Summary of Contents for Zeta Smart Connect Multi-loop
- Page 1 MULTI-LOOP REPEATER Installation Manual Doc: GLT-261-7-1 Doc: GLT-261-7-12 Issue: W.I.P Date: 25/08/2018 Issue: 001 Date: 08.02.2021 GLT-261-7-3...
-
Page 2: Table Of Contents
Smart Connect Multi-loop Repeater Installation Manual Contents Introduction ........................................3 About the Smart Connect Multi-loop Repeater ............................3 Overall Features ......................................3 Document Conventions ....................................3 Circuits and Zones ..................................... 3 System Components ..................................... 4 Panel Installation and Dimensions ................................5 Enclosure Dimensions .................................... -
Page 3: Introduction
Introduction About the Smart Connect Multi-loop Repeater The Zeta Smart Connect Multi-loop Repeater Panel can be used to monitor, operate and program Smart Connect Multi-loop fire alarm control panels (FACPs) from anywhere within the networked system. The Repeater features a 4.3” colour touch screen display that provides easy-to understand system messages. The Repeater is ergonomically designed with a LED, button and menu setup that perfectly replicates a Smart Connect Multi-loop Control Panel. -
Page 4: System Components
Smart Connect Multi-loop Repeater Installation Manual Typical Smart Network Fire Alarm Wiring System Components 4.3” colour touch screen display 32-bit microcontroller (MCU) Display PCB (MMP/DSP) USB connection to PC software 2 key switch inputs CPU reset button ... -
Page 5: Panel Installation And Dimensions
Smart Connect Multi-loop Repeater Installation Manual Panel Installation and Dimensions Enclosure Dimensions See table 1 for full dimensions. Table 1 Panel Side Bottom Knock Knock Knock Battery outs outs outs Size SMART/REP 230mm 340mm 307mm 96mm 70mm 200mm Panel Construction Details All components are manufactured from Zintec. -
Page 6: Mounting The Enclosure
Smart Connect Multi-loop Repeater Installation Manual The panel must be in a clean, dry position, which is not subject to excessive shock or vibration and at least 2 meters away from pager systems or any other radio transmitting equipment. The operating temperature range is -5°C (23°F) to 40°C (104°F); maximum humidity is 95%. -
Page 7: Cable Grounding
Smart Connect Multi-loop Repeater Installation Manual ATTENTION: DO NOT DRILL ANY ENTRY HOLES INTO THE DOOR SECTION OF THE ENCLOSURE. Cable Grounding The Repeater has no internal earth bars. It is recommended that network wiring is connected to ground at a Smart Connect control panel (only one side of the network wiring should be grounded). - Page 8 Smart Connect Multi-loop Repeater Installation Manual Figure 3: 28V DC wiring Figure 4: 28V DC terminal wiring ATTENTION: CHECK POLARITY IS CORRECT BEFORE TURNING THE POWER ON. www.zetaalarmsystems.com...
-
Page 9: Initial Power Up
The LCD shows the Zeta logo for a few seconds, while it checks to see what modules are fitted. (Note: the usual “System Healthy” banner is not shown during the module check.) Leave the panel soak for 100 seconds. -
Page 10: Wiring Recommendations For Network Wiring
Smart Connect Multi-loop Repeater Installation Manual Ring Topology NOTE: It is recommended to install the network in a ring topology for protection against open circuit and short circuit faults. Wiring Recommendations for Network Wiring The Smart network can support up to 64 panels. -
Page 11: Operation
Smart Connect Multi-loop Repeater Installation Manual Operation Refer to the Smart Connect Multi-loop Operation Manual (Doc: GLT-261-7-11). Fault Finding Refer to the troubleshooting section in the Smart Connect Multi-loop Operation Manual (Doc: GLT-261-7-11). Appendix A: SPECIFICATIONS Code Description Smart Connect Multi-loop Repeater...
