Summary of Contents for Vtvision VNVR-J4-J25-J32

  • Page 1 Network Video Recorder VNVR-J4-J25-J32 User Manual v-2.0...
  • Page 2 Note: Do not place heavy objects on the device regards; Do not let any solid or liquid to penetrate inside the device; Please regularly with a brush on the circuit board, connectors, chassis fans, chassis, dust, etc., turn off the power and unplug the power supply before clean;...

  • Page 3: Table Of Contents

    Introduction.................................5 Product Brief ............................5 Main Functions.............................5 Unpacking and cable connection ........................7 Unpacking ............................7 Hard disk installation ...........................7 Shelf Installation ..........................8 Front Panel ............................8 Rear panel ............................9 Audio & Video input and output connections ..................9 Alarm input and output connections ....................10 Connect Line 485 ..........................12 REMOTE CONTROL ........................14 Chapter 3 Basic operations ..........................17...
  • Page 4 4.4.5 RS485 ............................48 4.4.6 RS232 ............................48 4.4.7 Tour..............................49 4.4.8 Channel management ......................49 4.5 Advanced..............................54 4.5.1 HDD Management........................54 4.5.2 Account ............................55 4.5.3 Online user ............................58 4.5.4 Output adjust..........................58 4.5.5 Auto Maintain ..........................58 4.5.6 Restore............................59 4.5.7 Upgrade ............................59 4.5.8 Device Info.............................60 4.5.9 Import / Export..........................60 4.6 Info................................61 4.6.1 HDD info ............................61 4.6.2 BPS..............................62...

  • Page 5: Introduction

    1. Introduction Product Brief The series NVR is designed especially for security and defense field which is an outstanding digital surveillance product. It introduces embedded LINUX operating system which is more stable. It introduces standard H.264mp video compressed format which insures the high quality image, low coding ratio and single frame playing.
  • Page 6 Alarm recording, round robin, the screen prompts, beep, mail, FTP Communication interface With RS485 interface, alarm input and PTZ control With RS232 interface, scalable keyboard connection to the master, and connected to the computer serial port for system maintenance and upgrades, and matrix control With standard Ethernet interfaces, network remote access feature Intelligent operating Mouse action function...

  • Page 7: Unpacking And Cable Connection

    2. Unpacking and cable connection Unpacking When you receive the product: First, check whether the packaging equipment has obvious damage. Selection of protective packaging materials during transport can cope with most of the unexpected hit; Then, remove the device, remove the plastic protective film NVR, check whether there is any visible damage to the outside;...

  • Page 8: Shelf Installation

    cover the machine fix the cover Shelf Installation This product chassis specification is standard 1u, so it can be installed in the standard shelf. Installation steps and attention items: Make sure the temperature in the room lower then 35℃ (95°f). Keep the equipment has 15cm (6 inches) space around in order to air's circulation.

  • Page 9: Rear Panel

    Rear panel 2.5.1 rear panel interface diagram Function Function Function AC Input USB interface RS485 interface Power stitch Alarm output Audio input VGA output Rs232 interface BNC output HDMI output Alarm input Network port Audio output Audio & Video input and output connections 2.6.1 video input NVR video input port to the BNC input signal requirements: PAL / NTSC BNC (1.0VP-P, 75 ).

  • Page 10: Alarm Input And Output Connections

    Away from strong electromagnetic interference devices. Use TV as a video output device is an unreliable alternative. It also requires minimizing the use of time and strictly controls the interference power caused by neigh boring devices. Inferior TV leakage risks may cause damage to other equipment.
  • Page 11 Poor grounding may cause the chip to burn. 2.7.5 Any type of alarm input The alarm output unit interface is a normally open type. 8 external alarm interface schematic: (1) Alarm input 1,2,3,4 (2) Ground (3) RS232 serial interface to send and receive (4) RS485 interface (5) alarm inputs 5,6,7,8 (6) Ground...

  • Page 12: Connect Line 485

    When using an external power supply required for alarm equipment and NVR common ground. 2.7.7 Alarm Output Port Description 2 channels alarm output (normally open contact), the need for external alarm device power supply; To avoid overload and damage the host, please refer to the relay relevant parameters when connecting relay relevant parameters Annex.
  • Page 13 16 external alarm 485 Schematic...

  • Page 14: Remote Control

    REMOTE CONTROL Using the Numeric Buttons Serial Name Function number Search button Video search methods Same function as Multi-window button Multi-window button in the front panel Numeric button Code input/number input/channel switch Same function as<Esc>button in the <Esc> front panel Same function as direction button in Direction button the front panel...
  • Page 15 3. When ID input is done, press the system <ID> button again to check the setting. NVR connected topology of IPC...
  • Page 16 Calculate the network bandwidth Resolution 1 tunnel 4 tunnel 9 tunnel 25 tunnel 36 tunnel tunnel 1920×1080（1080P） 4Mbps 16Mbps 36Mbps 64Mbps 100Mbps 144Mbps 1280×960（960P） 3Mbps 12Mbps 36Mbps 48Mbps 75Mbps 108Mbps 1280×720（720P） 2.5Mbps 10Mbps 23Mbps 40Mbps 63Mbps 90Mbps 704×576（D1） 1.5Mbps 6Mbps 14Mbps 25Mbps 38Mbps...

  • Page 17: Chapter 3 Basic Operations

    Chapter 3 Basic operations Note: Gray button indicates non-support. 3.1 Boot Plug the power, open the rear panel power switch, power turns on, video recorder starts. Buzzer beeps after booting .The default video output is multi-screen output mode. When start-up time is within video setting time, the system will start timer recording automatically , the corresponding channel recording indicator light turns on, system starts working.

  • Page 18: Preview

    Picture 3.1 System Login Password protection: If the password is continuous wrong three times, the alarm will start. If the password is continuous wrong five times, the account will be locked. (Through rebooting or wait half an hour, the account will be unlocked automatically). For your system security, please modify your password after first login.

  • Page 19: Desktop Shortcut Menu

    Pic 3.2 Preview interface Channel name and status display,click Screen switch “channel” to pack up Pages flip up and down under Full screen display non-16-channel mode Play ull channel video/shut down full Play/shut down full channel channel video Note:It’s main stream resolution under single window,and it’s sub-stream resolution under multi-screen.

  • Page 20: Main Menu

    Non full screen full screen Picture 3.3 Shortcut Menu Note:When under non full screen, display”full screen”, and when under full screen display”leave full screen”. 3.5.1 Main menu Main menu includes various functions of the device. Pic 3.4 Main menu 3.5.2 Playback There are two ways for you to play the video files in the HDD 1.In the desktop shortcut menu 2.Main Menu>Record>playback...
  • Page 22 Pic 3.5 Video playback Playback control Operation hint Record mode Time interval choosing Switch by File searching Channel Date choosing time,file mode choosing Storage device File information Listed files Time searching choosing 【Listed files】Display files that accord with the searching criteria. 【File information】Show file information.

  • Page 23: Record Control

    Note: Frame by frame play should be under paused status. 【Operation hint】Show key function that cursor places. Special functions： ： ： ： Local zoom:When the system is in single-window full-screen playback mode, left-click your mouse anywhere on the screen to zoom the selected area, double click to exit. Note: When current resolution of the channel is over max resolution, a Red X will show when playback the channel.

  • Page 24: Ptz Control

    corresponding channel. 【Stop】Whatever state the channel is in, select Stop button to stop output alarm signal through corresponding channel. 3.5.5 PTZ control PTZ control, the digital channel need to link PTZ, the remote device should connect with PTZ and with protocol correctly set also. Control PTZ on the connected device, you can enter the interface through desktop shortcut menu.
  • Page 25 position. Clear Preset：Input preset points, click Remove button, remove the preset. Preset point input Preset button Pic 3.9 Preset Settings 2）Preset Point Calls In Picture 3.8, click Page Switch button, enter PTZ control interface as shown in Picture 3.10. In the input blank, input the preset points, then click Preset button, PTZ turn to the corresponding preset point.
  • Page 26 Preset Points Blank Tour Button Time interval Patrol number Blank Pic 3.11 Tour setup 2）The Calls of Tour In Picture 3.8, click Page Switch button, enter PTZ control menu as shown in Picture 3.10. Please input the number of tour in the value blank, then click tour button, PTZ begins to work on the tour patrol.
  • Page 27 Step2：Please click direction arrows to adjust PTZ direction, click Setup button enter Picture3.13, then select the right boundary ,return to Picture 3.8; Step3: Setup complete, that is the position of left and right boundary Note:when the left and right scan in one horizontal, the PTZ will cycle rotate from left scan along the reverse direction to the right scan.

  • Page 28: Output Adjust

    【Aux Num open】Operate corresponding auxiliary switch according to PTZ agreement； 【Page Switch】In Picture 3.14，click Page Shift button to enter Picture 3.15 PTZ Main Menu , the menu can be control by the menu control buttons. 3.5.6 Output Adjust Adjust TV output area parameters. You can use the desktop shortcut menu or enter [Main menu]> [Advanced]>...

  • Page 29: Chapter 4 Main Menu

    Chapter 4 Main menu 4.1 Main menu guide Main menu Sub menu Function Record conf Set the recording configuration, recording type, recording time section Record Playback Set recording search, recording play, video file storage Backup Detect backup device, format device, back the selective files Set motion detect alarm channel,linkage parameters: defending time Motion section, alarm output, screen hint, recording, PTZ, tour, buzz, email and...

  • Page 30: Record

    Set appointed HDD as read/write disk, read-only disk or redundant disk, management format disk, recover and so on User Modify user, team or password. Add user or team. Delete user or team management Break the connection with the already login user. Lock the account after Online user break until booting up again.

  • Page 31: Playback

    Picture 4.1 Record Conf 【Channel】Choose the corresponding channel number. Choose the all option to set the entire channels. 【Redundancy】Choose the redundancy function to double backup the file, which means writing the video files in two HDDs. When you do the double backup, make sure that there are two HDDs installed.

  • Page 32: Backup

    4.2.3 Backup You can backup the video files to external storage through setup. Note：The accommodate storage must be installed before the file backup. If the backup is terminated, the already backup can playback individually. Picture 4.2 detect storage device 【Detect】Detect the storage connected with the NVR such as HDD or universal disk. 【Backup】Click backup button and the dialog box pops up.

  • Page 33: Alarm Function

    backup or click the pause button to stop. Note：During backup you can exit to carry out other functions. 【Burning】The file will be burned synchronously after clicking. 【Erase】Choose the file you want to delete and click erasure to delete it. 【Stop】Stop the backup. 4.3 Alarm Function Alarm functions include: motion detect, video blind, video loss, alarm input and alarm output, abnormality.
  • Page 34 Pic 4.5 set the time section 【Interval】Only one alarm signal is turned on even there are several motion detect signals in the set interval. 【Alarm output】 Start the external equipment of corresponding linkage alarm when the motion detect alarm is turned on. 【Delay】Delay a few moments and stop when the alarm state is turned off.

  • Page 35: Video Blind

    【Delay】When alarm is over, recording will last some seconds(10~300sec),then stop. 【Show message】Pop the alarm information dialog box in the local host computer screen. 【Send EMAIL】■ means sending an email to user when the alarm is turned on. Note:Set in the [NetService] to send emails. 【FTP upload】To tick it, the video &...

  • Page 36: Alarm Input

    Pic 4.8 Video loss Set method: refer to chapter 4.3.1. Motion detect 4.3.4 Alarm input When the equipment obtains the external alarm signal, the alarm function is turned on. Note: Advanced button works the same with the right of the mouse. Pic 4.9 Alarm input Set method: refer to chapter 4.3.1.

  • Page 37: Abnormal

    4.3.6 Abnormal Analysing and inspecting current software and hardware: When some abnormal events happen,the device will make a relative answer such as show message ,buzzer and so on. Pic 4.10 Abnormal handing 【Event Type】 selecting abnormity you need 【Enable】 Select it to make sure abnormal function works. 【Show message】...

  • Page 38: General

    4.4.1 General Pic 4.11 general setup 【System time】Set the system data and time. 【Date format】Choose the data format: YMD, MDY, DMY. 【Date Separator】Choose list separator of the data format. 【Time Format】Choose time format: 24-hour or 12-hour. 【Language】Support 29 language at present:S- Chinese,T-Chinese,English,Farsi,Finnish,French, Greek,Hungarian, Italian, Japanese, German, polish, Portuguese, Russian, Spanish, Thai, Turkish, Vietnamese, Romania, Brazil,Indonesia, Swedish, Arabic, Bulgarian, Czech, Hebrew, etc.

  • Page 39: Network Setup

    Pic 4.13 DST (date) 4.4.2 Network setup Pic 4.14 Network setup 【Net Card】You can choose cable network card. 【DHCP Enable】Obtain IP address automatically(not suggested) Note： ： ： ： DHCP server is pre-installed. 【IP address】Set the IP address. Default: 192.168.1.10. 【Subnet mask】Set the subnet mask code. Default: 255.255.255.0. 【Gateway】Set the default gateway.

  • Page 40: Netservice

    Otherwise image quality precedence is valid. 4.4.3 NetService Choose the network service option and click the set button to configure the advanced network functions or double click the service button to configure the parameters. Pic 4.15 Netservice 【PPPoE setup】 Pic 4.16 PPPOE Enable：Reverse■...
  • Page 41 Pic 4.17 NTP setup The NTP server must be installed in the PC. Enable：Reverse■means selected，setting is effective. Host computer IP:Input the IP address which installs NTP server. Port:Default: 123. You can set the port according to NTP server. Time zone:London GMT+0 Berlin GMT +1 Cairo GMT +2 Moscow GMT +3 New Delhi GMT +5 Bangkok GMT +7 Hongkong Beijing GMT +8 Tokyo GMT +9 Sydney GMT +10 Hawaii GMT-10 Alaska GMT-9 Pacific time GMT-8 American mountain time GMT-7 American mid time...
  • Page 42 Receiver:Send the email to appointed receivers when the alarm is turned on. You can set three receivers at most. Title:You can set as you wish. 【IP Filter setup】 When choosing the white list, only the listed IP address can connect the NVR. The 64 IP addressed are supportive in the list.
  • Page 43 address column to visit. Note： ： ： ： The DNS setup must be configured correctly in the network setup. 【FTP setup】 FTP is available only when alarm happens, or alarm activates record and snapshot, it will upload corresponding record and snapshot pictures to FTP server. Pic 4.21 FTP setup 【Enable】Click Enable, then all settings will be available 【Server IP】...
  • Page 44 【Type】choose DNS 【Enable】■ means it is selected. 【Sever IP】IP address of DDNS server 【Port】: Port No. of device, corresponding DDNS server hear port. 【User name】the user name that device can log in DDNS server 【Password】the password corresponding to the user name. 【Refresh cycle】Time interval that device and DDNS stay synchronous.
  • Page 45 Pic 4.24 Wireless setup 【Enable】To tick it means enable. Settings are effective after enabling. 【Type】Dial type, default AUTO 【Wireless AP】3G access point 【Dial Number】3G Dial Number 【User Name】User name of 3G 【Password】Password of dial user 【IP Address】IP address, got from dialling. 【Mobile Monitor Setup】...
  • Page 46 【WIFI】 NVR connect to wireless router via WIFI module, then visit it through IP address, but make sure the NVR has connected with WIFI modern first. Pic 4.27 WIFI setup 【Search】 ：Click【search】to search all the available wireless device in current range. 【enable】...

  • Page 47: Gui Display

    Pic 4.29 cloud 4.4.4 GUI Display Configure the parameters of video output signal. Local preview mode include: time display, channel title, record status, alarm status, anti-jitter, transparency and resolution. Pic 4.30 GUI display 【Time Display】■ means enable .Display the system data and time in the surveillance window. 【Channel title】■...

  • Page 48: Rs485

    4.4.5 RS485 4.31 R485 【Protocol】Choose corresponding protocol for the model( for example: DaHua)； 【Address】Set corresponding address, default is 1； 【Baud rate】Choose corresponding bard rate, default is 115200； 【Data bits】Include 5-8 options，default is 8； 【Stop bits】Include 2 options, default is 1； 【Parity】Include odd check, even check, sign check, blank check.

  • Page 49: Tour

    【Baud rate】Choose the corresponding baud rate length. 【Data bits】Include 5-8 options. 【Stop bits】Include 2 options. 【Parity】Include odd check, even check, sign check, blank check. Default: void. 4.4.7 Tour Tour setup. means that the tour mode is enable. You can choose the single-view, four-view, nine-view ,sixteen -view of single mode tour or hybrid mode tour.
  • Page 50 Pic 4.34 channel management interface Digital channel: Single linkage page of digital channel...
  • Page 51 Multi-linkage page of Digital channel Pic 4.35 digital channel interface 【Channel】Select channel number. 【Enable】■ means enable, Settings are effective after enabling. 【Time Synchronization】■ means enable ,which means channel syncs with device. 【Connection Mode】Single connection and multi-connection, multi-connection can connect to several devices, device will be displayed one by one, tour interval can be set, no less than 10s;...
  • Page 52 【Port】Default is 34567 【User name】Default is admin Note: Click the search button, the following devices will be displayed, the user can select whatever device to connect based on their needs. Pic 4.37 Device list Channel Status: When the device has digital channel, all digital channel status can be displayed, including maximum resolution, current resolution, and connection status.
  • Page 53 Channel status under digital channel mode(Wrong added device information) as below: Note: when under multi-screen, sub-stream will be displayed, when under single screen, main stream will be displayed. when the current resolution is over the max resolution that the channel supports, then a red “X” will be shown on the preview image, for example: Under full digital channel mode, Max resolution of channel 3 is D1, if it was connected to a device with resolution over D1 ( such as 960H), you will see below pic:...

  • Page 54: Advanced

    Note:Different models have different channel modes, user can shift the mode freely if necessary. 4.5 Advanced Manage tools menu include: HDD Management, Account Management, Online User, Output Adjust, Auto Maintain, Restore, Upgrade, Device Info, Import/Export. 4.5.1 HDD Management Configure and manage the HDD. The menu displays current HDD information, including: HDD numbers, input port, type, status and overall capability.

  • Page 55: Account

    Pic 4.38 HDD management 4.5.2 Account Manage the user purview. Note:1. The following user and user group names, etc. The character length is 8 bytes at most. The blank ahead or behind the character string is invalid. The middle blank in the character string is valid.
  • Page 56 Pic 4.39 Account 【Modify User】Modify the existed user attribute. 【Modify Group】Modify the existed group attribute. 【Modify Password】Modify the user password. You can set 1-6 bit password. The blank ahead or behind the char string is invalid. The middle blank in the char string is valid. Note：...
  • Page 57 Pic 4.41 add user 【Add Group】 Add a user group and set the purview. There are 33 different purviews, including: shut down the equipment, real time surveillance, playback, record setting, video backup and so on. Pic 4.42 add group 【Delete User】Delete the current user. Choose the user and delete it. 【Delete Group】Delete the current group.

  • Page 58: Online User

    Pic 4.43 delete group 4.5.3 Online user To check the information of network user connected with local device, also can tick the selected user to break up connection,（click √ in the box） ，then the user will be frozen after connection stops, and will not log in until device reboots.

  • Page 59: Restore

    Pic 4.45 auto maintain 4.5.6 Restore The system restore to the default . You can restore the items according to the menu blow. Pic 4.46 restore Note: Under digital mode, no decoding setting included. 4.5.7 Upgrade Pic 4.47 upgrade...

  • Page 60: Device Info

    【Where to upgrade】 】 】 】 Choose USB interface. 【 【 【 【 Upgrade file】 】 】 】 Choose the file you want to upgrade. 4.5.8 Device Info Provide device interface info which can be set according to customers, to facilitate better understanding and use.

  • Page 61: Info

    Pic 4.49 import/export interface 4.6 Info Display the HDD information, includes HDD info, BPS, log, version info. 4.6.1 HDD info Display the HDD status, which contains: HDD type, overall capability, remaining capacity, status, recording time and so on. Pic 4.50 HDD Info Tips：○...

  • Page 62: Bps

    * behind serial number means the current working disk such as 1*. If the corresponding disk is damaged, the information will show “？”. Different models have different HDD numbers. 4.6.2 BPS Real-time display channel image stream（Kb/S）and HDD capability （MB/H）, which is shown in waveform diagram.

  • Page 63: Version

    Pic 4.52 log 4.6.4 Version Display the basic information such as hardware information, software version, issue date, serial number , NAT status and so on. Pic 4.53 version info 4.7 Shut down system Refer to chapter 3.5.8.

  • Page 64: Chapter 5 Basic Operations For Xm Cloud

    Chapter 5 Basic operations for XM cloud 5.1 Cloud technology surveillance Cloud technology, which uses the serial number to get access to the device, not only enables the device one step on net but also greatly brings convenience for customers to better monitor via wide area network.
  • Page 65 Pic 5.2 Cloud login interface Log in by user Customer logs in with their own registered user name and password, as below: Pic 5.3 cloud technology operation interface Device management: Mainly used for adding device, click add to add a serial number for the device to be monitored.
  • Page 66 Pic 5.4 device management interface Pic 5.5 add interface at device manage Note: in pic 5.5, the user name means the user name of monitored device, password means the password of corresponding user. My Device Mainly show all the added devices, click a device name which is successfully connected to the server can get access to the monitor.
  • Page 67 Pic 5.6 monitor page - log in by user Note:the icon of means offline, the device doesn’t connect to server successfully. Log in by device Pic 5.7 log in by device interface Input the serial number of device and the verify code to monitor and control the device directly.
  • Page 68 Pic: 5.8 monitor page - log in by device...

  • Page 69: Chapter 6 Faq And Maintenance

    Chapter 6 FAQ and maintenance 6.1 FAQ When the problems you come across are not listed, please contact the local service or call the HQ service. We are willing to provide professional service. 1、 、 、 、 The NVR can not boot up normally. Possible reasons are as follows: The power supply is not correct.
  • Page 70 6、 、 、 、 The local video is a mess. Possible reasons are as follows: Program data read errors, stream is small, mosaic under full screen playback mode, usually back to normal after rebooting. HDD data cable and the HDD jumper error. The HDD is damaged.
  • Page 71 The version is not exceeded dx8.1. Update the display card driver. Network connection failure. Network setting issues. Invalid password or user name. The CMS doesn’t match with the NVR program version. 13、 、 、 、 No image or mosaic under network preview screen and video file playback mode. Possible reasons are as follows: Poor network latency.

  • Page 72: Maintenance

    Possible reasons are as follows: The remote control address is not correct. The remote control distance is too far or the angle is too large. The battery is used up. The remote controller or the front panel of the recording machine is damaged. 20、...
  • Page 73 DVR or can even damage it. Therefore, to ensure the DVR work steadily in long-term, please regularly brush printed circuit boards, connectors, fans, machine box and so on. Please keep the project well grounding to prevent from video or audio signal interfered and the NVR from static or inductive electricity.
