TWIST
USER'S MANUAL
Read all precautions and instructions in this manual
before using this equipment
contact@isoitalia.com
Twist 20110E

Advertisement

loading
Need help?

Need help?

Do you have a question about the TWIST and is the answer not in the manual?

Questions and answers

Summary of Contents for Isotech TWIST

  • Page 1 IS O ITA L IA GR OU P S. r. l. Italian Spa Beauty and Tanning Equipment www.isobenessere.com www.isoitalia.com www.steril-line.com TWIST USER’S MANUAL Read all precautions and instructions in this manual before using this equipment contact@isoitalia.com Twist 20110E...
  • Page 2 Congratulations for this fabulous purchase! ISO Italia Group thanks you for choosing its own product from the line ISO TECH STERILE LINE WARNING: Carefully read this user and maintenance manual and in particular the recommendations, warn- ings and safety precautions contained therein. For proper use of the appliance all the instructions and instructions contained in this manual must be followed Keep this manual in a safe place, within easy reach of operators for immediate reference.
  • Page 3 DANGER The electrical safety of this appliance also depends on the characteristics of the electrical system that supplies it, which must therefore be made by qualified installers and comply with the laws and safety standards in force (in Italy DM 37/08 and CEI 64-8 standard). THIS APPLIANCE MUST BE CONNECTED TO GROUND IN A SAFE AND RELIABLE MANNER If in doubt, consult the installation and maintenance company of the electrical system.
  • Page 4 COMPLIANT Other technical-constructive characteristics of the product. Characteristic References code ISO for spare parts N ° 2 55W UVC lamps for each Twist module Type 55W (double ended) MPI17623 Lamp life 9000 hours (about 1 year in continuous service) N ° 2 electronic ballasts with PFC - 2 x 58W Type VS ELXc 258.248 n°...
  • Page 5 DIMENSIONS AND MECHANICAL CHARACTERISTICS The control console is designed for external installation on the walls; it also has a predisposition for fixing to three-module flush-mounting boxes of civil systems. On the internal sheet of the electrical panel, the passage for the electrical connections is provided in the center, in the upper part. Overall dimensions Control console dimensions Width 265 mm...
  • Page 6 The Twist module is designed for different fixings and passages for electrical connections to be prepared on site Overall dimensions of the internal body flush with the ceiling without finishing frame Product dimensions Twist internal body Length 1440 mm Width 160 mm...
  • Page 7 Depending on the type of fixing chosen, described above, the Twist product can be installed in the following ways: A) Externally at the level of the ceiling with all the mecha- nical structure in sight having the two side finishing frames...
  • Page 8 Chairman, legal representative, under his own personal responsibility, Hereby DECLARES that the Model TWIST Code: TWIST X X (X corresponds to the number of ceiling-mounted products installed to- gether) Device for the sterilization of surfaces, environments and objects with the use of UVC lamps...
  • Page 9 SAFETY WARNINGS This product is only intended for indoor air sanitation purposes, and for surface sanitization (non-medical devices). The product is not suitable for sanitizing / sterilizing / disinfecting medical devices. • This product must not be equipped with a general lighting lamp, also the UVC lamp used in this product shouldn’t be installed in general lighting devices.
  • Page 10 The product is equipped with an IR sensor that detects the presence of people inside the work space, the activation of this sensor sends a shutdown command to the control console which is placed in a lockout condition. This safety measure is to be considered as second level therefore it is not to rely only on the operation of the sensor which must be integrated with one or more provisions indicated above.
  • Page 11 UVC TWIST® can be installed individually or in parallel (multiple units connected within the same environment). To facilitate installation, the UVC TWIST® is equipped with hooks (to be hung from the ceiling) and flanges (to be attached to the plasterboard or to the wall). A rotation “closure” system prevents UVC light from escaping when the lamps are facing the germicidal chamber.
  • Page 12 TIMES OF USE UVC TWIST Referring to the declared irradiance for the lamps used in terms of UVC energy, 1.7 w / m² at a distance of one meter in relation and to the doses reported in the official tables for the destruction of microorganisms, we can indicate that, with the cycles shown below in the different configurations, the killing of 99% of bacteria on surfaces and objects is achieved that are irradiated.
  • Page 13 • A reset button for reactivating the system following the detection of movement in the environment where the Twist products are installed. • Un switch on the right side for selecting the “Cleaning Air” or “Cleaning Surface” operating mode correspon- ding to the switch pressed.
  • Page 14 TECHNICAL INFORMATION ON THE USE OF UVC IN ISO TECH PRODUCTS UV-C radiation is a proven and effective technology for destroying micro-organisms Iso Italia Group, with over 30 years of experience in UV lamp sector presents its product line for disinfection with UVC Steril Line germicidal lamps.
  • Page 15 UV BASICS Ultraviolet light belongs to the electromagnetic spectrum with a wavelength between 200 and 400 nm (nanome- ters), which is shorter than visible light, but longer than X-rays. All UV rays and bands are invisible to the human eye. The UV spectrum can be divided into the following bands: UV-A (Long Waves;...
  • Page 16 DOSAGE DETERMINES EFFICACY The amount of UV-C energy required to inactivate a given micro-organism is measured on the basis of the dose, which is determined by a combination of radiation energy and exposure time. A key difference between surface inactivation and airflow inactivation of micro-organisms is exposure time. The residence time in the UV field for micro-organisms in the airflow is in the order of seconds and would require a much higher UV-C dose compared to surface application.
  • Page 18 TIMER MPI17618 FUNCTIONING DESCRIPTION SETTINGS AND COUNT-DOWN FUNCTIONALITY To set the time of a work cycle, press the SET key once. The numbers corresponding to the “seconds” will flash first; then adjust the value with the UP and DOWN keys. Subsequently, if you want to further increase the time, press the SET button again.
  • Page 19 A single control system can manage several UVC TWIST modules up to a maximum of 5. The positioning of the UVC Corner module must be carried out considering the following aspects to avoid anomalous in- terventions of the safety systems.
  • Page 20 In both types the central body is the same therefore the following assembly indications can be considered for both cases. The Twist product is delivered assembled in all its parts except for the air pipes and relative grids to be used in the built-in model.
  • Page 21 Prepare the electrical connections as indicated in the relative paragraph, “connection to the electrical network” so that the connections go out in correspondence with those on the back of the twist product. Any deviations can be managed in the space provided between the twist module and the ceiling.
  • Page 22 After fixing the central part to the ceiling, proceed with the electrical connection between the control console and the Twist module, using the flying terminal blocks and respecting the numbers shown in the wiring diagrams and in the cables coming out from the back of the equipment...
  • Page 23 Only for the built-in model, the Ø 130mm holes on the false ceiling will be prepared for the lateral positioning of the air vents for recirculation in the environment if the system is used in Cleaning air mode Features of air recirculation components • plastic grids dimensions 145mm x 175mm holes fixing distance 132mm x 162mm (in any case it is advisable to check with the materials supplied) • Ø...
  • Page 24 3 x 0.75mm² ballast power supply 230Vac UVC lamp inside UVC corner from terminal n ° 3 of the 230V phase console> to terminal n ° 9 of the electrical panel inside the Twist from the ground terminal of the console> to the ground terminal of the panel inside the Twist from terminal n °...
  • Page 25 ° 7 12Vdc NC line contact (gray color)> to terminal n ° 13 of the electrical panel inside the Twist from terminal n ° 8 12Vdc NC line contact (yellow / green color)> to terminal n ° 14 of the electrical panel inside the Twist from terminal n °...
  • Page 26 MAINTENANCE In order to maintain the sanitizing and germicidal efficiency of the Stril Room components, it is essential to strictly follow the maintenance schedule indicated below. CAUTION!! Before any type of maintenance, especially internal ones, it is mandatory to disconnect the components from the power supply network.
  • Page 27 For a history of maintenance and assistance it is advisable to use the form below, keeping it together with the product ma- nual. Model equipment maintenance program: Serial number: Date intervention description replaced materials note: N°...
  • Page 31 FOR GUARANTEE ACKNOWLEDGEMENT AND CUSTOMER SERVICE The maintenance booklet, in which, for example, all the technical work carried out is recorded, should be kept in a safe place. Also, please remember that a copy of the “Installation sheet” is to be returned to ISO Italia Group. For any requests that lie outside the contents of this handbook we advise you to contact your local dealer who should also be contacted whenever you require technical assistance.
  • Page 32 TWIST GENERAL INDEX ATTENTION AND RECOMMENDATIONS ....................2 TECHNICAL FEATURES TWIST .......................4 DECLARATION OF CONFORMITY TWIST ....................8 STERIL ROOM SAFETY WARNINGS .......................9 FUNCTIONAL CHARACTERISTICS AND USE ..................11 BASIC CONCEPTS UV RAYS .........................14 TIMER K400 ..............................18 INSTALLATION AND COMMISSIONING ....................19 CONNECTION TO THE ELECTRICITY NETWORK ................24 MAINTENANCE ............................26...
