- Page 1 LED LCD TV OWNER' S MANUAL LE55K6500A Please READ this manual carefully before operating your TV, and retain it for future reference.
-
Page 2: Table Of Contents
01 Safety Warnings Welcome Important Information Safety notice Warning and cautions 02 Introduction Main Parameter Base Stand Assembly Instruction Wall Mounting Installation Guidelines Front Control Panel Rear/Side Sockets Connecting to your Haier TV 03 Remote Control Remote Control 04 Operation Operation 05 Trouble shooting Trouble shooting... -
Page 3: Safety Warnings
01 Safety warnings Thanks for buying this 55" LED LCD TV. This guide will help you set up and begin using your TV. 55"UHD Digital LED LCD TV Remote control AAA battery x 2 Instruction Manual Quick start guide Stand Now you can get started! IMPORTANT INFORMATION READ ALL INSTRUCTIONS BEFORE USE AND KEEP FOR FUTURE REFERENCE. -
Page 4: Safety Notice
Safety notice The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries. Warning: To avoid any injury caused by lean of the product, please always ensure the whole product was placed within the table surface in horizontal. -
Page 5: Warning And Cautions
WARNING AND CAUTIONS Warning Caution High voltages are used in the operation of this Do not trap the power supply cord under the television receiver. Do not remove the cabinet television receiver. back from your set. Refer servicing to qualified service personnel. -
Page 6: Introduction
Introduction 02 Introdution CAUTION INSTALLATION Never tamper with any components inside the *Locate the TV in the room where light does TV, or any other adjustment controls not not strike the screen directly. described in this manual. All LED-TV's are high *Total darkness or a reflection on the picture voltage electrical equipment. -
Page 7: Base Stand Assembly Instruction
Introduction Base Stand Assembly Instruction 1. Place the TV with the display side down on a 2. Lock 4PCS screws below and check each flat surface. Use a cloth to protect the display. screw is firmly tightened. Locate the 2PCS of bottom bracket into the gap in the bottom of the TV. -
Page 8: Wall Mounting Installation Guidelines
Introduction WALL MOUNTING INSTALLATION GUIDELINES This television can be wall mounted as follows: 1.Place the LED LCD Television onto a solid surface. Please place some soft material over the front of the screen to protect it from any damage. 2.Use the four screws provided to fix the TV onto a wall mounting bracket (not included) via the four VESA standard holes on the back of the television. -
Page 9: Front Control Panel
Introduction Front control panel ≤8m Bottom STORE Remote control sensor. Middle Button: press longtime for “power” Indicator LED: function; press once for “source” function RED: STANDBY. Up/Down: CH+/- Key board. Left/Righ: VOL-/+ Rear/Side Sockets HDMI3 HDMI2 HDMI1(ARC) VIDEO/Y HEADPHONE VIDEO OPTICAL output input... - Page 10 Introduction Connecting to your TV Green (Y) Blue (Pb/Cb) W White(AUDIO-L ) Red (AUDIO-R, Pr/Cr) Y Yellow (VIDEO) CVBS, DVD Player or other machine with CVBS/S-Video. HDMI3 HDMI2 HDMI1(ARC) VIDEO/Y Audio/Video machine with HDMI interfaces CVBS, DVD Player or other machine with YPbPr/YCbCr.
-
Page 11: Connecting To Your Haier Tv
Introduction Connecting to your Haier TV To select the device connected with the COMPONENT cable press the SOURCE button on the ▼▲ remote and use the keys to select YPbPr Connecting a DVD player / Satellite / cable press the OK button. set top box receiver / games console / PC or Laptop Option 4... -
Page 12: Remote Control
Remote Control 03 Remote Control Press to open the application store. APP STORE (Mute) Press to turn the sound on or off. Press to open the shortcut menu of tool. TOOL Press to adjust the volume level. VOL +/- Press to open Menu App Page. Press to open a favorite channel list. - Page 13 Remote Control DVB Tool Button Description 1.Picture Mode You can adjust picture effect here, such as Standard, Sports, Soft, Vivid, User, ECO etc. 2.Sound Mode You can adjust sound effect here , such as Standard, Music, Movie, Sports, User. 3.Sleep Time You can set sleep time , such as off, 10minuts, 20minuts, 30minuts, 60minuts, 90minuts, 120minuts,180minuts, 240minuts.
- Page 14 Remote Control exit MENU/ HTR-U12 mode. Insert Batteries into the Remote Control The " Keypad " under the (U12) Remote Control's backboard : is only useful when you open the Internet Explorer or you need enter the characters. 1. Remove the battery cover. Shaking remote control to open the mouse function, the 2.
-
Page 15: Operation
Operation 04 OPERATION Basic Operation Power supply to switch on/off this Unit. Before switch on, ensure that all connections will be proper correct.Press the Key at the bottom of the panel of this Unit to turn on this Unit.Press the Key to show Menu and select Power Logo to turn off this Unit.When the power indicator turns red, this Unit accesses standby state. - Page 16 Operation MPEG Noise Reduction Press ◀/▶ button to select to select Off/Low/Middle/Strong. Color Temperature Press ◀/▶ button to select Nature/Cool/Warm. Zoom Mode Press ◀/▶ button to select Auto/4:3/16:9/Zoom1/Zoom2/Just scan. Press ◀/▶ button to select On or Off. 2. Sound MENU 1).
- Page 17 Operation 3.1 Antenna Type 2). Press ▲/▼ button to select Program Edit and press OK to Press ◀/▶ button to select Air or Cable. Confirm.You can Delete,Move,Skip, Favorite. 3.2 Auto Tuning Press ◀/▶/▲/▼ button to select the country where you will operate the TV.
- Page 18 Operation 6. Setting MENU Note: The default password is 0000. if you forget the password, Press the MENU button and then press ◀/▶ button to select the you can input the super password:9443. Setting menu and then press the OK button. Press▲/▼...
- Page 19 Operation HDMI_CEC Network Press the MENU button and then press ◀/▶ button to select the Press the ◄ / ► to select the Network to set. Setting menu and then press the OK button. Press ◀/▶ button to select HDMI_CEC and press OK to confirm. If the HDMI_CEC is On, you can through the TV remote control to control the Blu-rayplayer.
- Page 20 Operation Video Language Setting Select current display language. Input Method Select the Input method. System Upgrade Music Upgrade to the newest system version. System Recovery Recovery system to original state. About Information about the TV. Photo Apps List Menu There are some Apps, you can choose your like application, and press OK button to open it.
-
Page 21: Trouble Shooting
Trouble Shooting 05 Trouble shooting Trouble phenomenon Symptom Inspection Check Picture Audio antenna position, direction Snow Noise or connection antenna position, direction Ghost Normal audio or connection electronic equipment,car/ Interference Noise motorcycle,fluorescent light Volume(check if mute is Normal Picture Mute activated or if the audio system connections are not correct) Power cord is not inserted... - Page 22 Trouble Shooting Trouble Shooting Most PC's and laptops when connected with a VGA Plug (the My TV does not display the picture blue 15 pin plug on your PC or laptop) require you to press on my laptop / PC when connected. some buttons on your key board to get a picture on a TV or other external display.
- Page 23 Trouble Shooting Trouble Shooting Digital TV Problems and possible Solutions. Picture Breaks into Pixels A typical example of a reception problem includes the break up of pictures (pixilation) or the picture freezing, sometimes there are clicking or squeaking sounds or the sound drops out or there is NO reception at all. Your picture may break into pixels due to the digital video signal dropping.
-
Page 24: Specification
Specification 06 Specification 55" UHD Digital LED LCD TV Integrated digital. Television picture quality: Screen Size: 139.7cm Resolution 3840x2160 pixels 50Hz. DVB-T, DVB-C, DVB-T2 DTV Tuner Decorder 16/32/64/128/256 QAM modulation MPEG2,MPEG4,H.265 3 HDMI sockets Component video socket./AV. 2 USB port. 1 LAN port. - Page 25 4 0 3 2 Q5 5 6 1 0 1...
