  • Page 1 Exclusively for VTX-C OWNER’S MANUAL...
  • Page 2 Congratulations Your new Kreepy Krauly VTX-C is designed to give you years of reliable performance. As soon as you complete the final assembly steps, it’s ready to use. Don’t worry, it doesn’t take long and this guide will walk you through assembly and installation step-by-step.

  • Page 3: Table Of Contents

    Contents Components checklist Assembling your VTX-C Installing the VTX-C in your pool Fine-tuning your VTX-C Authorised Kreepy Krauly Accessories Troubleshooting Looking after your VTX-C What should I expect from my VTX-C? Warranty information...

  • Page 4: Components Checklist

    Components checklist You will find all the pictured components inside this box. Male-male hose x1 Male-female hose x9 Hose weights x2 Hose protector sleeve Smart-Skim Smart-Skim adaptors used with most vacuum plates used with Polyplastics 190 & 210 standard used with Polyplastics SK10 (rectangular)
  • Page 5 Swivel head assembly Floatation assembly VTX-C cleaner unit Main body Weighted bumper strap Side leaf scoop Serial number Compact Scrubbing seal Sole...

  • Page 6: Assembling Your Vtx-C

    Assembling your VTX-C Attach the Seal STEP Slide the seal onto the groove at the bottom of the main assembly body so it’s able to rotate freely. TIP: If the seal does not sit in this groove, it will affect the cleaner’s scrubbing and climbing.
  • Page 7 Install the Floatation Assembly STEP Press the float arms into the grey housing until they click. STEP Attach the Bumper Strap Insert the bent end of the bumper into the back of the main body (near the bottom of the cleaner). Insert the other end into the swivel head assembly.

  • Page 8: Installing The Vtx-C In Your Pool

    Installing the VTX-C in your pool Prepare your Pool STEP If your pool is clean, balanced and algae-free, you’re ready to get started. First, clean the skimmer and pump basket. Check the water level. Brush down the sides of your pool.
  • Page 9 Fit the Smart Skim Valve STEP STEP Insert one of the supplied adaptor fittings, then attach to your vacuum plate. TIP: Depending on your vacuum used with most plate, you may have to use a vacuum plates different skim adaptor – we’ve used with Polyplastics included three to choose from.
  • Page 10 Start with the male-male hose and twist on a female-male length. Keep going until the hose is long enough to reach from your skimmer box to the far corner of your pool plus around 1.5 metres extra – this will optimise the coverage of your VTX-C. male male...
  • Page 11 STEP Connect the Hose to the VTX-C Submerge the VTX-C in your pool to expel all air (rotate to help remove trapped air). Now connect the weighted end of the submerged hose to the swivel head assembly of the VTX-C.
  • Page 12 Turn on the Pump STEP Your VTX-C should now be up and running. You should hear a gentle ticking – that’s your cue to relax while the VTX-C gets to work cleaning your pool.

  • Page 13: Fine-Tuning Your Vtx-C

    VTX-C. How to achieve the right incline VTX-C works best when the main body sits at a 45° incline to the pool surface. If your cleaner is lifting (greater than 45°), move the hose weight towards the cleaner.

  • Page 14: Authorised Kreepy Krauly Accessories

    Authorised Kreepy Krauly Accessories Main Drain Cover Place over main drain grille to ensure the VTX-3 can move smoothly. (No screws required.) Vacuum Plate Clamp Holds down the vacuum plate when the pool pump is off. Expanding Plug Used to block off selected skimmer box pool drain inlets.

  • Page 15: Troubleshooting

    – opening and closing until  it moves freely. • Check Smart-Skim spring is correctly attached. • Check for a blockage in the main body of your VTX-C (see page 19).
  • Page 16 • Check large debris isn’t blocking out of the water and the pump is your hose or VTX-C (see page 17). • Check the Smart-Skim or Auto VTX-C stays at one end of Skim valve and vacuum plate...
  • Page 17 You notice bubbles at return on the steps: to pool outlets: • Shorten the pool hose so the VTX-C • Check if the hose is damaged isn’t in range of the steps and clean by lifting it near the surface and the missed area manually.
  • Page 18 VTX-C is always coming How to unkink or uncoil to the surface of the pool, your hose possibly drawing in air: Option 1 • Check that the Smart-Skim (see - The easiest method is to lay it page 7) or Auto Skim valve (see flat by the pool for a few hours on page 12) is installed correctly.
  • Page 19 Pool blankets prevent chlorine evaporating. If you’re using one, carefully monitor your chlorine or salt water setting to avoid over chlorinating your pool, which can harm your VTX-C and void your warranty. If you have any questions, please call our Customer Service department on 1800 777 255 or talk...

  • Page 20: Looking After Your Vtx-C

    IMPORTANT If you are giving the water a shock treatment with chlorine or other chemicals, remove your VTX-C from the pool for at least 24 hours. If the chemicals are too strong for people to swim in, they’re too strong for the VTX-C.

  • Page 21: What Should I Expect From My Vtx-C

    What should I expect from my VTX-C? How it moves How it Cleans Your Kreepy Krauly VTX-C will move Your VTX-C will clean your pool backwards in direction, with the daily with your normal filter cycle water flowing through the base of...
  • Page 22 Your Warranty Your VTX-C is engineered to last. This is reflected in the 2-year Full System Warranty and 10-year Flow Turbine Warranty. Protecting Your Warranty All Kreepy Krauly pool cleaning systems are made in Australia to withstand harsh Australian conditions. They are manufactured from top quality materials that are UV, salt and chemical resistant.
  • Page 24 Alternatively, contact your local Clark Rubber pool shop professional. www.kreepykrauly.com.au We reserve the right to revise, change, or modify VTX-C without incurring any obligations to make like changes on VTX-C models previously sold. This publication remains the sole copyright of Sherwood Overseas Co Pty. Ltd...
