- Page 2 As shoppers, we’re always trying to find the perfect balance between quality & value. At BCP, we believe we’ve achieved that. Our diverse catalog of everyday essentials is tailored especially to our customers & guaranteed to hit that sweet spot of high quality & low price.
-
Page 3: Tools Required
NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. • Do not stand on or use any part of this item as a step ladder. • Firmly secure all bolts, screws and knobs before use. •... - Page 4 PARTS TOP BAR FRONT LEG BACK LEG 1 PC 2 PCS 2 PCS LEG SUPPORT BACK SUPPORT MIDDLE SUPPORT 2 PCS 1 PC 1 PC FRONT SWING FRAME BACK SWING FRAME LEFT SEAT FRAME 1 PC 1 PC 1 PC RIGHT SEAT FRAME SWING ARM SEAT...
-
Page 5: Product Assembly
PARTS LOWER CANOPY UPPER CANOPY CANOPY FRAME FRAME 2 PCS 2 PCS 1 PC CUSHION 3 PCS PRODUCT ASSEMBLY Insert a part B front leg into the part A top bar. Attach a part C back leg with a part 1 bolt set and two part 2 bolt sets. - Page 6 PRODUCT ASSEMBLY Attach a part D leg support and one side of the part E back support to the legs with three part 4 bolt sets. Repeat on the other side. NOTE: The leg support and back support share a part 4 bolt set. Attach the part F middle support with two part 8 bolt sets, one on each side.
- Page 7 PRODUCT ASSEMBLY Insert the part L seat into the clamps on the back swing frame. Attach the seat with two part 3 bolt sets and two part 11 spacers. Place a part 9 nut cap on every nut. Hang the swing by inserting the spring hooks into the designated holes on the top bar.
- Page 8 PRODUCT ASSEMBLY Slide a part M lower canopy frame into the slots on the part O canopy. Within the canopy, attach a part N upper canopy frame with three part 7 screws. Repeat on the other side. Secure the canopy to the swing with two part 12 knobs, one on each side. Place three part P cushions.
- Page 9 CONVERTING THE SWING Pull the seat up from the clamps on the back swing frame. Lay the seat flat while sliding the support arm into the designated slots on the rear of the swing.
- Page 10 Check out more great products: bestchoiceproducts.com...
- Page 11 Earn points while you shop. Join today! Give your friends 15% o their first order! For each successful referral you’ll receive 100 points. bestchoiceproducts.com...
-
Page 12: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
Need help?
Do you have a question about the SKY2134 and is the answer not in the manual?
Questions and answers
2 pcs leg support
