Assembly Instructions
18

Tools Required for Assembly

Minimum
28
(2) 1/2" Wrenches
39
(2) 7/16" Wrenches
Remove from Carton
Remove all parts and hardware packages from the carton.
Assembly
2
Note: Bolts on the Hitch Arm Assembly are not fully tightened to make assembly easier.
14
35
1. Remove two pre-attached 5/16" x 2" Hex Head Bolts in front holes and the two 5/16" x 3" Hex Head Bolts
in rear holes. Remove the 5/16" Nylock Nuts (both sides) and Cross Brace. It is not necessary to remove the
43 tire for this step, this is shown only for clarity. See Figure 1.
46
27
50
47
31
18
17
18
Figure 1
Cross
Brace
5/16" Nylock Nut
5/16" x 3" Hex Head
Bolt
5/16" x 2"
Hex Head
Bolt
