Slimline wi-fi doorbell camera

Advertisement

Quick Links

Slimline Wi-Fi
Doorbell Camera
Installation
Guide
ADC-VDB105
1

Check Your Doorbell

Check Your Wi-Fi Speed at the Door

The Doorbell Camera requires a minimum of 2.5
Mbps upload speed to operate. In a browser on
your smartphone visit
determine the Internet speed.
Didn't Ring?
If the existing doorbell does not ring the indoor chime when the button
is pressed, there may be a power issue and an electrician should be
consulted before beginning the doorbell camera installation process.
2
Mechanical Chime
Digital Chime
telus.com/speedtest
to

Before You Start

Watch the installation video at
telus.com/DoorbellCamera
the QR code.
What's in the box?
Doorbell Camera
Wall Mounting
Bracket
Wall Anchors
Masonry Drill Bit
You'll need:
Smartphone
Screwdriver
or Tablet
2.5 Mbps Upload
Low Voltage Power
Wi-Fi
(8-30 VAC, 10 VA or 12 VDC)

Check Your Chime

Requires installation of Digital Doorbell Adapter. For
installation instructions, please refer to Step 9 or visit
telus.com/DoorbellCamera.
Don't have one of these?
If your chime box is not either of the above options or you have an
intercom system, then it is incompatible with the Doorbell Camera.
or scan
Wall Screws
Digital Doorbell Adapter
Pencil
Drill
(Optional)
Existing Wired
Chime Box
"Ding
Dong"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADC-VDB105 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TELUS ADC-VDB105

  • Page 1 Masonry Drill Bit Digital Doorbell Adapter You’ll need: Smartphone Screwdriver Pencil Drill or Tablet (Optional) ADC-VDB105 2.5 Mbps Upload Low Voltage Power Existing Wired Wi-Fi (8-30 VAC, 10 VA or 12 VDC) Chime Box Check Your Doorbell Check Your Chime Mechanical Chime “Ding...
  • Page 2 Shut OFF Power to Doorbell Remove Existing Doorbell You’ll need: Screwdriver 2 Wires Test Doorbell Bend the doorbell wires so they don’t slip back into the wall. No Wires? If the existing doorbell does not have wires then it is incompatible with the Doorbell Camera.
  • Page 3 Masonry Install Attach Mounting Bracket You’ll need: You’ll need: Wall Anchors Masonry Drill Bit Drill Hammer (Optional) Screwdriver Mounting Bracket Wall Screws Connect Power Wires Attach Doorbell Camera You’ll need: You’ll need: Mounting Bracket Screwdriver Doorbell Camera Screwdriver NOTE It doesn’t matter which terminal you connect a wire to.
  • Page 4 Get the TELUS SmartHome App Add Camera to Your Account SmartHome1’s system SmartHome Security Log in Email/Username Password Forgot your SmartHome Security log in? Learn how you can recover it. Download the TELUS SmartHome app, then log in with your My TELUS credentials.
  • Page 5 Flash Additional Support Rapid Double Power supply issue Flash Our customer support agents are available 24/7 at 1-855-255-8828. No Colour Possible power supply issue For additional installation instructions, videos and troubleshooting, please visit telus.com/DoorbellCamera or scan the QR code below.
  • Page 6 Troubleshooting Guide Entering troubleshooting modes Flashing Continue to press and hold the main button for troubleshooting steps below. Wi-Fi access point mode Flashing Press and hold the main button for 60 seconds until ashing, then release. Power cycle Press and hold the main button for 70 seconds Flashing until ashing, then release.
