GAS FIREPIT USER MANUAL
!
IMPORTANT
READ BEFORE USE
SAVE THESE
INSTRUCTIONS
!
Warning:
For Outdoor Use Only.
If stored indoors, detach and
leave cylinder outdoors.
In the event of a blowback,
！
close the control valve and re-ignite
the appliance. If the problem
persists, please contact Safire (the
supplier)
IN CODE:2531CS-0167
P
If the information in this manual is not
followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
Installation and service must be
performed by a qualified installer,
service agency or gas supplier.
Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away
from the appliance and
immediately call your gas
supplier or fire department.
Gas Supplies Sold Separately
!
Warning:
Read the installation, operation
and maintenance instructions
thoroughly before installing or
servicing this equipment.
Save these instructions for future
reference. If you are assembling
this unit for someone else, give
this manual to him or her to read
and save for future reference.
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
An LP-cylinder not connected for use
should not be stored in the vicinity of
this or any other appliance.

Advertisement

Table of Contents
loading

Summary of Contents for Safire GF-1070RDR

  • Page 1 If the problem from the appliance and should not be stored in the vicinity of immediately call your gas persists, please contact Safire (the this or any other appliance. supplier or fire department. supplier) Gas Supplies Sold Separately...

  • Page 2: Table Of Contents

    Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. SPECIFICATIONS Product Name Gas Type Gas Fire Pit LPG or Natural Gas Model No. GF-1070RDR/1070SQR/910CDR/etc. Heat input 10 inch burner:12kW, 13inch burner:13.2kW.

  • Page 3: Important Safety Information

    Important Safety Information FIRE TABLE IS FOR OUTDOOR USE AND DECORATIVE PURPOSES ONLY • WARNING Failure to follow the dangers, warning and cautions in this manual may result in serious bodily injury or death, or in a fire or an explosion causing damage to property. •...
  • Page 4 Important Safety Information (Continued) • This gas fi re table must be used ONLY outdoors in a well-ventilated space and shall NOT be used inside a building, garage, or any other enclosed area. • DO NOT use this outdoor gas fire table for indoor heating. TOXIC carbon monoxide fumes can accumulate and cause asphyxiation.
  • Page 5 Important Safety Information (Continued) • Prior to fire table operation, check the hose for evidence of excessive abrasion or wear. If the hose is damaged, cracked or cut, it must be replaced before using the gas fire table. The hose assembly can only be replaced with a hose assembly specified by the manufacturer. Before each use, remove the lava rocks.
  • Page 6 Propane (LP) Dangers And Warnings (Continued) • LP gas tank must be arranged for vapor withdrawal. • The LP gas tank must have a tank collar to protect the tank valve. • The LP gas tank should not be dropped or handled roughly. •...

  • Page 7: Hose And Regulator Assembly And Replacement

    Hose & Regulator Assembly And Replacement a. If the burner valve is open prior to the LP gas cylinder service valve being opened, the connection will interpret this free flow of gas to be a leak. b. The connection safety feature will reduce gas flow from the regulator to the appliance to a minimal level.

  • Page 8: Parts List

    Parts List Item Quantity 1 Table 2 LP Gas Regulator and Hose （Optional） 3 AAA Battery （Optional） 4 Lava Rock or Fire Glass 1 box （Optional） 5 Vinyl Cover （Optional） 6 Tank Seat （Optional） Table Lid...

  • Page 9: Assembly Instructions

    Assembly Instructions Install the AAA battery as shown in the diagram below. Batteries may contain Mercury. Do not put it into the fire or trash. WARNING Please treat it as hazardous waste and recycle properly. Place lava rock by hand. Do NOT dump bag out into tray to avoid clogging the burner with dust.
  • Page 10 1. Place the tank seat on the ground and place a 20lb. propane tank into the tank seat (5). 2. Tighten down the screw in the bottom of the tank seat to secure the propane tank. Connecting the LP Gas Tank Check to make sure there is no debris in the head of the LP gas tank or in the head of the regulator valve.
  • Page 11 Leaving the LP Gas tank connected could cause the excess flow safety device to trip. Technical data Appliance name GAS FIRE PIT Model No. GF-1070RDR/1070SQR/etc. Burner type 10 inches round burner 13 inches round burner Nominal heat input 12kW(946g/h) 13.2kW(1040g/h)

  • Page 12: Pre-Use Instructions

    Pre-Use Instructions Prior to each gas fire table operation, check the hose and valve for evidence of excessive abrasion or wear. WARNING Before using this outdoor fire table, make sure you have read, understand and are following all information provided in the Important Safety Information section of this manual. Failure to follow those instructions can cause death, serious injury or property damage.

  • Page 13: Lighting

    Lighting Instructions WARNING If burner fl ame goes out during operation, immediately turn the control knob “ OFF” and let the gas clear a minimum of 5 minutes before attempting to re-light the fireplace. WARNING Do not wear loose or fl ammable clothing while lighting fire table.

  • Page 14: Care And Cleaning

    Care and Cleaning General Care and Cleaning This outdoor fire table should be cleaned regularly to ensure safe use and extend product life and need regular servicing of the fire table Debris from any source, or any soot formed shall require removal. Specific methods as below. NOTE: After repeated use, a slight discoloration of the finishes may occur.

  • Page 15: Helpful Tips

    Helpful Tips If the burner will not light or stay lit, please perform the following checks. It is possible that the Excess Flow Safety Device has been tripped. Turn the control knob to off and close the LP Gas tank valve. Disconnect the regulator. Turn the Control Knob to “HIGH”.

  • Page 16: Troubleshooting

    Troubleshooting Problem: Burner will not light using igniter Please review the Helpful Tips on page 15 for common fixes to this problem. Possible Cause 1: Electrode and burners are wet. -Wipe dry with cloth. Possible Cause 2: Igniter battery is dead or backwards. -Check that the AAA battery is inserted correctly in the igniter (see page 10) or replace the battery.
  • Page 17 Troubleshooting Problem: Sudden drop in gas flow, or a reduced flame height Possible Cause 1: Out of Gas. -Check for gas in the LP gas tank. Possible Cause 2: Excess flow safety device may have been activated. -Turn control knob to “ OFF” , wait 30 seconds and light outdoor fi re table. If fl...
