Summary of Contents for Hyundai Mobis ATC410AAN

  • Page 3 Quick Guide Menu > User's Manual on Web (QR Code)
  • Page 5 Warnings • Driving Ý System handling Ý • • • • • • • • • • •...
  • Page 6 Precautions System handling Ü Operation Ü • • • • •...

  • Page 8: Table Of Contents

    Contents System overview Using the split screen 1-12 Opening the split screen 1-12 Editing the split screen 1-13 Component names and functions Closing the split screen 1-13 Control panel Steering wheel remote control Useful functions Using the First Run Setup Using the touch screen “Press”...
  • Page 9 Radio Using the HD Radio Data 2-17 Checking weather information via HD Radio Data 2-19 Listening to the radio Checking weather information in Doppler Radar 2-19 Radio screen Seeing the driving information 2-20 Saving the current radio channel Editing the radio channel list Using the Hybrid menu 2-21 Hybrid screen...
  • Page 10 Navigation Phone Connecting a Bluetooth device Registering a device Disconnecting a registered device Deleting a registered device Making a call via Bluetooth Dialing from the recent call list Dialing from the favorites list Dialing from the contacts 6-10 Using the dial pad 6-13 Rejecting a call 6-16...
  • Page 11 Voice functions Using safety and security services Voice recognition Stolen Vehicle Recovery Using the voice recognition Contacting the Blue Link Center Available voice commands Using the Siri Eyes Free 7-19 Settings Voice Memo 7-20 Using the voice memos 7-20 Recording a voice memo 7-21 Head-Up Display Playing a voice memo...
  • Page 12 Bluetooth 9-17 Display 9-30 Android Auto 9-19 Guidance 9-31 Apple CarPlay 9-19 Volume Control 9-33 Reset 9-33 Return to Map: Set Time 9-20 TUNE Knob Function 9-21 Custom Button Steering Wheel MODE Button 9-22 Home Screen 9-22 Split Screen 9-23 My Data 9-23 Date/Time...
  • Page 13 Appendix Solutions 11-2 System status indicator icons 11-9 11-11 Trademarks 11-23 Driver assistance Driver Assistance 10-2...

  • Page 14: System Overview

    System overview Component names and functions Using the touch screen Using the Home screen Seeing the all menus screen Using the split screen...

  • Page 15: Control Panel

    Component names and NAV button • Moves to the navigation/route screen. • When you press and hold the button, functions the Places screen appears. > See “Searching by keyword.” The following describes the part names and controls on the RADIO button •...

  • Page 16: Steering Wheel Remote Control

    Steering wheel remote control SETUP button • Displays the Settings screen. • When you press and hold the button the SW Info/Update screen appears. > See “SW Info/Update.” Guide” that is separately provided. TUNE knob/ • Turn the knob to change the Voice Recognition •...
  • Page 17 Move lever/ • Changes the broadcast program button ( Radio/Media function. • Long push or long press to search a using the system, be sure to read the user's manual for safe and broadcast program while listening to convenient manipulation. the radio.
  • Page 18 Warning Ý • Driving while distracted can result in a loss of vehicle control that may lead to an accident, severe bodily injury, or death. The driver's primary responsibility is the safe and legal operation of the vehicle, and the use of any vehicle systems, including the touch screen and steering wheel controls, which take the driver's eyes, attention, and focus away from the safe operation of the vehicle, or which are not permissible by law,...

  • Page 19: Using The Touch Screen

    Using the touch screen Caution Ü • The system can be turned on even when the ignition switch is This system is equipped with a touch-enabled screen. You can use turning on the vehicle for a long time, it may cause battery various practices by using this feature.

  • Page 20: Press" Gesture

    “Press” gesture “Press and hold” gesture Press and hold the desired item. The corresponding function is run or the corresponding menu is It is used to fast forward or rewind during playback. selected.

  • Page 21: Slide" Gesture

    “Slide” gesture “Drag” gesture On the media playback screen, press the slide bar to Press and hold the desired item and drag it to change the playback position. another position. You can change the playback position during playback. The selected item moves to the new position.

  • Page 22: Swipe" Gesture

    “Swipe” gesture “Spread/pinch” gesture Lightly swipe the screen in the desired direction. On the map screen, press and hold the screen with It is used to move fast vertically or horizontally across the menu screen or options list. It is used to zoom in or out the map.

  • Page 23: Using The Home Screen

    Using the Home screen > See “ .” The Home screen provides various functions. The list of menu items appears. A To return to the Home screen from other screens, press • Edit Home Widgets: Used to edit the types and positions of widgets on the Home screen.

  • Page 24: Editing Widgets On The Home Screen

    Editing widgets on the Home screen Editing icons on the Home screen You can edit the types and positions of the widgets to display on You can see and rearrange the list of icons in the Home screen. the Home screen. At the upper left of the Home screen, press Menu At the upper left of the Home screen, press Menu >...

  • Page 25: Seeing The All Menus Screen

    Seeing the all menus screen Using the split screen (if equipped) You can see all menus on the Home screen. You can set to display various information such as map, Radio/ Media info, driving info, and clock on the split system screen. Press and gently swipe the Home screen to the left as shown below.

  • Page 26: Editing The Split Screen

    Editing the split screen You can change information on the split screen. Press and hold, and then drag the split screen up or down to select the desired information item. Closing the split screen Press the split screen button when the split screen is open.

  • Page 28: Useful Functions

    Useful functions Using the First Run Setup Using the phone projection function Using the driving assist display Using the climate control system Using the rear-seat climate control system Using the Driver Talk mode in the rear seat Using the Quiet mode in the rear seat Playing Sounds of Nature Using the HD Radio Data Seeing the driving information...

  • Page 29: Using The First Run Setup

    Using the First Run Setup When the First Run Setup screen appears, press (if equipped) A To use the default settings without changing the environment, press Skip. multiple people are using the vehicle. screen such as user name, language, and map display method. When a safety warning message appears, read it, select the driver image, and then press Set the language to display on the screen and...
  • Page 30 Set the keyboard type for text entry and then Set the map display method and then press Next. press Next. • 2D Heading Up: The map is rotated depending on the driving direction. To set the driver’s name, press • top.
  • Page 31 Using the phone projection • Visit the Android Auto website at https://www.android. function com/auto to check the list of countries, device types, and models that support Android Auto. When you connect an Android smartphone or iPhone to the • Download and install the Android Auto application from Google Play Store.
  • Page 32 Connect a smartphone to the USB port on the vehicle by using the provided USB cable. On the All Menus screen, press Perform the desired function. and then press OK. • To run the functions for phone, music, or navigation on A To end the Android Auto and disconnect from the the smartphone, press the corresponding app icon.
  • Page 33 A To use the functions on your smartphone with the minimized system settings, update the smartphone OS to the latest version. After you connect an iPhone to the vehicle with Apple CarPlay, you can run and control applications on the phone through the system screen.
  • Page 34 Connect an iPhone to the USB port on the vehicle by using the provided USB cable. On the All Menus screen, press Perform the desired function. and then press OK. • To run any of functions (phone, messaging, navigation, A To end the Apple CarPlay and disconnect from the iPhone, etc.) on your iPhone, press the corresponding function remove the USB cable from the system.

  • Page 35: Using The Driving Assist Display

    Using the driving assist display A To use the functions on your smartphone with the minimized system settings, update the smartphone OS to the latest version. You can see the view around the vehicle through the system screen. A Charges may apply for any mobile data used while Apple model.
  • Page 36 Displays the vehicle’s moving direction based on the steering angle. Press the “R” (Reverse) button shifter (or move the shift lever to “R” in a previous vehicle model) with the vehicle turned on. Displays the moving direction if you reverse the vehicle in neutral.
  • Page 37 (if equipped) You can look down the rear view from the top through the rear- A You can change the motion settings of the rear camera. On view display. the All Menus screen, press Setup > Advanced > Extend and then check On the rear-view screen, press .
  • Page 38 Press the icon to get a view in the desired (if equipped) direction. You can check the surroundings by using multiple cameras on the vehicle. Icon A Use the +/- button on the right of the screen to zoom in or out.
  • Page 39 Press the “R” (Reverse) button shifter (or move the On the surround view screen, press shift lever to “R” in a previous vehicle model) with the vehicle turned on. Select and then change the settings. The system displays the rear view of the vehicle. •...

  • Page 40: Using The Climate Control System

    Using the climate control function. system (if equipped) Can activate Climate mode for the driver’s seat only. You can check and adjust the climate system settings on the screen. The list of menu items appears. Press the [CLIMATE] button on the climate control •...
  • Page 41 Using the rear-seat climate control system (if equipped) You can check or set the rear-seat climate status on the system screen. Perform any of the following methods: • Press the [REAR] button on the climate control system. For manual temperature control •...
  • Page 42 Using the Driver Talk mode in Make conversation through the microphone of the driver’s seat. the rear seat (if equipped) A To end the Driver Talk mode, press End. A When you move to another screen without pressing End, When the driver’s voice cannot be delivered well to the rear seat, shortly press the End Call button on the steering wheel to you can use the microphone of the driver’s seat for smooth end the driver talk function.

  • Page 43: Using The Quiet Mode In The Rear Seat

    Using the Quiet mode in the Playing Sounds of Nature rear seat (if equipped) (if equipped) To allow occupants in the rear seat to have rest and sleep, you Listen to the calming sound of rain, waves, and more to relax can set to adjust the system volume.

  • Page 44: Using The Hd Radio Data

    Using the HD Radio Data The list of menu items appears. : Displays the QR • code that provides access to the online user manual You can access an array of information with HD radio data such for the system. as HD Radio™.
  • Page 45 On the All Menus screen, press HD Radio Data. Press see the details. On Route. in local roads may not be accurate. Use the information at your discretion. 2-18...
  • Page 46 Radio Data On the All Menus screen, press HD Radio Data. On the All Menus screen, press HD Radio Data. Press Press Check today's weather information of your See the weather condition details in the HD Radio position (for city). coverage area.

  • Page 47: Seeing The Driving Information

    Seeing the driving information (if equipped) You can analyze the driving patterns by checking the driving information such as driving time, distance, idle time, and vehicle update information. speed distribution. Use this information to ensure safe and A Subscribe to Blue Link to check the function. >...

  • Page 48: Using The Hybrid Menu

    Using the Hybrid menu The list of menu items appears. • receipt in a pop-up. : Displays the QR • code that provides access to the online user manual On the All Menus screen, press for the system. • The Hybrid screen provides the following features and information: 2-21...
  • Page 49 Returns to the previous step. Can see the average fuel economy and electric motor usage of the vehicle. > See “ .” You can see the fuel economy of the vehicle. On the screen, press > See “ .” The list of menu items appears. : Displays the QR code •...
  • Page 50 On the screen, press Returns to the previous step. Can see the graphs for hybrid fuel economy and electric motor usage. Can see the average fuel economy of the vehicle. Can initialize all fuel economy graphs. The list of menu items appears. : Displays the QR code •...
  • Page 51 Starting with the motor power Returns to the previous step. Can see the driving status of the vehicle. Driving with the engine and motor battery. The list of menu items appears. : Displays the QR code Driving with the engine •...
  • Page 52 Driving and charging with Braking the vehicle by the engine power decreasing the power of engine and charging with its deceleration energy Driving with the motor Braking the vehicle by power and charging with decreasing the power of the engine power engine No power transfer in Charging with both the...

  • Page 53: Using The Plug-In Hybrid Menu

    Using the Plug-in Hybrid menu Returns to the previous step. Can see the drivable range under the remaining battery amount and search for nearby charging stations. > See “ .” You can see the driving and energy information, schedule charging, or search for charging stations. Can check information such as drivable distance and battery status.
  • Page 54 Returns to the previous step. Can see the list of nearby charging stations. Used to change the map display mode. You can check the drivable range under the remaining battery ): Displays the map with the north • if necessary. (2D Heading Up): Rotates the map depending on •...
  • Page 55 Select the region to search on the left of the screen and then select the desired charging station on the right. When you want to drive beyond the drivable range, you can A To set a charging stations as a favorite, press to the search for charging stations within the range and start route right of its name.
  • Page 56 You can see the drivable distance and the estimated charging time. On the screen, press Returns to the previous step. Can see the total range & battery status and drivable distances for each fuel type (electricity, gasoline). Can see the full charging time for AC charging. The list of menu items appears.
  • Page 57 You can schedule the charging based on the departure time. A For more information about the departure time setting: You can set to automatically charge the battery according to the “ .” preset departure time. In addition, you can set to automatically >...
  • Page 58 Select the departure time and then press the item. On the screen, press A To access the online user’s manual on the Next Departure Time Settings screen, press Menu > and then scan the displayed QR code. Set the time and day and then press OK. Press on the right of On the Charge Management screen, you can see the set...
  • Page 59 Select and then change the settings. On the screen, press Check and then press You can charge the battery for the Next Departure, time. Press OK. A Scheduled charging is performed only when the charging connector is connected to the vehicle. A Scheduled charging is synchronized with the preset departure environment.
  • Page 60 You can check the fuel economy for driving. On the screen, press You can see the eco-driving information and driving records. On the screen, press Returns to the previous step. Can see the graphs for hybrid fuel economy and electric motor usage.
  • Page 61 You can check the driving dates, distances, and average fuel economy for previous driving records. On the screen, press On the screen, press A When there is the best fuel economy, appears before the record. A To delete a record, press Menu > 2-34...
  • Page 62 Starting with the motor power Returns to the previous step. Can see the driving status of the vehicle. Driving with the engine and motor battery. The list of menu items appears. : Displays the QR code Driving with the engine •...
  • Page 63 Driving and charging with Braking the vehicle by the engine power decreasing the power of engine and charging with its deceleration energy Driving with the motor Braking the vehicle by power and charging with decreasing the power of the engine power engine Charging with both the No power transfer in...

  • Page 64: Using The Electric Vehicle Menu

    Using the Electric Vehicle Returns to the previous step. Can check the drivable range under the remaining menu battery amount and search for nearby charging stations. > See “ .” You can use various features for electric vehicles, such as seeing Can check information such as drivable distance and battery the driving or energy information, scheduling a charging, or status.
  • Page 65 On the Range screen, check the drivable distance and nearby charging stations. You can check the drivable range under the remaining battery The drivable range is distinguished by a blue circle. Using the icons within the drivable range, you can check the locations if necessary.
  • Page 66 Returns to the previous step. Used to change the map display mode. When you want to drive beyond the drivable range, you can (2D Heading Up): Rotates the map depending on • search for charging stations within the range and start route the travel direction.
  • Page 67 Check the location of the destination and then press A When there are previous destinations, press > A Depending on the third-party service provider, information You can see the drivable distance and the estimated charging Returns to the previous step. time.
  • Page 68 The list of menu items appears. : Can see energy consumptions for each • component after you started the vehicle. : Can set the target • battery level for DC charging. > See “ charge and climate controls according to the preset departure .”...
  • Page 69 Select the departure time and then press the item. You can schedule the charging and climate controls based on the departure time. On the screen, press Press on the right of Set the time and day and then press OK. On the screen, press Check...
  • Page 70 Select and then change the settings. On the screen, press Check and then press You can charge the battery for the Next Departure, time. Set the desired temperature and auto defogging Press OK. and then press OK. A Scheduled charging is performed only when the charging connector is connected to the vehicle.
  • Page 71 You can set to use the scheduled charging and climate controls You can set the battery amount to charge. On the screen, press Max. charging. On the screen, press Check and then set the following details: Select a charging type to set the target battery level.
  • Page 72 Select the charging current to be used for AC Charging. You can see the eco-driving information of the vehicle. On the screen, press On the screen, press ECO Select a charging type to set the charging current. Select the desired item to see its information. Set the charging current and then press OK.
  • Page 73 You can check the driving dates, distances, and average EV economy for previous driving records. You can check the amount of carbon dioxide reduction compared to driving with gasoline. On the screen, press On the screen, press A When there is the best fuel economy, appears before the record.
  • Page 74 : Can increase the battery temperature in • You can set to display the warning message when the remaining advance to enhance the charging and driving performance battery amount is low for the destination and you can also see when scheduling charge or climate controls in winter. This the drivable distance.

  • Page 76: Radio

    Radio Listening to the radio Listening to HD Radio™ Listening to SiriusXM™ radio...

  • Page 77: Listening To The Radio

    Listening to the radio You can scan radio channels by using various options. Save your favorite channels to the presets list. Perform any of the following methods: • On the All Menus screen, press Radio. • On the control panel, press the [RADIO] button. Type B Radio screen Returns to the previous step.
  • Page 78 Warning The list of menu items appears. Ý • Enter Station: Can select or directly enter the desired Driving while distracted can result in a loss of vehicle control radio frequency. that may lead to an accident, severe bodily injury, or death. The •...
  • Page 79 Changing the radio mode Changing the radio channel Perform any of the following methods: Perform any of the following methods: • On the Radio screen, press Band repeatedly. • On the Radio screen, press the desired channel from the presets list. •...
  • Page 80 Using the scan function On the Radio screen, press Only the channels with good reception can be listened for 5 seconds in turn. Type B You can continue listening to the scanned channel. Type A...

  • Page 81: Saving The Current Radio Channel

    Saving the current radio channel When you save the current playing channel in the preset list, you can easily select it later. Perform any of the following methods: • While listening to a broadcast, press and hold an empty preset number with no channel on the radio screen. •...

  • Page 82: Editing The Radio Channel List

    Editing the radio channel list Changing the number of channels to display on the preset list Changing the order of registered channels At the upper left of the Radio screen, press Menu > Set Number of Presets. At the upper left of the Radio screen, press Menu >...

  • Page 83: Listening To Hd Radio

    Listening to HD Radio™ You can listen to radio from HD radio stations when they are available. On the Radio screen, press When HD Radio signals are received, the radio switches from the analog mode to the HD mode. Type B A In HD mode, the buttons for HD Radio stations appear at the top of the radio screen.

  • Page 84: Hd Radio™ Technology

    HD Radio™ Technology Program Info: Presents song name, artist, station IDs, and other relevant data streams. Digital, CD-quality sound. HD Radio™ Technology enables local radio stations to broadcast a clean digital signal. AM sounds like today's FM and FM sounds like a CD. FM stations can provide additional digital-only audio programming on HD2/HD3...

  • Page 85: Listening To Siriusxm™ Radio

    Listening to SiriusXM™ radio SiriusXM mode screen You can listen to radio channels provided by SiriusXM, a satellite radio service. Changing to SiriusXM mode On the Radio screen, press Band > SiriusXM. Returns to the previous step. Can change the radio mode. Can access the list of available SiriusXM radio channels.

  • Page 86: Searching For Siriusxm Radio Channels

    Searching for SiriusXM radio channels Displays the options list. You can select a channel from available SiriusXM channels. • Channel List: Can see the list of available SiriusXM channels. On the Radio screen, press Band > SiriusXM. • What is on My Presets?: Displays the broadcast schedule. •...

  • Page 87: Selecting Channels By Using Channel Numbers

    Selecting channels by using channel Seeing the program schedule numbers You can see the program schedule and information for the channels saved in your preset list. When you know the exact channel number, you can enter it to select the channel directly. On the Radio screen, press Band >...

  • Page 88: Listening To Featured Favorites Channels

    Listening to Featured Favorites channels You can listen to Featured Favorites channels on the SiriusXM radio. Multiple sets of channels can be broadcast and can be changed by SiriusXM. On the Radio screen, press Band > SiriusXM. On the SiriusXM radio screen, press Menu > Featured Favorites.

  • Page 90: Media

    Media Using media...
  • Page 91 Using media Perform any of the following methods: • On the Home screen, press the Radio/Media info widget. • On the control panel, press the [MEDIA] button. mobile device, such as USB device and MP3 player. You can also A When multiple media are connected, press the [MEDIA] play Bluetooth music by connecting a Bluetooth device, which button once more and then press the desired media supports a Bluetooth function.
  • Page 92 Warning Ý Can pause or resume playback. Driving while distracted can result in a loss of vehicle control that may lead to an accident, severe bodily injury, or death. The driver's primary responsibility is the safe and legal operation of the Can see the duration of the playing song and the current vehicle, and the use of any vehicle systems, including the touch playback position.
  • Page 93 Fast forward By using the fast forward function, you can listen to music in the USB device from the desired point during playback. Perform any of the following methods: Perform any of the following methods: • On the USB music playback screen, press within 3 seconds during playback.
  • Page 94 Perform any of the following methods: On the USB music playback screen, press repeatedly. • On the USB music playback screen, press • On the control panel, press the [TRACK ] button. Each time the icon is pressed, the random playback mode is A You can also run the function by using the Move lever/button are played randomly with no sequence.
  • Page 95 USB music list screen Caution Ü • Be sure to start the vehicle before connecting a USB device. You can search and play the desired music from the list by When you start the vehicle after connecting a USB device, the pressing List on the USB music playback screen.
  • Page 96 Listening to music via Bluetooth A When connecting a USB storage, do not use a separate extension cable and directly connect to the USB port. When you connect a USB storage via a USB hub or extension cable, To use a Bluetooth device for audio playback, connect a device the device may not be recognized.
  • Page 97 Bluetooth audio playback screen When two Bluetooth audio devices are connected to the system, select a device to play music. The list of menu items appears. connected audio device via Bluetooth. • Media Sources: Opens the media selection window. • Sound Settings >...
  • Page 98 Resuming playback of the current Bluetooth Resuming playback of the previous Bluetooth Perform any of the following methods: Perform any of the following methods: • On the Bluetooth audio playback screen, press • On the Bluetooth audio playback screen, press twice.
  • Page 99 Resuming playback of the next Bluetooth audio Perform any of the following methods: • On the Bluetooth audio playback screen, press • On the control panel, press the [TRACK ] button. A You can also run the function by using the Move lever/button on the steering wheel.
  • Page 100 Navigation Navigation functions...
  • Page 101 Navigation functions > See “Searching by keyword.” Navigation Menu overview > See “Searching by previous destinations.” > See “Registering a searched place as a favorite place.” > See “Searching the nearby points of interest.” > See “Stopping the route guidance.” >...
  • Page 102 Place or Address > See “ .” • Reorder Icons • User's Manual on Web (QR Code) Place or Address • Split Screen Finding a route easily Warning Ý • [MAP] • [NAV]...
  • Page 103 Filter by Category Start Guidance...
  • Page 104 Caution Ü • •...
  • Page 105 Map screen...
  • Page 106 Heading Up • • North Up • • 3D Map • Using the detailed guidance • • • > See “Stopping the route guidance.”...
  • Page 107 Adjusting the navigation volume Details Navigation Volume Priority Menu > Map Display Setup > Sound > Navigation Volume > Use Map Screen Volume Buttons or Volume Knob > See “Use Map Screen Volume Buttons or Volume Knob.” Menu > Nav Settings...
  • Page 108 Stopping the route guidance Pause Route Detour Pause Route Resume Route On Route Resume Route Category Pause Route Resume Route Navigation Menu > Cancel Route Menu >...
  • Page 109 Searching by keyword Navigation Menu Place or Address Navigation Menu • [NAV] • 5-10...
  • Page 110 Filter by Category Menu > User's Manual on Web (QR Code) Start Guidance 5-11...
  • Page 111 Searching by previous destinations Navigation Menu Previous Destinations Menu > User's Manual on Web (QR Code) Start Guidance Deleting a previous destination Delete Delete 5-12...
  • Page 112 History Navigation Menu Search Categories Menu > User's Manual on Web (QR Code) 5-13...
  • Page 113 Start Guidance Menu > Nearby POIs > Edit POI Menu > Nearby POIs > All POI Categories 5-14...
  • Page 114 Navigation Menu Menu > Nearby POIs Restaurants Menu > User's Manual on Web (QR Code) Menu > Nearby POIs Edit POI 5-15...
  • Page 115 Start Guidance Menu > User's Manual on Web (QR Code) Navigation Menu Emergency Start Guidance 5-16...
  • Page 116 Editing the route Add Waypoint Setting a waypoint Navigation Menu Done Menu > User's Manual on Web (QR Code) 5-17...
