Table of Contents
Summary of Contents for WOBIT MD150T
- Page 1 MD150T Manual Digital processing unit with display for force sensors without amplifiers P.P.H. WObit E.J.K. s.c. Dęborzyce 16, 62-045 Pniewy tel.48 61 22 27 422, fax.48 61 22 27 439 e-mail: wobit@wobit.com.pl www.wobit.com.pl...
-
Page 2: Table Of Contents
Based on the information should not be inferred a certain features or suitability for a particular application. This information does not release the user from the obligation of own judgment and verification. P.P.H. WObit E.K.J. Ober s.c. reserves the right to make changes without prior notice. -
Page 3: Safety And Assembly Rules
• Avoid routing control (signal) cables in parallel with or in close vicinity of power and supply cables. • Avoid close vicinity of devices generating high level of electromagnetic and/or pulse interference (high power loads, loads with phase or group power regulation). www.wobit.com.pl Manual -MD150T – 27.10.2014 – v.1.3 page 3... -
Page 4: Device Description
The measurement result is presented on six position display. MD150T has multipurpose usage as well at industry as in laboratory, where averaged or precise force (weight) measurement is necessary. Depends on used sensor there is a possibility of small masses in range as well small weights (grams) as large loads (tons). -
Page 5: Description Of Connectors And Front Panel
12-36 VDC power supply, min. 250mA Power supply mass Force sensor connection MD150T digital processing unit can be integrated with any force sensor, which has input with resistance of standard bridge bigger than 150Ω. Sensor should be connect according to scheme below. - Page 6 White Yellow Green Tab. 1 Description of cable colors for force sensors of WObit’s offer. CAUTION! In longer period of time can happen, that derivation colors can change. Wrong connection do not cause damage device or sensor. It only cause indicating of opposite value (at changing E+ form E- or S+ from S- derivation), or incorrect (exchange between power supply and output).
-
Page 7: Menu Description
Restoring factory default settings Password X-0000 - not active Parameter confirmation/abortion Menu exit/abortion Blinking measurement value means exceeding of sensor rated load (more information- chapter Błąd! Nie można odnaleźć źródła odwołania.). www.wobit.com.pl Manual -MD150T – 27.10.2014 – v.1.3 page 7... -
Page 8: Example Of Parameter Change
3.2 Example of parameter change After correct connection of external elements and switching power supply on, MD150T process display is ready for operation with previously used settings, and in case of first operation – with factory settings. In order to enter programming mode, press . -
Page 9: Filtering Of Measurements
-99.9999 up to 99.9999. 5. Configuration of relay outputs MD150T digital processing unit has 2 relay outputs PK1 and PK2 which can be switched on/off depending on current measurement value. The following parameters are used for relay outputs configuration: 1. -
Page 10: Password Protection
0000 value – enter previously set password. The password 14. RS2 can be deactivated by switching the parameter 18.PAS and 15. BEP 16. LED setting 0000 value. 17. FAC 18. PAS www.wobit.com.pl Manual -MD150T – 27.10.2014 – v.1.3 page 10... -
Page 11: Usb And Rs485 Modbus Interfaces
(e.g. high interference of power grid) the communication may not be possible. 7.2 RS485 (MODBUS-RTU) interface MD150T digital processing unit is equipped with RS485 interface. It can be used for communication with PLC controller, HMI panel or other device supporting MODBUS-RTU protocol. Default transmission parameters: ... - Page 12 Address of Hi registries 0x13 Address of Lo registries 0x88 Address of Lo registries 0x88 Registry 0x00 Hi 0xFF Registry0x00 Hi 0xFF Registry 0x00 Lo 0x00 Registry0x00 Lo 0x00 16 Bytes 16 Bytes www.wobit.com.pl Manual -MD150T – 27.10.2014 – v.1.3 page 12...
-
Page 13: Complementary Information
8. Complementary information 8.1 Type of force sensors WObit company has a broad offer of force sensors in range from single Newton’s up to hundreds of kilonewtons. Depends on assembly and way of measuring force (tension, compression) are available sensors with different shapes (table below). -
Page 14: Technical Parameters
Operating temperature range 0..50 Display 6 digits, height13.5 mm Housing height: 45 mm width: 92 mm length: 81 mm Weight 200g Degree of protection IP40, from panel head – IP65 Universal password 3145 www.wobit.com.pl Manual -MD150T – 27.10.2014 – v.1.3 page 14...
