- Black hot : the hot part is black in color. The warmer the temperature, the darker the
color.
b. "MENU" function
Press the "COLOR PALETTE / MENU" button for 2 seconds to enter the IR configuration menu.
Then, press the "COLOR PALETTE / MENU" button for 1 second to switch tabs. When you are
on a tab, press the "BRIGHTNESS" button or the "ZOOM" button for 1 second to change the
configuration. Press the "COLOR PALETTE / MENU" button for 3 seconds to exit the menu.
Contrast: adjustable from 0 ~ 100%. You can adjust the contrast according to the
environment using the "BRIGHTNESS" button or "ZOOM" button.
Brightness: adjustable from 0 ~ 100%. By default, brightness is 40% in "white heat"
mode and 60% in "dark heat" mode. You can adjust the contrast according to the
environment using the "BRIGHTNESS" button or "ZOOM" button.
Picture enhancement settings: adjustable from 0 ~ 60. You can adjust the contrast
according to the environment by using the "BRIGHTNESS" button or "ZOOM" button.
Red display settings
white. You can adjust the contrast according to the environment using the "BRIGHTNESS"
button or "ZOOM" button.
Wi-Fi function parameters: activate (STA) or deactivate (N) the WiFi function by
pressing the "BRIGHTNESS" button. When WiFi is enabled, the icon
upper right corner of the image.
Note: enabling Wi-Fi for a long time will increase the power consumption of the thermal
vision monocular, which will shorten the battery life. Please deactivate this function when
you do not need to use WiFi.
VIS1057 - Indice A – Août 2021
Configure infrared settings in the product
adjustable from -100% ~ 100%. 0% is warm red and 100% is warm
:
is displayed in the
