Summary of Contents for Kencove Solar Dolly
- Page 1 Solar Dolly™ Assembly Manual...
- Page 2 Components and Hardware 1. Battery Box 2. Stabilizer Legs (R,L) 3. Uprights (R, L) 4. Adjustable Angle Brackets 5. Panel Brackets (R,L) 6. Controller Mounting Bracket 7. Energizer Mounting Brackets Tools needed for assembly: • 11 mm wrench • Large Phillips screwdriver •...
- Page 3 Assembly Instructions Step 5: Attach controller mounting bracket using the middle holes on the panel brackets. The ends should point toward front of dolly as shown below. Fig. 1 Step 1: Attach left and right stabilizer legs to battery box. Be sure to face the bolts outward as shown in Fig.
- Page 4 For more information on components and solar powered fencing, call 800-KENCOVE. The solar dolly at right is outfitted with a 30- watt panel, 3 J Stafix Dual-Purpose Energizer, 5 amp controller and a deep cycle marine battery (recommended).
- Page 5 ™ How to Outfit the Solar Dolly Panel Brackets Solar Panel Battery Box Solar Controller Controller mounting bracket 12 v Energizer Energizer Battery Cable mounting brackets Deep Cycle Marine Battery le Marine Battery Step 1: Attach the solar panel Prior to initial assembly, be sure battery is fully charged.
- Page 6 After connecting the wires, turn the energizer on to ensure correct connections. Your Solar Dolly™ electric fencing system is now ready to be connected to the fence.
