OWNERS MANUAL
Manufacturer: Zhejiang Kingroma Industrial & Trading CO. ,LTD.
Address:NO.1 Baihe Road, Baihuashan Industrial Area, Wuyi, Zhejiang China
Please note that this is a general manual. So, the style of the ATV that you
have may differ from the picture shown in this manual.
Original instructions
Please read this owner's manual carefully before using this product ! This is most important !
Please read this owner's manual carefully! It's good for driver's safety and vehicle's
maintenance!
If the rider is without safety awareness or driving experiences, please do drive under
the adult's supervision! This is most important! It's very important for your safety.
This product is recommended for riders of 14 years old or over.
Do not lend the vehicle to others who don't know how to operate.
Please observe the local law and regulations.
Content
! Assembling
! Charger
! Tire and Tire pressure gauges
-Front, rear suspension (inspection)
-Front brake system (inspection)
-Rear brake system (inspection)
-Battery (inspection)
! Storage
! Maintenance & accessories
! Accessory description, data, circuit diagram, age warning and warning labels.
