M=BUS Uninterruptible Power Supply (UPS)
Shockproof rechargeable battery for the M=BUS
data acquisition system.
|
Battery and loop-through operation
|
Status LEDs for power level, status and
charging
|
Space saving installation of M=BUS Pro
devices on top of the UPS
|
Passive cell balancing
TECHNICAL SPECIFICATIONS
Capacity
Input voltage (battery charging without consumer)
Input voltage (loop-through mode)
Max. input power consumption (charging without
consumer)
Output voltage
Max. output power consumption (battery mode)
Max. output power consumption (loop-through mode)
Max. overvoltage protection (input / output)
Short circuit protection
Dimensions incl. base plate (L x W x H)
Weight incl. base plate
Operating temperature
Overtemperature protection (shutdown)
Automatic shutdown
Shockproof
©MESSRING GmbH
Robert-Stirling-Ring 1 I 82152 Krailling, Germany I
All rights reserved.
19.09.2018
www.messring.de
3,500 mAh, 37 VDC (Lithium-Polymer)
9...36 VDC
18...36 VDC
50 W
22 VDC
154 W
44 W
60 VDC
Yes
220 mm x 170 mm x 93 mm
2,646 g
0...35°C
60°C (internal)
After 2 min, output power consumption <140 mA
100 G
1 / 4
