- Page 1 3, 4 & 5 Bar HD Angle Iron Flexible Harrow (3HD, 4HD, 5HD) Setup/Owner’s Manual Our Tradition is Quality Driven and Field Proven Manual # - MAN-345HD-DFC-004...
-
Page 2: Table Of Contents
Table of Contents Warning ...........................3 Safety Rules ..........................3 To the Owner ...........................4 Warranty Policy ........................4 Mounting the Harrow Field Cultivator - Chisel ....................5 Disk - Disk Chisel ......................7 Adjusting the Attachment Pull Chain .........................9 Lift Chain ..........................9 Pull Link ..........................10 Recommended Torque Specifications ................10 Common Adapter Mounts ...................... -
Page 3: Warning
Always support the implement when mounting or working on the attachment. • Be careful around teeth, tines, sweeps, and blades: they get sharper with wear. 1-800-537-7370 Manual # - MAN-345HD-DFC-004 Remlinger Mfg reserves the right to change pricing or specifications at anytime without notice or obligation... -
Page 4: To The Owner
Warranty will only be granted after examination by appropiate personnel. This warranty is expressly limited to the replacement of defective products. This warranty does not obligate Remlinger Manufacturing to cover cost of labor to replace these parts. This warranty is in effect for 1 year after purchase. -
Page 5: Mounting The Harrow
The mounting arm must be directly above the channel brackets on the attachment. Use the 5/8” - 11 x 6 1/2” hex cap bolts and mounting plates. See common adapters below. 1-800-537-7370 Manual # - MAN-345HD-DFC-004 Remlinger Mfg reserves the right to change pricing or specifications at anytime without notice or obligation... - Page 6 Do not allow the chain to get twisted. Chain twist will cause the inside of the links to rub together. This rubbing will cause the links to wear prematurely and will not be covered by warranty. 1-800-537-7370 Manual # - MAN-345HD-DFC-004 Remlinger Mfg reserves the right to change pricing or specifications at anytime without notice or obligation...
-
Page 7: Disk - Disk Chisel
Use the 5/8” - 11 x 2” hex caps bolts to attach the mounting arm to the adapter plate. 1-800-537-7370 Manual # - MAN-345HD-DFC-004 Remlinger Mfg reserves the right to change pricing or specifications at anytime without notice or obligation... - Page 8 Do not allow the chain to get twisted. Chain twist will cause the inside of the links to rub together. This rubbing will cause the links to wear prematurely and will not be covered by warranty. 1-800-537-7370 Manual # - MAN-345HD-DFC-004 Remlinger Mfg reserves the right to change pricing or specifications at anytime without notice or obligation...
-
Page 9: Adjusting The Attachment
Carrying the attachment bars in the field with the lift chains may cause premature chain wear. • Do not allow twist in the chain. Always allow an even number of links to hang free. 1-800-537-7370 Manual # - MAN-345HD-DFC-004 Remlinger Mfg reserves the right to change pricing or specifications at anytime without notice or obligation... -
Page 10: Pull Link
2380 - 2720 3227 - 3688 1-1/2” 1940 - 2200 2631 – 2983 3160 - 3560 4285 - 4827 1-800-537-7370 Manual # - MAN-345HD-DFC-004 Remlinger Mfg reserves the right to change pricing or specifications at anytime without notice or obligation... -
Page 11: Common Adapter Mounts
Butt-up Adapter - Straight Rear Frame Butt-up Adapter - Welded Rear Plate Universal Adapter - Rear Mount Frame Butt-up Adapter - Rear Mount Frame 1-800-537-7370 Manual # - MAN-345HD-DFC-004 Remlinger Mfg reserves the right to change pricing or specifications at anytime without notice or obligation... -
Page 12: Cross Chains For Flat Fold & Double Fold Wing Implements Only
The chains should not move the section left or right. The lift chains should still hang straight down. 1-800-537-7370 Manual # - MAN-345HD-DFC-004 Remlinger Mfg reserves the right to change pricing or specifications at anytime without notice or obligation... -
Page 13: Bolt-On Extension And Harrow Section Connector Kits
Note: Also can be used to connect (2) complete sections together if mounting arm confliction arises when attaching complete harrow kit to your machine. 1-800-537-7370 Manual # - MAN-345HD-DFC-004 Remlinger Mfg reserves the right to change pricing or specifications at anytime without notice or obligation... - Page 14 Remlinger Manufacturing 16394 US 224 PO Box 299 Kalida, OH 45853 Toll Free 1-800-537-7370 Phone (419) 532-3647 Fax (419) 532-2244 technicalsupport@remlingermfg.com www.remlingermfg.com View Manual Online Email Tech Support...
