- Page 1 MODEL NC-350A Series CURRENCY COUNTER USERS GUIDE (Version 2.0 - First Edition: May 2001)
-
Page 2: Table Of Contents
CONTENTS • Contents Page (This Page) • General Information • Machine Overview • Technical Specification • Initial Operation Steps • Function Setting • Length Detection Setting • Width Detection Setting • UV Counterfeit Detection Setting • Magnetic Counterfeit Detection Setting •... -
Page 3: General Information
Should you have any doubts, please contact your local distributor, or sales agent, for further advice. In the NC-350A series, there are three models with various functional options: • NC-350A The Basic Model •... -
Page 4: Technical Specification
TECHNICAL SPECIFICATION Counting Speed 1500 pcs/min (High Speed) 1000 pcs/min (Standard Speed) 600 pcs/min (Low Speed) Hopper Capacity 200 pcs Suitable Note Size 130 x 60~190 x 80mm Operation Mode Double Detection Mode Accumulation Counting Mode Ultraviolet Detection Mode (Option) Magnetic Detection Mode (Option) Length Detection Mode (Option) Width Detection Mode (Option) -
Page 5: Initial Operation Steps
INITIAL OPERATION STEPS CAUTION: Before you turn on the machine, please ensure you remove ALL Notes from the Hopper and Stacker areas. Turn ON the Power Switch on the rear of the machine. The machine will enter a 'Self-Test' mode whereby the display will show: The machine Motor systems will run for approximately 1 second and then, if correct, the Motors will stop and the display will change to show:... - Page 6 If the various function settings of the machine were pre-set by the previous operator, the machine will automatically default back to these previous selections when you turn the machine back ON. If you wish to change the default function setting, please see the section headed ‘Function Setting’ - (See Page 6).
-
Page 7: Function Setting
Function Setting 1. LENGTH DETECTION (Only available for the model with “3D”) NOTES: 1. Length Detection (LD) is an optional feature of the NC350A series currency counter. It is principally used to identify the denomination of the bank notes being counted where the particular national currency has a significant (+3 mm) difference, in length, between denominations. -
Page 8: Uv Counterfeit Detection Setting
display will show: The selectable range of the Width Detection Accuracy is 3mm, 5mm, 7mm, 9mm and off. You can select the Width Detection Accuracy simply by pressing the corresponding numeric keys. Turn off this function by pressing the key “0”. After selecting the desired level, press the START key to save the setting and exit from the setting mode. -
Page 9: Magnetic Counterfeit Detection Setting
Press the UVD keys to change the default UVD detection level setting, if required. The indicated U - - 2 will now change through U - - 3, U - - 0, U - - 1 and U - - 2, then recycle sequentially. The 0 indicates OFF, the 1 indicates a LOW detection level, the 2 indicates a STANDARD level, and the 3 indicates a HIGH detection level. -
Page 10: Speed Setting
2. Correctly setting the Thickness Control Knob will eliminate unnecessary cases of these incidents. 3. The DD system defaults to d - - 3 at switch-on. This is the standard setting recommended for use when the quality of the bank notes is consistent. Very dirty currency and/or where the bills being counted vary widely in their condition, are provided for by the following pre-set DD levels to enable the machine to run smoothly without frequent false, or ‘nuisance’... -
Page 11: Counting Mode Setting
Press the SPEED key to change the default SPEED setting, if required. There are three selectable speed: 600pcs/min(Low), 1000pcs/min(Standard) and 1500pcs/min(High). After selecting the desired speed, press the START key to save the setting and exit from the setting mode. 7. -
Page 12: Dustproof Cover Setting
If you want to clear the batch setting and switch to the Continuous Counting Mode, press the C key. If there is counting number on the counting display, the counting number will be first cleared. The machine is switched to the Continuous Counting Mode. The display will show: ACCUMULATION COUNTING MODE By pressing the ADD key, you can select the Accumulation Mode ON, or OFF. -
Page 13: Maintenance Routines
MAINTENANCE ROUTINES Please maintain the machine via this simple daily procedure: Turn the Main Power Switch OFF and disconnect the Mains Power Cord from the rear of the machine. Using the brush provided, clean the central Hopper Sensor, the two Stack Sensors, Hopper area and the Stacker area. - Page 14 Additionally, please maintain the machine using this relatively simple monthly routine: Turn the Main Power Switch OFF and disconnect the Mains Power Cord from the rear of the machine. Using a piece of clean, lint-free cloth and an approved non-toxic solvent fluid, carefully clean the surfaces of the following parts, which are identified in the two photographs below.
-
Page 15: Troubleshooting
Troubleshooting Error Code Reason Remedy Incorrect Feed Gap setting Adjust the Feed Gap for the correct setting There is a jammed note in the feed Remove the jammed note by pressing the START key passage A partial, or folded note, has been Remove the partial, or folded note, and press the START key to (HF2) detected... - Page 16 *** In the interests of our ongoing policy of continual product improvement, specifications are subject to change without prior notice. Users Guide for NC-350A Currency Counter...
