MO0906-EB
Getting Acquainted
Congratulations upon your selection of this CASIO watch. To get the most out of your
purchase, be sure to read this manual carefully.
About This Manual
• Depending on the model of your watch, display text appears either as dark figures
on a light background or light figures on a dark background. All sample displays in
this manual are shown using dark figures on a light background.
• Button operations are indicated using the letters shown in the illustration.
• Each section of this manual provides you with the information you need to perform
operations in each mode. Further details and technical information can be found in
the "Reference" section.
General Guide
• Press C to change from mode to mode.
• In any mode (except a setting mode), press B to illuminate the display.
Timekeeping
You can adjust the Home Time city date and time in the Timekeeping Mode.
• Pressing D in the Timekeeping Mode will toggle upper right display between the
screens shown below.
Home City Date
Day of the week
To set the time and date
PM indicator
City code
Hour :
Minutes
Seconds
3. Press C to change the flashing screen content in the sequence shown below to
select the other setting.
City Code
Duration
4. When the timekeeping setting you want to change is flashing, use D or B to
change it as described below.
Screen:
To do this:
Change the city code
Toggle the DST setting between
Daylight Saving Time (
Standard Time (
Toggle between 12-hour (
24-hour (
Reset the seconds to
Change the hour and minutes
Change the year, month, or day
Toggle the display illumination
duration between 1.5 seconds (
and three seconds (
5. Press A to exit the setting mode.
• The day of the week is displayed automatically in accordance with the date (year,
month, and day) settings.
Operation Guide 5082
Timekeeping Mode
Press C.
Home City Time
PM indicator
Date
Day of the week
Hour : Minutes
D
Seconds
Seconds
1. In the Timekeeping Mode, hold down A for about three
seconds until the city code flashes on the upper left
display. This is the setting mode.
2. Use D and B to select the city code you want.
• Make sure you select your Home City code before
changing any other setting.
• For full information on city codes, see the "City Code
Table".
12/24-Hour
DST
Seconds
Format
Day
Month
Year
Do this:
Use D (east) and B
(west).
Press D.
) and
).
Press D.
) and
) timekeeping
Press D.
Use D (+) and B (–).
Press D.
)
)
Daylight Saving Time (DST)
Daylight Saving Time (summer time) advances the time setting by one hour from
Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
To change the Daylight Saving Time (summer time) setting
DST indicator
12-hour and 24-hour timekeeping
• With the 12-hour format, the P (PM) indicator appears above the hour digits for
times in the range of noon to 11:59 p.m. and no indicator appears for times in the
range of midnight to 11:59 a.m.
• With the 24-hour format, times are displayed in the range of 0:00 to 23:59, without
the P (PM) indicator.
• The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is
applied in all other modes.
Stopwatch
Hour
Minutes
Speed hand
Important!
• Check to make sure that the speed hand is not moving before you perform any
Stopwatch Mode button operation.
Specifying a Distance Value
You can use the procedure below to specify a distance value, if you want. If you
specify a distance value, the watch will calculate and indicate speed for certain
stopwatch operations.
• The distance value represents kilometers, miles, or any other distance unit you want.
Specifying a distance value of 10.0, for example, can mean 10.0 kilometers or 10.0
miles.
• No speed calculation is performed when 0.0 is specified as the current distance
value.
• For lap time readings, you can specify either the lap distance (when all the laps are
the same distance) or the total race distance.
• For split time readings, you can specify the total race distance only. Though the
watch will indicate a speed each time you take a split reading, they will be based on
the total race distance, and so they will not indicate actual intermediate split speeds.
Alarm Mode
1. In the Timekeeping Mode, hold down A for about three
seconds until the city code flashes on the upper left
display. This is the setting mode.
2. Press C. This will display the DST setting screen.
3. Use D to toggle the DST setting on and off.
DST off (
)
• The default DST setting is OFF (
4. When the setting you want is selected, press A to exit
the setting mode.
• The DST indicator appears to indicate that Daylight
Saving Time is turned on.
You can use the stopwatch to measure elapsed time, lap
times and split times. If you specify a distance value, the
stopwatch also will calculate and display speeds.
• The digital display range of the stopwatch is 99 hours,
59 minutes, 59.999 seconds. The stopwatch continues
to run until you stop it. If it reaches the above limit, it will
restart the time measurement from zero.
• The stopwatch operation continues even if you exit the
Stopwatch Mode. If you exit the Stopwatch Mode while a
stopwatch operation is in progress, the segments in the
lower left dial will appear and disappear sequentially as
stopwatch seconds are counted. This is to let you know
that a stopwatch operation is in progress.
• All of the operations in this section are performed in the
Stopwatch Mode, which you enter by pressing C.
DST on (
)
).
