Summary of Contents for Essence TR-KPD
- Page 1 Smart Security TR-KPD User Guide ESUGSS070 Version 1.0 September 2020...
-
Page 2: Table Of Contents
Arming ............................7 3.2. Disarming ............................ 7 3.3. Checking Arming Status ......................8 3.4. Triggering a Panic Alarm ......................8 Changing the Batteries ........................... 9 Specifications ............................10 Appendix A Keypad Indications and Actions ..................13 Smart Security TR-KPD User Guide... -
Page 3: Product Description
Product Description 1. Product Description The TR-KPD (keypad) is an encrypted, battery operated, wireless, access control and system arming device. Key features include: User identity verification using a proximity RFID tag or passcode MiFare® DESFire® RFID technology ... -
Page 4: Installing The Keypad
Screwdriver Drill To install the keypad: 1. Choose a smooth, flat indoor wall near the door. 2. Release the keypad's mounting base by lifting the tab and sliding the base in the tab’s direction. Smart Security TR-KPD User Guide... - Page 5 4. Insert four fresh new AA alkaline batteries, according to the correct polarity. A new battery can explode if it is incorrectly installed. WARNING! 5. Drill a hole in the wall and insert a wall anchor. 6. Clean and dry the wall. Smart Security TR-KPD User Guide...
- Page 6 Tamper pin hole 9. Press the wall mount into place. 10. Insert a screw in the tamper pin hole and tighten. 11. Align the keypad onto the mounting base, and slide the keypad into place. Smart Security TR-KPD User Guide...
-
Page 7: Arming And Disarming
√ If your user is configured for passcode only, enter the passcode and press If your user requires a tag and a passcode, enter the passcode and then place the tag over the Smart Security TR-KPD User Guide... -
Page 8: Checking Arming Status
3.4. Triggering a Panic Alarm In case of an emergency, you can trigger a panic alarm. To trigger a panic alarm, press and hold the keypad's SOS button for at least five seconds. SOS button Smart Security TR-KPD User Guide... -
Page 9: Changing The Batteries
4. Insert four new fresh AA alkaline batteries, according to the correct polarity. WARNING! A new battery can explode if it is incorrectly installed. 5. Align the keypad onto the mounting base, and slide the keypad into place. Smart Security TR-KPD User Guide... -
Page 10: Specifications
Specifications 5. Specifications Item Data Part Number ES700TRKPD Communications Bi-directional protocol: ECOP – Essence proprietary communication protocol Maximum RF range: Up to 700m (2,296 ft.) – open air Modulation and frequency: Europe: 868.3 MHz 2FSK ... - Page 11 L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage; (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Smart Security TR-KPD User Guide...
- Page 12 Changes or modifications to this equipment not expressly approved by the party responsible for compliance (Essence Security International Ltd.) could void the user’s authority to operate the equipment. Smart Security TR-KPD User Guide...
-
Page 13: Appendix A Keypad Indications And Actions
Delay Arm - Countdown Orange Countdown beeps clockwise Delay Arm - Three short Lights red Success beeps for two seconds Attempt to One long Lights red arm when beep for two seconds armed away Smart Security TR-KPD User Guide... - Page 14 30 seconds Panic - Failure One long Blinks red beep for two seconds Press non- clockwise numeric key for two when alarm seconds in memory Press Lights information - green for Disarmed seconds Smart Security TR-KPD User Guide...
- Page 15 Tag Learn - Three short Lights Success beeps green for seconds Tag Learn - One long Flashes red Failure beep for two seconds No response One long Blinks red from panel beep for two seconds Smart Security TR-KPD User Guide...
- Page 16 Nothing contained herein shall be construed as conferring by implication, estoppels, or otherwise any license or right, either express or implied, under any patent or trademark of Essence or any third party. No use of any trademark may be made without the prior written authorization of Essence.
- Page 17 Legal Notice Smart Security TR-KPD User Guide...
