- Page 1 ELECTRIC COUNTER TOP GRIDDLE WITH CHEESEMELTER OPERATION MANUAL EL-1624T EL-1636T EL-1624T Shown CECILWARE CORPORATION 43-05 20 AVENUE, LONG ISLAND CITY, NEW YORK 11105-1295 ■ 718-932-1414 FAX 718-932-7860 www.cecilware.com NN22A 5/05...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ... page 2 Packaging ... page 2 Installation ... page 2 Operation ... page 3 Cleaning, Care and Maintenance ... page 3 Safety ... page 4 Trouble Shooting ... page 4-5 Compliance ... page 5 Electrical Diagram ... page 6 Explosion View ... -
Page 3: Introduction
* The machine has not been handled and cleaned correctly. Packaging Cecilware prides itself on quality and service, ensuring that at the time of packing all products are supplied fully functioning and free of damage. Provided in this package are the following:... -
Page 4: Operation
This will assist in reducing power consumption and also allow for a quicker heating response when needed. Cecilware recommends that the cooking surface be lightly greased before each use. For cheesemelting or finishing, simply adjust the grilling grid to your needs beneath the hotplate and element. -
Page 5: Safety
*Do not immerse in water or use hose to clean. *If the power cord is damaged, it must be replaced by a Cecilware Recommended Qualified Service Technician in order to avoid a hazard. -
Page 6: Compliance
Note: All Cecilware products are tested prior to packing. Compliance Cecilware products have undergone strict product testing in order to comply with regulatory standards and specifications set by international, independent, and federal authorities. As testimony to such compliance, Cecilware products carry the following marks/symbols: Cause 1. -
Page 7: Electrical Diagram
Electrical Diagram Model: EL-1624T： on/off switch thermostat EL-1636T： 240V on/off switch 1 thermostat 1 pilot light 1 element 1 The above circuit diagram has been provided to assist qualified technicians. A Recommend Qualified Service Technician should carry out repairs if needed. Do not remove any components or service panels on this product. -
Page 8: Explosion View
Explosion View MODEL: EL -1624T... - Page 9 MODEL: EL – 1636T...
-
Page 10: Spare Part List
THERMOSTAT PILOT LIGHT THERMOSTAT DIAL GRILLING RACK CRUMB TRAY ON/OFF SWITCH DRIP TRAY FEET BASE PLATE CORD AND PLUG *NA = not available except by special order. EL-1624T Part NO. 08036 08078 08067 08041 08037 08038 08054 08039 080040 08047 EL-1636T Part NO. -
Page 11: Specifications
Specifications CECILWARE VOLTAGE MODEL EL-1624T 240V 60HZ EL-1636T DIMENSIONS POWER W×D×H (watts) 24” ×22 ” ×12 1/4 ” 2400 36” ×22 ” ×121/4 ” 3600 (inches) - Page 12 CECILWARE CORPORATION 43-05 20 AVENUE, LONG ISLAND CITY, NEW YORK 11105-1295 ■ 718-932-1414 FAX 718-932-7860 www.cecilware.com...
