Tyco Security Products Sur-Gard System Five Operating Manual

Table of Contents

Advertisement

Quick Links

November 21, 2014:
•Added 3G4000 and 3G4000RF to UL/ULC listed transmitters in section 2.2.1
•Removed "FM approved" from section 2.3.1
•Added warning label to section 3.1 in figures 3-2 and 3-3
•Added "This equipment shall be operated by SERVICE PERSONS only within
RESTRICTED ACCESS LOCATIONS; refer to this Operating Manual for all the
Safety Instructions." to section 3.1
•Updated SG-SVLFANTR, SG-SVCFANTR and SG-SVSERCAB to SG-S5LFANTR,
SG-S5CFANTR and SG-S5SERCAB throughout manual.
SG-System 5 v1.0
Operating Manual
NOTE: This manual contains information regarding product use and function, in addition to manufacturer liability and restrictions
pertaining to it. The entire manual should be read carefully.
