Zoef Robot HARM 2.0 User Manual page 2

Table of Contents
Technical Information......................................... 2
Welcome............................................................. 2
Safety Instructions............................................. 3
Notice Signs on the Appliance............................ 4
Warranty............................................................. 4
Planning the Installation..................................... 5
Appliance Overview............................................ 6
Initial Set-Up....................................................... 8
Status Messages / Error Messages..................... 9
Automatic Start.................................................. 10
Use...................................................................... 10
Manual Start....................................................... 11
Cleaning...............................................................12
Storage................................................................ 12
Replacing the Knife.............................................13
Technical Information
Charging voltage...............................AC100 – 240 V
Frequency................................................. 50 /60 Hz
Height adjustment.................................25–65 mm
Cutting width.................................................24 cm
Weight ...................................................approx. 10 kg
Maximum area............................................1500
Battery capacity...............................3/4 Ah Li-ion
Battery voltage........................................ 28 V
Charging time.................................. approx.60 min
Operating time................................ approx. 60 min
Sound power level L .............................. 62dB(A)
WA
Uncertainty K............................................... 3 dB(A)
Sound pressure level L
...........................51 dB(A)
PA
Uncertainty K............................................... 3dB(A)
Protection class...............................................IP56
| 2 |
Welcome
You are purchasing a high-quality product,
showing that you have high expectations to it.
For effective and safe operation, read and fol-
low these instructions and the safety instruc-
tions contained therein carefully. Keep this
manual and the original packaging for future
reference and for repackaging for transfer. We
want you to choose our appliances and prod-
ucts in future as well.
This robot mower is a smart auto recharging
home appliance powered by lithium-ion ba�ery
and integrated with mul�ple sensors detec�ng
obstacles, li�ing, �l�ng angels, flipping over, rain
boundary line perimeter.
Within the boundery line perimeter laid prior on your
lawn, the robot mower is able to automa�cally
mow your lawn during programmed clock �me and
recharge itself. This great device can reduce the
amount of work and save lots of �me for lawn
maintainence. This model is suitable for lawn sizes
under 1500m2.
Optional accessories
100m
m 2
User Manual
Garage
Limiting cable
Nails
150x
Replacement
knife set
