Summary of Contents for Tomahawk TW3H
- Page 1 TW3H Operation Manual WATER PUMP FIND THE HOW TO GUIDE ON YEAR Honda Engine...
-
Page 2: Table Of Contents
6. After Each Use 6.1 Clean Up 6.2 Stor age 7. Maintenance 8. Troubleshooting 9. Limited Warranty 10. How to Wet Screed 11. How to Screed Form to Form 12. Operating on Wet Concrete 13. Parts Manual 14. Tomahawk Catalog & Coupon... - Page 3 Register Your Equipment Thank you for purchasing TOMAHAWK equipment! Your product is covered by the TOMAHAWK Warranty policy, but in order to activate your warranty, we need you to register your product. In addition to activating your equipment warranty, product registration will grant you access to important product updates, streamlined customer service and more.
-
Page 4: Safety Information
Tomahawk Power. The information contained in this manual is based on equipment’s production at the time of publication. Tomahawk Power reserves the right to change any portion of this information without notice. -
Page 5: Laws Pertaining To Spark Arresters
1.2.2 NEVER touch the engine or muffler while the engine is on or immediately after it has been turned off. These areas get hot and may cause burns. 1.2.3 NEVER use accessories or attachments that are not recommended by Tomahawk Power. Damage to equipment and injury to the user may result. -
Page 6: Safety While Using Combustion Engines
1.2.9 ALWAYS operate machine with all safety devices and guards in place and in working order. DO NOT modify or remove safety devices. DO NOT operate machine if any safety devices or guards are missing or inoperative. 1.2.10 ALWAYS read, understand, and follow procedures in Operator's Manual before attempting to operate equipment. -
Page 7: Technical Data
1.4.6 ALWAYS replace worn or damaged components with spare parts designed and recommended by Tomahawk Power. 1.4.7 ALWAYS disconnect spark plug on machines equipped with gasoline engines, before servicing, to avoid accidental start-up. -
Page 8: Machine Data
2.2 Specifications Model TW3H Outlet Diameter 3" X 3" Max Total Head 89ft Suction Head 25ft Max Discharge 340 gal/min Engine Model GX240 Engine Brand Honda Horsepower Run Time 3.25 hrs Fuel Tank Capacity 1.5 gal Weight 93 lbs Product Warranty... -
Page 9: Assembly Guide
4. Operating Controls 4.1 Operating Controls 4.1.1 The centrifugal pump is operated using the engine operating controls. The engine controls are located at the engine end of the pump frame. 4.1.2 The controls consist of a throttle lever (for speed control), choke lever (for cold weather starting), fuel shutoff... - Page 10 4.3 Motor Oil Use Honda 4-stroke oil, or use an equivalent high detergent, premium quality motor oil certified to meet or exceed U.S. automobile manufacturer’s requirements for Service Classification SG, SF. Motor oils classified SG, SF will show this designation on the container. SAE 10W/30 is recommended for general, all-temperature use.
-
Page 11: Operation
4.5 Check Engine Fuel WARNING • MAKE SURE YOU REVIEW EACH WARNING IN ORDER TO PREVENT FIRE HAZARD. • DO NOT REFILL TANK WHILE ENGINE IS RUNNING OR HOT. • CLOSE FUEL SHUT OFF VALVE BEFORE REFUELING. • BE CAREFUL NOT TO GET DUST, DIRT, WATER OR OTHER FOREIGN OBJECTS INTO FUEL. •... -
Page 12: After Each Use
5.2 Starting and Operating the Engine 5.2.1 Refer to the Honda engine owner’s manual. 5.2.2 Put the fuel valve in the ON position. 5.2.3 Move the choke lever to the closed position. NOTE: • The choke may not be needed if the engine is warm or the air temperature is high. 5.2.4 Set the ON/OFF switch to ON (the ON/OFF switch is mounted on the recoil shroud). -
Page 13: Stor Age
6.2 Changing Engine Oil 6.2.1 An initial oil change should be performed after the first twenty- (20) hours of use. Thereafter, change oil every 200 hours or as directed on the oil packaging. 6.2.2 Before changing the oil, check for a suitable way to dispose of the used oil. Do not pour it down sewer drains, onto garden soil or into open streams. -
Page 14: Maintenance
7. Maintenance To maintain the centrifugal pump in peak operating condition, observe and implement the maintenance and adjustment schedule in the table below. Inspect and/or service the centrifugal pump at the intervals shown below. AFTER AFTER AFTER AFTER FIRST 1000 DAILY FIRST 50 FIRST 200... -
Page 15: Troubleshooting
The troubleshooting tables below can be used as a guide to isolate centrifugal pump faults. Refer to these tables when the engine fails to start after several attempts. If, after following these procedures, the pump fails to start, contact the nearest Tomahawk pump dealer. Fault... -
Page 16: Limited Warranty
9. Limited Warranty Tomahawk Power LLC. ("We'' or "Us'') warrants to the original purchaser only ("You'' or “Your”) that the Tomahawk product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of 1 year from date of ourchase. - Page 17 Assumption of Risk You acknowledge and agree that any use of the product for any purpose other than the specified use(s) stated in the product instructions is at Your own risk. Governing Law This limited warranty gives You specific legal rights, and You also may have other rights which vary from state to state.
-
Page 18: How To Wet Screed
Parallel technology capable for double the power Parallel technology capable for double the power OSHA and GFCI Compliant 2 Year Product Warranty 2 Year Product Warranty 2 Year Product Warranty HAVE QUESTIONS? Contact us. We’re here to help! Email us at sales@tomahawk-power.com... -
Page 19: How To Screed Form To Form
36” & 46” Concrete Power Trowel 3” Trash Water Pump Part#: TSCAR8H Part#: TPT36K & TPT46K Part#: TW3H 5.5 HP Honda GX160 Engine 6 HP Kohler CH260 & 14 HP Kohler CH440 Engines Moves liquids at a rate up to 290 gal/min Remove traffic lines at 800 - 1,000 linear ft/hr Adjust trowel blade pitch from 0-28°... -
Page 20: Operating On Wet Concrete
With same day shipping and faster delivery times, count on Tomahawk to keep you powered throughout the day! With long lasting parts and engines, Tomahawk equipment will be the star of your fleet for years to come. Visit www.tomahawk-power.com to get started today!
