3.8 AMP CLOSE QUARTER DRILL
This product can expose you to chemicals including
LEAD/CADMIUM/DEHP, which is known to the State
of California to cause cancer and birth defects or
other reproductive harm. For more information go
to www.P65Warnings.ca.gov.
Please carefully read and save these instructions before attempting to assemble, maintain, install, or operate this product.
Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property
damage and/or personal injury. Please keep instructions for future reference.
For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping.
For Customer Service, Call 1-800-348-5004
or e-mail customerservice@focus-ontools.com
WARNING
*Actual product may vary slightly
33185
12/2017
Advertisement
Table of Contents
Summary of Contents for Steel Core 33185
- Page 1 Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property damage and/or personal injury. Please keep instructions for future reference. For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping. For Customer Service, Call 1-800-348-5004 33185 12/2017 or e-mail customerservice@focus-ontools.com...
- Page 2 SPECIFICATIONS Power 120V~60Hz, 3.8 Amp Motor No Load Speed 0 - 1,400 RPM Chuck Capacity 3/8" WORK AREA • Keep your work area clear, clean and well lit. Cluttered work surfaces and dark areas invite accidents. • Keep people not involved in the work, especially children away from the work area while operating a power tool.
- Page 3 • Make sure the power switch is in the "OFF" position before plugging it into the receptacle. This will prevent accidental starting. Carrying tools with your finger on the switch or plugging in the tools with the switch in the "ON" position invites accidents. •...
- Page 4 EXTENSION CORDS: Make sure your extension cord is not damaged. When using an extension cord, be sure to use one heavy enough to carry the current your product draws. For lengths more than100 ft, No. 10 AWG extension cords should be used. An undersized cord results in a drop in line voltage and loss of power and overheating.
- Page 5 OPERATING INSTRUCTIONS WARNING: the voltage specifications on the rating plate must correspond with the supply voltage. INSTALLING OR REMOVING A DRILL BIT CAUTION: Always be sure that the tool is switched off and unplugged before installing or removing a bit. Hold the ring and turn the sleeve counter-clockwise to open the chuck jaws.
- Page 6 PARTS LIST Item Description Item Description ST4×16 Screw Gear Nameplate Bearing 6000–2Z Right cover Drive shaft Cord sleeve Protect cover Power cord Chuck Brush box Screw M6×16 Brush stand Switch spanner Brush Switch push pole Bearing R-4 Switch press piece Rotor Axle P1.8×28 Stator...
- Page 7 ASSEMBLY DIAGRAM customerservice@focus-ontools.com 1-800-348-5004...
