RDS Pro Series Quick Reference Manual

"Tramline Bouts"
The Wheel Marks display
a tick when on a tramline
bout and which side is
preset Alarm threshold
active.
alarm and the Metering
The Second line shows
the current Tramline Bout.
The Third line shows the
Tramline Target.
"Forward Speed"
This displays the live
Forward Speed
Reading.
If the speed is too high
or too low then it will
alarm and show an
up/down arrow.
"Power On / Off"
Button
Turns the Artemis on
and off.
"Pre-Start"
This button starts the
metering motor running
to prime the seed pipes
prior to the drill entering
the ground or moving
forward.
ARTEMIS PSi QUICK REFERENCE GUIDE
"Fan Speed"
This is the Fan RPM
Press at any time to return from the Rate screen or any other
Speed.
If this drops below the
Press to switch between Fan 1 & Fan 2 while on the MAIN page if
then the system will
Motor will not run.
"Seed/Fert Motor On / Off" Buttons
These buttons allow the metering motors to be
independently switched on or off.
These buttons will override the cut out status on the
drill.
"Return to MAIN Screen"
screen, back to the 'MAIN' Artemis screen displayed here.
using twin fans.
on if the drill is lifted while
"Tramline Hold" Button
This will prevent the
tramline bout counting
working in the field.
PT NO. S/DC/500-10-731 : ISSUE 1.00 : 2/7/13 : UK731100.DOC
Numeric Keypad
Used to enter a 'Target
Rate' while on RATE
page. If the Target Rate
displayed is incorrect,
just type in a new one,
finishing with the Enter
key.
Use also for keying in a
value within Setup
Menu.
"ENTER" Button
When you have typed
in a new Target Rate on
the RATE page, press
this button to enter it.
"Setup" Button
Used to enter the
Setup/Configuration
Menu
"SD/MMC Card
Reader"
"Tramline +1 Bout" Button
This button will override the
current Tramline Count and add
1 bout the current Tramline
Bout.
