Technical data:
Column number:
Maximum load:
Max speed:
Input voltage:
Lowest position:
Highest position:
Desktop size:
Duty cycle:
Applicable temperature: 0~40°C
Certified:
B10
MONTAGE HANDLEIDING
GUIDE D'INSTALLATION
INSTALLATION GUIDE
INSTALLATIONSANLEITUNG
GUIDA D'INSTALLAZIONE
GUIA DE INSTALACIÓN
500MM
800MM
2
70KG
25mm/s
100V~240V
710mm
1210mm
wide: 1000-1600mm - deep: 500-800mm
Continuos operation for 2 minutes after pause of 18 minutes.
CE
1000MM
710MM
25MM/S
1600MM
1210MM
Advertisement
Related Manuals for Basic Line Essentials B10
Summary of Contents for Basic Line Essentials B10
- Page 1 MONTAGE HANDLEIDING GUIDE D’INSTALLATION INSTALLATION GUIDE INSTALLATIONSANLEITUNG GUIDA D’INSTALLAZIONE GUIA DE INSTALACIÓN 500MM 1000MM 710MM 25MM/S 800MM 1600MM 1210MM Technical data: Column number: Maximum load: 70KG Max speed: 25mm/s Input voltage: 100V~240V Lowest position: 710mm Highest position: 1210mm Desktop size: wide: 1000-1600mm - deep: 500-800mm Duty cycle: Continuos operation for 2 minutes after pause of 18 minutes.
- Page 2 Accessory list: ST 4. 2 2.5 x2 .5 4x 4 5x 5 Part list: Pedestal Left column Right column Supporting beam Transmission rods Supporting plate Adapter Baffle Power cable Cable tie Adaptor holder Handset Switch cord Control box Installation instruction: 1 1 2 2 1 1 1 1 1 1 4 4...
- Page 3 STEP 1 Installatie van voet (1) Installation de piédestal (1) Installation of pedestal (1) Installation des Sockels (1) Installazione del piedistallo (1) Instalación de pedestal (1) 5x 5 Install (1) & (2), (3) together, use the 5x5 allen key (A) to tighten the screws (E) STEP 2 Montage van de draagbalk (4) Installation de la poutre de support (4)
- Page 4 STEP 4 Montage van steunplaat (6) Installation de la plaque de support (6) Installation of supporting plate (6) Installation der Trägerplatte (6) Installazione della piastra di supporto (6) Instalación de placa de soporte (6) 5x 5 Connect supporting plate (6) with columns (2)&(3), use the 5x5 allen key (A) to tighten the screws (C) STEP 5 Installatie van de voedingsadapter...
- Page 5 STEP 6 Installeer de schakelkast en de handset Installez le boîtier de commande et le combiné Attach the control box (14) and the handset Install the control box and handset (12) to the tabletop with screws (D) Installieren Sie die Steuerbox und das Mobilteil Installare la scatola di controllo e il microtelefono Instale la caja de control y el auricular Not included...
- Page 6 STEP 9 Sluit alle kabels aan op de adapter Connectez tous les câbles à l’adaptateur Connect all cables to the adaptor Schließen Sie alle Kabel an den Adapter an Collegare tutti i cavi all’adattatore Conecte todos los cables al adaptador 1 1 3 3 7 7 1 1 1 1 1 1 4 4...
- Page 7 STEP 10 Draai het bureau met minimaal 2 personen om naar zijn definitieve positie. Tournez le bureau dans sa position finale. Tournez le bureau avec 2 personnes minimum! Turn the desk over with at least 2 people to its final position. Drehen Sie den Schreibtisch mit mindestens 2 Personen in die endgültige Position.
- Page 8 WAARSCHUWING WARNUNG Voeding: 100~240V AC 50-60Hz Stromversorgung: 100~240V AC 50-60Hz Serviceomgeving: 0 ~ 40 ° C Betriebsumgebung: 0 ~ 40 ° C. Haal de stekker uit het stopcontact voordat u begint met schoonmaken. Gebruik een licht vochtige Ziehen Sie vor der Reinigung den Netzstecker aus der Steckdose. Verwenden Sie ein leicht feuchtes doek om het oppervlak schoon ta maken.
