- Page 1 HYDRAULIC MINI POWER PACKS START-UP / INSTALLATION REFERENCE F214 G2 REV A 6-15-20...
- Page 2 Solenoid – DO3 4W/3P A-PO Check DA Solenoid – 2-DO3 4W/3P A-PO Check DA Solenoid – 4W/3P Dual PO Check DA Solenoid – 4W/2P Dual PO Check, A-Relief APU Auxiliary Power F214 G2 REV B 7-8-20...
- Page 3 It is important that if you need to change the mounting orientation, the suction and return tubes inside the tank are correct (Contact FORCE America for assistance). Mount the power pack on a solid and level surface free of debris, collision, vibration and weather conditions to ensure proper functionality of the power pack.
- Page 4 MUST CONNECT TO EXTERNAL VALVES TO OPERATE ACTUATORS OPTIONAL METRIC MOUNTING M10X18 BOLT KIT - 1009653 NOTE: BODY NOT GROUNDED MUST CONNECT GROUND STUD NOTE: RED & BLACK WIRE NOT INCLUDED! SHOWN TO ILLUSTRATE TYPICAL WIRING FA-214 V000 G2 7/20 PG 4...
-
Page 5: Wiring Diagram
LEVER CENTER HOLDS LOAD OPTIONAL METRIC MOUNTING M10X18 BOLT KIT - 1009653 LEVER DOWN OPENS VALVE TO RETURN OIL BACK THROUGH “P” PORT WIRING DIAGRAM NOTE: BODY NOT GROUNDED MUST CONNECT GROUND STUD RAISE HOLD FA-215 V001 G2 7/17 LOWER PG 5... -
Page 6: Mounting Specification
ALL OFF – HOLD LOAD ENERGIZE SOLENOID VALVE ONLY TO RETURN OIL TO TANK BACK THROUGH “P” PORT OPTIONAL METRIC MOUNTING M10X18 BOLT KIT - 1009653 WIRING DIAGRAM OPTIONAL PENDANT WIRING: 10' - 1052051 PG 6 FA-214 V002 G2 7/20... -
Page 7: Wiring Overview
OPTIONAL PENDANTS: MUST CONNECT TO BATTERY GREEN ON CABLE) 1052052: 2X4H3G - DA 10' GROUND! 1096955: 2X4H6.1G - DA 20' BLACK PENDANT WIRE TO TOP SOLENOID SPADE BLACK COIL WIRE TO MOTOR GROUND STUD FA-214 V005 G2 7/20 PG 7... - Page 8 Coil Wire) (Cable to Chassis Ground) NOTE: BODY NOT GROUNDED MUST CONNECT GROUND STUD OPTIONAL PENDANTS: 1052052: 2X4H3G - DA 10' 1096955: 2X4H6.1G - DA 20' BLACK (Coil wire to Motor ground stud) FA-214 V006 G2 7/20 PG 8...
-
Page 9: Hydraulic Schematic
BODY NOT GROUNDED MUST CONNECT GROUND STUD MOTOR GROUND STUD MUST CONNECT TO BATTERY GROUND! OPTIONAL PENDANTS: 1052052 2X4H3G 1096955 2X4H6.1G 20' Wire Kit # K-HT-DIN-1 # 1023291 SOLENOID INPUT STUD MUST CONNECT TO BATTERY POWER! FA-214 V008 G2 7/20 PG 9... - Page 10 WIRE KIT # K-HT-DIN-2 1023462 YELLOW BOTTOM VALVE NOTE: WHITE BODY NOT GROUNDED MUST CONNECT GROUND STUD BLUE MOTOR GROUND STUD VALVE MUST CONNECT TO BATTERY GROUND! GREEN SOLENOID INPUT STUD MUST CONNECT TO BATTERY POWER! FA-214 V011 G2 7/20 PG 10...
- Page 11 PENDANT BOTH COIL BLACK WIRES TO GROUND STUD BOTTOM COIL #2 WHITE TO WHITE TOP COIL #1 OPTIONAL PENDANTS: WHITE TO GREEN 1052052: 2X4H3G - DA 10' POWER 1096955: 2X4H6.1G - DA 20' STUD FA-214 V014 G2 7/20 PG 11...
- Page 12 BODY NOT GROUNDED MUST CONNECT GROUND STUD MOTOR GROUND STUD TO BATTERY GROUND! WHITE TO GREEN (WHITE ON COIL/ GREEN ON CABLE) BLACK COIL WIRE TO BLACK PENDANT WIRE TO MOTOR GROUND STUD TOP SOLENOID SPADE FA-214 V015 G2 7/20 PG 12...
- Page 13 M10X18 BOLT KIT - 1009653 11.52 WIRING DIAGRAM RED & BLACK WIRES NOT INCLUDED! SHOWN TO ILLUSTRATE TYPICAL WIRING NOTE: BODY NOT GROUNDED MUST CONNECT GROUND CABLE ! DC VOLTAGE HERE RUNS THE MOTOR! FA-214 V111 G2 7/20 PG 13...
