Summary of Contents for Selecta TC3080PL
- Page 1 Assembly Instructions MANTC3080PL REV A 21/01/21 POLY TRAY TILT TRAILER TC3080PL SILVAN AUSTRALIA PTY. LTD. ABN 48 099 851 144 www.silvan.com.au www.sherlocklastslonger.com.au FOR SERVICE SUPPORT PH 1300 745 826 info@silvanaust.com...
- Page 2 Parts Supplied Nylon M8 x 20 M8 x 60 Spacer (x10) (x2) (x2) Split Pin M8 x 50 M8 x 15 (x2) (x4) (x8) Axle Washers (x4)
- Page 3 Assembly IMPORTANT SAFETY INSTRUCTIONS • When inflating tyres we recommend using a bicycle or foot pump to prevent over inflation. The maximum pressure is 30psi. Never use air compressors as the risk of over inflation and bursting is high • Do not allow children to use the cart without supervision, it is not a toy •...
- Page 4 Assembly STEP 2 Fit the front tray support and handles When attaching the handle fit the 2 plastic spacers.
- Page 5 Assembly STEP 3 Fit the drawbar, axle and wheels Fit the wheel so the air valves face out Fit the tow tongue STEP 4 Tighten and recheck all bolts...
