Rowin Nano Series Operating Instructions

Looper Station
◆ LED
Indicate looper status.
◆ Mode switch
Models:
●½SPEED: ½ speed
playback recording
●NORMAL: Forward play
●REVERSE: Reverse play
(Recording function
disable)
◆ OUTPUT Jack
1/4" mono audio jack,
outputs the signal
OPERATION
Power on(no data)
Power on(with data)
Tap footswitch(no data)
Tap footswitch when
recording/overdubbing
Tap footswitch when playing
Hold footswitch when
playing/overdubbing
Hold footswitch when recording Delete
Tap footswitch twice when
playing/recording/overdubbing
Hold footswitch when stopped
Recording(around 10 minutes)
◆ Working Current:96mA
◆ Dimensions:75(d)*36(w)*26(h) mm
◆ Weight:133g
Mini loop station box

Operating Instructions

STATUS
Empty
Stop
Record
Play
Overdub
Undo/Redo
(last recording)
Stop
Delete
Memory full,Play Green LED light up

Specifications

Manual
◆ DC In power Jack
DC 9V (negative in the
center )
◆ USB interface
Use to import file to the
box or export file from the
box, and also use to
upgrade fireware of the
box.
◆ LEVEL Knob
Adjust the play output
volume.
◆ INPUT Jack
1/4" mono audio jack,
for connecting Guitar.
◆ Switch
LED STATUS
Off
Green LED Flash
Red Led light up
Green LED light up
Red Led light up
Green LED Flash fast
Green LED Flash fast
Green LED Flash
Green LED Flash fast
