U-Line S-21664 User Manual

S-21664
HANDHELD METAL
DETECTOR
Internal Sensitivity
Adjustment (under grip)
3-WAY POWER SWITCH
The 3-way power switch has two on positions and a
central off position. When the power switch is pressed
forward, the metal detector will sound an audible alert
upon detection of any metal and the red light alert
will appear. When the switch is pressed backward, the
metal detector will vibrate upon detection of any metal
and no sound will be heard, even though the red light
alert will appear. Power is turned off when the switch is in
the central position.
LED LIGHT ALERTS
The rear green light illuminates whenever the detector
is on. The red light, forward-most of the three lights,
illuminates whenever metal is detected. The center
amber light illuminates when battery power becomes
low and the battery should be recharged or replaced.
PAGE 1 OF 9
1-800-295-5510
uline.com
3-Way Power Switch
(Audible-Off-Silent)
Battery Cover
Safety Sling
Interference
Elimination Button
COMPONENTS / FUNCTION
Pour le français, consulter les pages 7-9.
LED Light Alerts
Detection Coil
(Top and Bottom Surfaces)
Earphone/
Recharger Jack
AUDIO ALERT
The speaker provides a clearly audible sound whenever
metal is detected. The audio alert sounds only when the
power switch is pressed forward.
VIBRATING ALERT
The vibration mode is activated when the power switch
is pressed backward. The unit's handle will vibrate and
the red light will alert the operator whenever metal is
detected.
INTERFERENCE ELIMINATION BUTTON
The detector is factory set for a high level of sensitivity to
detect the smallest of items. This high level of sensitivity
may produce alarms when approaching a floor
containing rebar. Press and hold this button to decrease
sensitivity to a level that does not respond to the rebar.
Release button and detector returns to normal sensitivity.
Para Español, vea páginas 4-6.
0621 IS-21664
