- Page 1 Öhlins EC Diagnostic Tool Owner’s Manual...
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS Safety Symbols General Warnings In this manual, mounting instructions and other technical Note! documents, important information concerning safety is The shock absorber/front fork/steering damper is an important distinguished by the following symbols: part of the vehicle and will affect the stability. Note! The Safety Alert Symbol means: Warning! Your safety is Read and ensure you understand the information in this manual... -
Page 3: Table Of Contents
CONTENTS In this manual Safety precautions ..............2 Contents .................3 Installing the hardware ............4 Installing the software .............5 Connecting the EC Diagnostic tool ........10 Diagnose a system ............. 12 Part list..................13... -
Page 4: Installing The Hardware
INSTALLING THE HARDWARE 1. Connect the following cables to the EC Diagnostic Tool as shown in figure 1: • Power cable • D-sub cable • Patch cable 2. Connect the CAN/USB adapter to the D-sub cable. Note! Do not connect the box to the computer before installing the software. -
Page 5: Installing The Software
INSTALLING THE SOFTWARE The software to the Öhllins EC Diagnostic Tool is to be downloaded from Öhlins World site (http://world.ohlins.com). Access to the site is restricted to authorized users only. The software bundle includes the Öhlins Diagnostic Tool Program and driver needed for the CAN / USB adapter. - Page 6 INSTALLING THE SOFTWARE Installation progress The installation can take up to a few minutes. Öhlins diagnostic tool installation completed Click “Next” to continue. CAN/USB adapter driver installation Start the CAN/USB adapter driver installation. Click “Next” to continue.
- Page 7 INSTALLING THE SOFTWARE Release notes Read the release notes and/or detailed installation instructions for the driver. Click “Next” to continue. Installation option If you want to create shortcuts in the start menu, select “Start Menu Shortcuts”. Click “Next” to continue. Location of installed files Keep the default setting (recommended).
- Page 8 INSTALLING THE SOFTWARE Installation completed Click “Close”. Restarting computer Restart the computer. Click “Restart” to restart the computer. Note! Save all work and close all other programs before you restart the computer. Connect the CAN / USB adapter to the computer´s USB port.
- Page 9 INSTALLING THE SOFTWARE Select “Install the software automatically”. Click “Next” to continue. Software installation is now complete. Press “Finish”.
-
Page 10: Connecting The Ec Diagnostic Tool
CONNECTING THE DIAGNOSTIC TOOL 3.1 Connect the diagnostic tool 1. Identify which connectors that should be used for the diagnostic test. 2. Before turning the EC Diagnostic tool on, remove the existing connection between the harness and the shock absorber/front fork/ spring preloader and connect the correct connector from the EC Diagnostic Tools harness. - Page 11 PERFORMING DIAGNOSTIC 4.1 Compability 4.3 After Diagnostics The shock absorber connections on the patch cable (RC and RR) are compatible with the stepper motors 21704-XX. Adjust the spring preload to the lowest level and connect then the motors to the vehicle´s wire harness. The fork connections on the patch cable (FC and FR) are compatible with stepper motors 21717-XX.
-
Page 12: Diagnose A System
DIAGNOSE A SYSTEM 5.1 Software Instructions Here we describe how to use the software and the capabilites of it. Start the Diagnostic tool by Start-menu -> Öhlins diagnostic tool -> Diagnostic tool. Turn on the power on the diagnose box. The program connects to the box, “ECU-running”... -
Page 13: Part List
PART LIST 6.1 Part List Article Number Article Description Unit Quantity/assembly 35001-01 Öhlins EC Diagnostic Tool 35002-01 Patch Cable 35003-01 Power Cord 2m 35003-02 D-sub cable 0.5m 35003-03 Adapter CAN/USB 35006-01 Rubber Foot 6.4/1.9 07222-01 Owners manual Öhlins EC Diagnostic Tool... - Page 14 Your Öhlins retailer: Öhlins Racing AB Box 722 Phone: +46 (0)8 590 025 00 SE-194 27, Upplands Väsby Fax: +46 (0)8 590 025 80 Sweden www.ohlins.com...
