- Page 1 INVICTA LITHIUM BATTERIES INSTRUCTION MANUAL...
- Page 2 INVICTA LITHIUM BATTERIES Welcome to your new Invicta Lithium LiFePO4 Battery. Please read the instructions and warning on this card carefully to ensure you get the most out of your battery. Warnings • Keep battery away from exposure to heat, high voltage and direct sunlight.
- Page 3 LITHIUM BATTERIES Warranty Invicta has a 7-year full replacement warranty when installed in an approved application. Please refer to your warranty card or invictalithium.com.au and register your battery to ensure your battery is in an approved application. A copy of the warranty statement can be found at www.invictalithium.com.au/warranty-statement/.
- Page 4 BMS Over-discharge Protection Voltage Low-Voltage cut-off device setting Series and Parallel of batteries There are strict conditions under which the Invicta Lithium Range can be configured into Series OR Parallel systems. Please note these conditions below. • Not all SNL batteries can be configured into a Series or parallel system.
- Page 5 INVICTA LITHIUM BATTERIES Parallel Configuration ANODE CATHODE PACK 4 PACK 1 FIG 1 Ensure all batteries to be in the parallel configuration have been fully charged individually by matched chargers. 2. Ensure OCV of each battery is less than <0.2V of each other.
- Page 6 INVICTA LITHIUM BATTERIES Series Configuration ANODE CATHODE PACK 4 PACK 1 FIG 2 Check Part number contains an “S” on end to ensure the battery is suitable for Series configuration. 2. Ensure all batteries to be in the series configuration have been fully charged individually by matched chargers 3.
- Page 7 LITHIUM BATTERIES Bluetooth App download The Bluetooth versions of the Invicta Lithium range are indicated by a “BT” at the end of the part number e.g. SNL12V100BT. App Download – Apple Store Go to App Store on your mobile device.
- Page 8 Invicta battery, please contact the team at Sealed Performance Batteries (SPB) on 1300 001 772 or info@spb.net.au. Invicta is a brand of SPB, a company that has over 25 years experience in energy storage and are located in Brisbane, Sydney and Melbourne. For more...
