ITEM NO.
Title
QTY.
1
Aisle Sign Base
2
Aisle Sign Top
3
#8x0.5" P PH SMS
4
Sign Mounting Hardware
3
1
Included in box
*Note not all hardware may be used during installation.
Inline Aisle Gondola Sign
1
1
1
1
L Shape
T Shape
2
Sign mounting
hardware in
polybag
assembly instructions
Assemble top to base
•
Sign can be rotated 90 degrees to base. Rotate sign
depending on where it will be placed and getting your best
viewing angle.
•
Use (1) #8 x 1/2" screw.
pg. 1 of 3
Advertisement
Table of Contents
Summary of Contents for DGS Inline
- Page 1 Inline Aisle Gondola Sign assembly instructions ITEM NO. Title QTY. Aisle Sign Base Aisle Sign Top #8x0.5" P PH SMS Sign Mounting Hardware L Shape T Shape Sign mounting hardware in polybag Assemble top to base • Sign can be rotated 90 degrees to base. Rotate sign...
- Page 2 Inline Aisle Gondola Sign assembly instructions Bend Tab 2x Retail Gondola Shelving Mount • Set assembled sign in desired location on top of gondola shelving back panel. • Attach sign to gondola shelving back panel. There are two options to screw the sign in place.
- Page 3 Inline Aisle Gondola Sign assembly instructions Bend Tab 2x Push button in, pull up on top to extend Hang Printed Signs And Adjust Viewing Wire Rack Mount • Bend bracket tab flanges upward. Height • Set sign onto wire rack or shelf.
