. Range 1-255.Scan the following barcode, Next scan three Numeric Barcodes in appendix, for example, to hide the data after the third character (the fourth begins to hide),scan three Numeric Barcodes in turn: 0 0 3 ASTERISK, INC.

  • Page 29: Hide Tail Data

    To hide the tail part of the output decoded data, it can be configured to hide any length. If the configured length exceeds the length of the barcode data, the entire contents of the current barcode will be hidden. *Disable Enable ASTERISK, INC.
  • Page 30 ASR-023B Scan Module Setup Manual Set Hidden Length Range 1-255. Scan the following barcode, Next scan three Numeric Barcodes appendix. For example, if you need to hide 16 characters, scan three Numeric Barcodes in turn: 0 1 6 Set hidden length-tail ASTERISK, INC.

  • Page 31: Barcode Enable/ Disable

    ASR-023B Scan Module Setup Manual Barcode Enable/ Disable 6.1. 1D Barcode Master Switch Enable *Disable ASTERISK, INC.

  • Page 32: Barcode Master Switch

    ASR-023B Scan Module Setup Manual 6.2. 2D Barcode Master Switch Enable *Disable 6.3. UPC-A *Enable Disable Do not transmit UPC-A check bit ASTERISK, INC.

  • Page 33: Upc-A Additional Codes

    ASR-023B Scan Module Setup Manual *Transmit UPC-A check bit 6.4. UPC-A Additional Codes 6.4.1. UPC-A 2 Additional Codes Enable *Disable 6.4.2. UPC-A 5 Additional Codes Enable ASTERISK, INC.

  • Page 34: Upc-A Additional Code Reading

    ASR-023B Scan Module Setup Manual *Disable 6.4.3. UPC-A Additional Code Reading When there is an additional code, the additional code is also read and displayed Enable *Disable 6.5. UPC-E *Enable ASTERISK, INC.

  • Page 35: Upc-E Additional Codes

    ASR-023B Scan Module Setup Manual Disable Do not transmit UPC-E check bit * Transmit UPC-E check bit 6.6. UPC-E Additional Codes 6.6.1. UPC-E 2 Additional Codes Enable ASTERISK, INC.

  • Page 36: Upc-E 5 Additional Codes

    ASR-023B Scan Module Setup Manual *Disable 6.6.2. UPC-E 5 Additional Codes Enable *Disable 6.6.3. UPC-E Additional Code Reading When there is an additional code, the additional code is also read and displayed Enable ASTERISK, INC.

  • Page 37: Upc-E Transfer To Upc-A

    Enable *Disable 6.8. UPC-A Transfer to EAN-13 If this feature is enabled, when the UPC-A barcode is read, the barcode data read will include the system bit, otherwise not. ASTERISK, INC.

  • Page 38: Ean-8

    ASR-023B Scan Module Setup Manual Enable *Disable 6.9. EAN-8 * Enable Disable 6.10. EAN-8 Additional Codes 6.10.1. EAN-8 2 Additional Codes ASTERISK, INC.

  • Page 39: Ean-8 5 Additional Codes

    ASR-023B Scan Module Setup Manual Enable *Disable 6.10.2. EAN-8 5 Additional Codes Enable *Disable 6.10.3. EAN-8 Additional Code Reading When there is an additional code, the additional code is also read and displayed ASTERISK, INC.

  • Page 40: Ean-13

    ASR-023B Scan Module Setup Manual Enable *Disable 6.11. EAN-13 * Enable *Disable ASTERISK, INC.

  • Page 41: Ean-13 Additional Codes

    ASR-023B Scan Module Setup Manual 6.12. EAN-13 Additional Codes 6.12.1. EAN-13 2 Additional Codes Enable *Disable 6.12.2. EAN-13 5 Additional Codes Enable *Disable ASTERISK, INC.

  • Page 42: Ean-13 Additional Code Reading

    ASR-023B Scan Module Setup Manual 6.12.3. EAN-13 Additional Code Reading When there is an additional code, the additional code is also read and displayed Enable *Disable 6.13. CODE 128 * Enable Disable ASTERISK, INC.

  • Page 43: Gs1-128

    ASR-023B Scan Module Setup Manual 6.14. GS1-128 * Enable Disable 6.15. ISBT-128 * Enable Disable ASTERISK, INC.

  • Page 44: Interleaved 2

    Numeric Barcodes is in appendix. To change the selection or cancel an incorrect entry, scan Cancel appendix. I 2 of 5 - Length within range I 2 of 5 - Any length ASTERISK, INC.

  • Page 45: Matrix 2

    0, 4, 1, 2 (single digit numbers must be preceded by a leading zero). Numeric Barcodes is in appendix. To change the selection or cancel an incorrect entry, scan Cancel in appendix. Matrix 2 of 5 - Length within range Matrix 2 of 5 - Any length ASTERISK, INC.

  • Page 46: Transmit Matrix 2 Of 5 Check Bit

    For example, to decode Industrial 2 of 5 barcodes containing between 4 and 12 characters, first, you should scan the following barcode “D 2 of 5 - Length within range”, then scan 0, 4, 1, 2 (single digit numbers must be preceded by a leading ASTERISK, INC.

  • Page 47: Standard 2

    For example, to decode Standard 2 of 5 barcodes containing between 4 and 12 characters, first, you should scan the following barcode “Standard 2 of 5 - Length within range”, then scan 0, 4, 1, 2 (single digit numbers must be preceded by a ASTERISK, INC.

  • Page 48: Transmit Standard 2 Of 5 Check Bit

    Numeric Barcodes is in appendix. To change the selection or cancel an incorrect entry, scan Cancel in appendix. Standard 25 - Length within range Standard 25 - Any length 6.19.2. Transmit Standard 2 of 5 Check Bit Enable *Disable ASTERISK, INC.

  • Page 49: Code 39

    ASR-023B Scan Module Setup Manual 6.20. Code 39 *Enable Disable 6.20.1. Code39 Length Any length code39 6.20.2. Code39 Check Bit Transmit ASTERISK, INC.

  • Page 50: Transmit The Start And Ending Symbol Of Code 39

    ASR-023B Scan Module Setup Manual *Do not transmit 6.20.3. Transmit the Start and Ending Symbol of Code 39 *Disable Enable 6.21. Code 39 Full ASCII Enable *Disable ASTERISK, INC.

  • Page 51: Code 32

    (Code 32 barcode and Code39 barcode are closely connected, not only the encoding method is the same, but also the identification effect of Code 32 barcode will be automatically converted to 6-bit Code39 Code). Enable *Disable 6.22.1. Code32 Add Prefix A Enable ASTERISK, INC.

  • Page 52: Code 93

    ASR-023B Scan Module Setup Manual *Disable 6.23. Code 93 Enable *Disable 6.24. Code 11 Enable ASTERISK, INC.

  • Page 53: Transmit Check Bit

    ASR-023B Scan Module Setup Manual *Disable 6.24.1. Transmit Check Bit Enable *Disable 6.25. Codabar Enable *Disable ASTERISK, INC.

  • Page 54: Plessey

    ASR-023B Scan Module Setup Manual Disable start and ending symbol * Enable start and ending symbol 6.26. PLESSEY Enable *Disable ASTERISK, INC.

  • Page 55: Msi

    ASR-023B Scan Module Setup Manual 6.27. Enable *Disable 6.27.1. Length Any length can read 6.28. GS1-Databar Enable ASTERISK, INC.

  • Page 56: Itf14

    ASR-023B Scan Module Setup Manual *Disable 6.29. ITF14 Enable *Disable Transmit check bit Do not transmit check bit ASTERISK, INC.

  • Page 57: Gs1 Composite Code

    GS1 Composite Code It is recommended to enable 1D barcode master switch and 2D barcode master switch before enabling GS1 composite code, otherwise GS1 composite code may not be really enabled. Enable *Disable 6.31. QR Code * Enable Disable ASTERISK, INC.

  • Page 58: Read Reverse Cr Code

    ASR-023B Scan Module Setup Manual 6.31.1. Read Reverse CR Code *Only read normal code Read normal/reverse code 6.32. Data Matrix * Enable Disable ASTERISK, INC.

  • Page 59: Read Reverse Data Matrix

    ASR-023B Scan Module Setup Manual 6.32.1. Read Reverse Data Matrix *Only read normal code Only read reverse code Read normal/reverse code 6.33. PDF 417 *Enable Disable ASTERISK, INC.

  • Page 60: Read Reverse Pdf417

    ASR-023B Scan Module Setup Manual 6.33.1. Read Reverse PDF417 *Only read normal code Only read reverse code Read normal/reverse code 6.34. Aztec Code Enable ASTERISK, INC.

  • Page 61: Maxi Code

    ASR-023B Scan Module Setup Manual *Disable 6.35. Maxi Code Enable *Disable 6.36. Hanxin Code Encode ASTERISK, INC.
  • Page 62 ASR-023B Scan Module Setup Manual *Disable ASTERISK, INC.
  • Page 63 ASR-023B Scan Module Setup Manual Appendix 1: Numeric Barcodes For parameters requiring specific numeric values, scan the appropriately numeric barcode(s). ASTERISK, INC.
  • Page 64 ASR-023B Scan Module Setup Manual ASTERISK, INC.
  • Page 65 ASR-023B Scan Module Setup Manual Appendix 2: Cancel To change the selection or cancel an incorrect entry, scan the barcode below. Cancel ASTERISK, INC.
  • Page 66 Interleaved 2 of 5/ITF, ITF14 Industrial 2 of 5, Standard 2 of 5 CODE11 MSI, MSI/Plessey UCC/EAN-128/GS1-128 Bookland EAN/ISBN，ISSN GS1 DataBar-14, GS1 DataBar Limited, GS1 DataBar Expanded, Matrix 2 of 5 PDF417 DataMatrix (DM) Aztec Code Maxi Code HanXin ASTERISK, INC.
  • Page 67 Print Screen CTRL R 1019 Delete CTRL S 1020 Tab + shift CTRL T 1021 CTRL U 1022 CTRL V 1023 CTRL W 1024 CTRL X 1025 CTRL Y 1026 CTRL Z 1027 CTRL [ 1028 CTRL \ ASTERISK, INC.
  • Page 68 Space Space 1033 1034 ‘ 1035 1036 1037 1038 & 1039 ‘ 1040 1041 1042 1043 1044 1045 1046 1047 1048 1049 1050 1051 1052 1053 1054 1055 1056 1057 1058 1059 1060 < 1061 1062 > 1063 ASTERISK, INC.
  • Page 69 ASR-023B Scan Module Setup Manual 1064 1065 1066 1067 1068 1069 1070 1071 1072 1073 1074 1075 1076 1077 1078 1079 1080 1081 1082 1083 1084 1085 1086 1087 1088 1089 1090 1091 1092 1093 1094 1095 1096 ‘ 1097 1098 ASTERISK, INC.
  • Page 70 ASR-023B Scan Module Setup Manual 1099 1100 1101 1102 1103 1104 1105 1106 1107 1108 1109 1110 1111 1112 1113 1114 1115 1116 1117 1118 1119 1120 1121 1122 1123 1124 1125 1126 1127 Undefined ASTERISK, INC.
