360⁰ Regulator Maintenance Guide
Your marker comes equipped with some of the best regulators on the market. To ensure the best
consistency and the highest flow possible, it is recommended that you clean and lubricate the 360⁰
regulator approximately every 10 cases of paint.
1. Degas the marker and ensure that there are no paintballs in the
breech or barrel of the marker.
2. Remove your macroline hose from the 90˚ fitting on your regulator
3. Unscrew your regulator from the vertical adaptor, and set your
marker down.
4. Grasp the two halves of the regulator, and unscrew the regulator
base in a counter clockwise fashion.
5. Tap the regulator base on a hard, flat surface to allow the regulator
piston, spring stack, spring follower to slide out of the regulator base.
The main valve attached to the marker body does not need removed
or serviced.
6. Inspect the surface of the piston and o-rings for excessive wear or
nicks, and replace as necessary.
7. Inspect the interior walls of the regulator base—if necessary, use a
swab on the interior of the regulator base to clean debris and old
grease.
8. Regrease the piston o-ring with Dow 55, and gently replace the
piston, spring stack, retainer o-ring, and spring follower back into
the regulator base.
9. When disassembling the washer stack make sure that the top and
bottom washers curve to the outside. A close up of the spring stack
with the retaining o-ring is shown to the right. The retaining o-ring
does not require lubrication
10. If in doubt – just stack the washers like this: )()()()(
The shim stack disassembled. The retainer o-ring is
the only one in the marker that does not get lubed.
The 360 reg has the ability to rotate so that
the macro fitting is in a position that is
comfortable.
Disassemble the regulator by unscrewing the
top and bottom halves then removing the
internals. Tapping the bottom half into your
hand will help the washer stack slide out
Removing the adjustment screw from the bottom of
the regulator is optional at this point. Really. If it
makes you feel better remove it and use a cotton
swab to wipe out the inside.
Advertisement
Summary of Contents for Bob Long Technologies 360 Regulator
- Page 1 360⁰ Regulator Maintenance Guide Your marker comes equipped with some of the best regulators on the market. To ensure the best consistency and the highest flow possible, it is recommended that you clean and lubricate the 360⁰ regulator approximately every 10 cases of paint. 1.
- Page 2 360⁰ Regulator Maintenance Guide Velocity Adjustment: The velocity of your marker is controlled through the 360 Regulator, which is adjusted with a 1\8” Allen wrench. Turning the screw clockwise (or inward) will increase your velocity; turning the screw counterclockwise will decrease your velocity. Adjusting position of the macroline adapter: Loosen the set screws at the top of your 360 Regulator and gently rotate the body until the macroline adapter is in the position you prefer.
