MAC TOOLS GG1100A Operating Instructions

Operating Instructions • Warning Information • Parts Breakdown
Read and carefully study the operating instructions before unpacking and operating the
Continuous Shot Air Grease Gun. The gun must be operated, maintained and repaired
by a person who is familiar with the operating instructions. Operate the gun only after
you have read and understand this operation manual.
FOR YOUR SAFETY
AND TO PREVENT INJURY:
EXTREME PRESSURE MAY CAUSE WHIP HOSE TO BURST. USE ONLY
APPROVED HOSES AND FOLLOW THE HOSE INSTRUCTIONS AND
WARNINGS.
THIS AIR OPERATED GREASE GUN CAN DEVELOP HIGH PRESSURES -
UP TO 6,000 PSIG (414 BAR). USE SAFETY GLASSES AND GLOVES
WHILE OPERATING THE GUN. KEEP HANDS CLEAR OF THE EXPOSED
RUBBER PORTION OF THE HOSE WHILE OPERATING THE GUN WITH
HOSE.
IF FLUID APPEARS TO PENETRATE THE SKIN, SEEK IMMEDIATE
MEDICAL ATTENTION. DO NOT TREAT AS A SIMPLE CUT.
BE SURE THE TRIGGER IS NOT DEPRESSED WHEN ATTACHING THE
GUN TO AN AIR INLET HOSE.
AVOID ACCIDENTAL STARTING.
HOLD THE HOSE ONLY BY THE METAL SPRING GUARDS ON THE END.
DO NOT ALLOW THE HOSE TO KINK. DO NOT BEND THE HOSE IN A
TIGHT RADIUS.
REPLACE THE HOSE AT FIRST SIGN OF WEAR, KINK OR DAMAGE TO
THE OUTSIDE JACKET.
USE ONLY HIGH PRESSURE GREASE GUN HOSE AS A
REPLACEMENT.
FEATURES
• 360º Swivel head - includes a 6" bent metal
spout and 18" high pressure hose
• Comfort grip handle - features both a bulk
loading fitting and air release vent
• Locking follower design
• External end cap with heavy duty
"T" pull handle
• Swivel head design allows access to almost
all grease fitting locations
GG1100A
The Mac Tools Air Operated Continuous
Shot Grease Gun is a fully pneumatic
powered tool. The gun is designed for
manual lubrication of grease points in
automotive and truck applications. The
gun has a single action pump that
delivers grease each time the trigger is
depressed and the plunger moves
forward.
FOR YOUR SAFETY
AND TO PREVENT INJURY:
High pressure hazard.
Wear safety goggles.
Do not exceed 60 psi with
hose or 90 psi with solid
extension. To do so may
cause personal injury.
Continuous Shot
Air Grease Gun
1
GG1100A
Rev. 08/15/03
