12-VOLT EMERGENCY
SUMP PUMP SYSTEM RBSP
CONSUMER HOT-LINE: 1-800-942-3343 • MONDAY - FRIDAY • 7 AM to 5 PM
WARRANTY: PRODUCT DEFECTS COVERED 12 MONTHS FROM DATE OF PURCHASE OR 18 MONTHS FROM
DATE OF MANUFACTURE. RECEIPT AND PRODUCT DATE CODE REQUIRED FOR WARRANTY CLAIM.
WATER ACE PUMP COMPANY • ASHLAND, OHIO 44805-1969
23833A141
INSTALLATION MANUAL
12-VOLT SYSTEM
BSP
MODEL R
Battery not included
EASTERN
STANDARD
TIME
