Page 2
This document explains about the parameters and setting screens for the ZENOLOGY Pro Model Expansion. The parameter names, the order in which they appear and other information may differ, depending on the product.
Page 3
System System CONDITION KEY MODE Simulates the changes that occur as a unit ages. [SOLO] button PITCH DRIFT Sound is produced monophonically. Adjusts the slight pitch drift that occurs when notes are [POLY] button played on an analog synthesizer. Sound is produced polyphonically. [UNISON] button Sound is produced in unison.
DCO-1 DCO-1 [TUNE] knob (OSC1 TUNE) Adjusts the OSC1 pitch. (OSC1 LFO MOD) Adjusts the depth to which LFO modulates OSC1. (OSC1 PIT ENV) Adjusts the depth to which the ENV specified by OSC ENV MODE affects the OSC1 pitch envelope. [RANGE] button [WAVEFORM] button (OSC1 RANGE)
Page 5
DCO-2 DCO-2 [TUNE] knob (OSC2 TUNE) Adjusts the OSC2 pitch. [FINE TUNE] knob (OSC2 FINE TUNE) Finely adjusts the OSC2 pitch. (OSC2 LFO MOD) Adjusts the depth to which the LFO modulates OSC2. (OSC2 PIT ENV) Adjusts the depth to which the ENV specified by OSC ENV MODE affects the OSC2 pitch envelope.
MIXER MIXER [DCO-1] knob (OSC1 LEVEL) Adjusts the volume balance of OSC1. [DCO-2] knob (OSC2 LEVEL) Adjusts the volume balance of OSC2. (MIXER ENV DEPTH) Adjusts the depth to which the envelope specified by MIXER ENV MODE controls the OSC2 level. [DYNAMICS] button (MIXER DYNAMICS) Adjusts the sensitivity at which the velocity controls the...
Page 7
[R] [M] [S] buttons (VINTAGE FLT TYPE) If a vintage type model is selected, these buttons change the type of filter. [R] models a Roland filter, and [M] and [S] model vintage synthesizers made by other companies. [CUTOFF FREQ] knob (CUTOFF) Specifies the cutoff frequency of the low-pass filter.
Page 8
[LEVEL] knob (AMP LEVEL) Adjusts the volume of the tone. [MODE] button (AMP ENV MODE) Selects whether the volume is controlled by ENVELOPE-2 (ENV2) or stays at a fixed volume as long as the key is held down (GATE). [DYNAMICS] button (AMP DYNAMICS) Adjusts the sensitivity at which velocity controls the AMP ENV depth.
[RATE] knob (LFO RATE) Specifies the rate of the LFO cycle. [WAVEFORM] button (LFO WAVEFORM) Selects the waveform of the LFO. SINE, SQR, S&H DELAY TIME (LFO DELAY TIME) Adjusts the time from when the key is pressed until the LFO starts to apply modulation.
Page 10
DYNAMICS DYNAMICS [DYNAMICS] button [MODE] button (PITCH DYNAMICS) (OSC ENV MODE) Adjusts the sensitivity at which the velocity controls the Selects the envelope and polarity used to control OSC. depth of the pitch envelope.
Page 11
ENVELOPE-1 ENVELOPE-1 KEY [FOLLOW] button (ENV1 KEY FOLLOW-S) Specifies the ENV1 key follow in four levels. With higher values, ADR times become longer as you play lower on the keyboard, and shorter as you play higher. [A] knob (ENV1 ATTACK) Adjusts the Attack time.
Page 12
ENVELOPE-2 ENVELOPE-2 KEY [FOLLOW] button (ENV2 KEY FOLLOW-S) Specifies the ENV2 key follow in four levels. With higher values, ADR times become longer as you play lower on the keyboard, and shorter as you play higher. [A] knob (ENV2 ATTACK) Adjusts the Attack time.
[MFX] button [MFX TYPE] indication [MFX LEVEL] knob Turns MFX on/off. Shows the currently selected Adjusts the MFX output level. MFX name. MFX parameters The edit screen is different for each MFX type.
Page 14
Controller Controller BEND [2] [3] [4] [7] buttons MOD [LFO] knob (BEND PITCH-STEP) (MODULATION LFO) Specifies the range of pitch change produced by pitch Specifies the amount of LFO applied by modulation. bend in four levels: 2, 3, 4, or 7 semitones. A.TOUCH [LEVEL] knob A.TOUCH [LFO] knob Specifies how the volume of the tone is affected by...
