Summary of Contents for Shenbao SBR-50.0H-A-S

Page 1 Model: SBR-50.0H-A-S...
Page 2: Table Of Contents
Contents Performance Data Specifications Performance data of Swimming Pool Heat Pump Unit - -- - - - - - 2.The dimension for Swimming Pool Heat Pump - - - - - - - - - - - - - -- 2 3.Wire controller operation guide- - - - - - - - - - - - - - - - - - - - - - - - -- - - 3 4.Maintenance- - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -- 15 5.Wiring diagram - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 16...
Page 3 Dear customers: In order to use this machine safely, please read this user's manual carefully before using and installation, especially pay attention to each notice remark for usage and maintenance. Also keep it carefully for later use. Heat pump water heater is a professional machine, it may cause damage or hazard when wrong installed.
Page 4: Performance Data Of Swimming Pool Heat Pump Unit
SWIMMING POOL HEAT PUMP 1.Performance data of Swimming Pool for A type Model SBR-50.0H-A-S 50000 Rated Heating Capacity BTU/h 170000 36000 Rated Cooling Capacity BTU/h 125000 ℃ Heating Range 20~40 ℃ Cooling Range 8~28 Heating Input Power 11100 Cooling Input Power...
Page 5: The Dimension For Swimming Pool Heat Pump
SWIMMING POOL HEAT PUMP 2.The dimension for Swimming Pool Heat Pump 1450 Measure: mm...
Page 6: Wire Controller Operation Guide
SWIMMING POOL HEAT PUMP 3.Wire controller operation guide...
Page 7 SWIMMING POOL HEAT PUMP 3) Wire Controller Operation...
Page 8 SWIMMING POOL HEAT PUMP of Timming Setting,press “ ” once again,when the timming ON/OFF setting is set at the same time,the timming ON/OFF setting is cancelled.
Page 9 SWIMMING POOL HEAT PUMP 3) Parameters Digit Meaning Range Default Remarks Cold water set point temp Can adjust SET0 8-28℃ 12℃ Hot water set point temp Can adjust SET1 20-40℃ 40℃ Auto backwater set point temp 27℃ SET2 8-40℃ Can adjust Can adjust Tank water set point temp SET19...
Page 10 SWIMMING POOL HEAT PUMP 4 ) Failure code and parameter tables Long-distance Protect/Failure Remark controller Water inlet temperature sensor failure PP 1 Water outlet temperature sensor failure Coil temperature sensor 1 failure Air circulation temperature sensor 1 failure Ambient temperature sensor failure Coil temperature sensor 2 failure Winter anti-freezing protection I Winter anti-freezing protection II...
Page 11 SWIMMING POOL HEAT PUMP 5) Two ways to connect wifi a. First way For Android System Install the APP of “SmartLink3 Demo” ◎ ◎ Turn on the heat pump, and make sure the area of heat pump installed cover with wifi signal. What's more, make sure your smart phone with wifi connected.
Page 12 SWIMMING POOL HEAT PUMP a. First way It may take 1 minute to match all wifi setting. ◎ If connected successful, it could show “SmartLink Compelted” as below pic. If failed, it could show “time out”as below pic, then you have to repeat step 3 & 4 again. ◎...
Page 13 SWIMMING POOL HEAT PUMP a. First way For IOS System Find out “SmartLink” in the APP Store, download and install it. ◎ You can scan below QR code for fast installation as well. ◎ Input the passwords of your local wifi. ◎...
Page 14 SWIMMING POOL HEAT PUMP b. Second way for wifi setting Turn on the heat pump. ◎ Use laptop or smart phone to find wifi “HF-LPB100”and connect it. ◎ Open website of “10.10.100.254”, input user name and password as below. ◎ User name: admin Password: admin After that, you could find below interface.
Page 15 SWIMMING POOL HEAT PUMP b. Second way for wifi setting Then select STA setting, press Scan, then press Save. See below refer pic. ◎ Please choose the safety and reliable local area network which available. Then press OK to ◎ Confirm.
Page 16 SWIMMING POOL HEAT PUMP b. Second way for wifi setting Make sure the Encryption Method choose WPA2PSK, and Encryption Algorithm choose AES. ◎ Input the password of your local area network. Then press Save. After finished all above steps, come to Restart interface, and press OK to confirm ◎...
Page 17 SWIMMING POOL HEAT PUMP c. Remarks ◎ Make sure to press “SAVE” for each setting. If IP address changed, all above setting need to re-set. ◎ If you try first way of “Smartlink3 DEMO” and failed, ◎ then try the second way for wifi setting. Long press turn ON/OFF button and UP button for 10 ◎...
Page 18: Maintenance
SWIMMING POOL HEAT PUMP 4. Maintenance To check the water supply device often. You should avoid the condition of no water or air entering into system, or that will influence unit’s performance and reliability. You should clear the water filter regularly to avoid unit’s damage by filter’ jam. There should be dry, sanitary and ventilation around the unit.
Page 19: Wiring Diagram
SWIMMING POOL HEAT PUMP 5. Wiring diagram...
Page 20: Service
SWIMMING POOL HEAT PUMP Service 1.How to obtain Service For Pool Owner If you are having trouble with the unit, please contact the Installer immediately. 1. Provide your Dealer with the following information: A. Serial # located on back panel nameplate . B.
Page 21 SWIMMING POOL HEAT PUMP Pool Temperature Range Heated pool max temp Heated pool min temp Unheated pool max temp Unheated pool min temp 2. The charts displayed for an indoor pool Energy flows for indoor pool. Pool temperature during daytime operating period. Space temperature during daytime operating period.
Page 22: The Installation About Heat Pump & Chlorinator
SWIMMING POOL HEAT PUMP Space Humidity operating period Maxlmum Minlmum The position of installing unit 2000mm above the top Air outlet Air inlet Air inlet Heat pump Above 1000mm Above 1000mm Attachment 2 The Installation about Heat Pump & Chlorinator Pressure-type Chlorinator or Brominator Filter Water Pump...
Page 23: Common Units Conversion
SWIMMING POOL HEAT PUMP Attachment 3 Common Units Conversion Linear Measure 1 inch=25.4 millimetres 1 foot=12 inches=0.3048 metre 1 yard=3 feet=0.9144 metre 1 (statute)mile=1760 yards=1.609 kilometres 1 nautical mile=1852 m. Square Measure 1 square inch=6.45 sq.centimetres 1 square foot=144 sq.in.=9.29 sq.decimetres 1 square yard=9 sq.ft.=0.836 sq.metre 1 acre=4840 sq.yd.=0.405 hectare 1 square mile=640 acres=259 hectares...
