Quick Start Manual
General
Switch on ventilator
Press the «ON/OFF» button on the left-hand side of your bellavista ventilator.
It takes about one minute for the device to start.
During the power-up process bellavista automatically performs some
system tests. If any irregularities should arise, bellavista generates an alarm
signal and the power-up process is discontinued.
Start screen
When you have started bellavista, the start screen appears:
1a
1b
1c
7
6
1a
Ventilation with the same settings as previously
1b
Ventilation for a new patient
1c
Predefined profile
2
Select patient type
3
Gender, height and lung condition
4
Select breathing circuit
imtmedical ag . Gewerbestrasse 8 . 9470 Buchs . Switzerland . www. vyaire.com
Start button
2
4a
4b
3
4c
4a
Invasive, non-invasive ventilation or HFOT
4b
ATC
4c
Breathing circuit
5
Ventilation adjustment parameters
6
Start ventilation
7
Main menu
5
6
the art of ventilation
Please make sure your
bellavista ventilator is plugged into a
power source before you press the
«ON/OFF» button.

Advertisement

loading
Need help?

Need help?

Do you have a question about the bellavista and is the answer not in the manual?

Questions and answers

Summary of Contents for imtmedical bellavista

  • Page 1 Switch on ventilator Please make sure your bellavista ventilator is plugged into a Press the «ON/OFF» button on the left-hand side of your bellavista ventilator. power source before you press the It takes about one minute for the device to start.
  • Page 2 On the screen you will see the side of the device with the info button being pressed. Here you will find explanations of the various connection ports. Info button imtmedical ag . Gewerbestrasse 8 . 9470 Buchs . Switzerland . www. vyaire.com...

  • Page 3: Circuit Test

    To tions on the screen. ensure that the test is performed properly it is essential that you select the breath- ing circuit used on the start screen. imtmedical ag . Gewerbestrasse 8 . 9470 Buchs . Switzerland . www. vyaire.com...
  • Page 4 Follow the instructions and turn the flow sensor around again. When the test has also been completed in that direction, you will hear a signal after approx. 90 seconds. imtmedical ag . Gewerbestrasse 8 . 9470 Buchs . Switzerland . www. vyaire.com...
  • Page 5 Adjust the values by swiping up or down. Confirm the values by pressing «Con- firm». When you have adjusted the settings accordingly to suit the patient's needs, press «Start ventilation» and bellavista starts ventilating. imtmedical ag . Gewerbestrasse 8 . 9470 Buchs . Switzerland . www. vyaire.com...
  • Page 6 Settings Page for the settings of ventilation modes and checking the timing parameters. Apnoea ventilation settings Switching backup on/off, setting apnoea time and adjusting the backup mode. imtmedical ag . Gewerbestrasse 8 . 9470 Buchs . Switzerland . www. vyaire.com...

  • Page 7: Stopping Ventilation

    If you wish to discontinue the process, press «Cancel». To switch bellavista off, briefly press (for 1 second) the «ON/OFF» button on the left-hand side of the device. Then a window appears with an arrow which you have to drag to the right. To shut down com- pletely, bellavista takes about 20 seconds.
