Summary of Contents for Sierra Wireless AirPrime XM1210

  • Page 1 AirPrime XM1210 Product Technical Specification 41112759 Rev 2.3...
  • Page 2 Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare when wireless devices such as the Sierra Wireless modem are used in a normal manner with a well-constructed network, the Sierra Wireless modem should not be used in...
  • Page 3 This product may contain technology developed by or for Sierra Wireless Inc. This ® product includes technology licensed from QUALCOMM . This product is manufactured or sold by Sierra Wireless Inc. or its affiliates under one or more patents licensed from MMP Portfolio Licensing. Copyright © 2019 Sierra Wireless. All rights reserved.
  • Page 4 Product Technical Specification Revision Release date Changes number March 11, 2019 Added GST in: Table 3-2 on page 19 • Table 3-3 on page 19 • Table 3-4 on page 20 • GST—Position Error Statistics on page 31 • Updated Figure 1-2 on page 11 March 18, 2019...
  • Page 5: Table Of Contents

    Contents Function Description ........... . . 10 Overview.
  • Page 6 Product Technical Specification Reference Design ............33 Reference Schematic Design for Using UART0 + I2C / UART0 + USB .
  • Page 7 List of Figures Figure 1-1: XM1210 ............10 Figure 1-2: System Block Diagram .
  • Page 8 List of Tables Table 2-1: Pin Assignment..........14 Table 2-2: NRESET .
  • Page 9 List of Tables Table 5-2: Beidou/GPS External Antenna........41 Table 5-3: Tri-Frequency External Antenna .
  • Page 10: Function Description

    1: Function Description Overview This document provides the necessary guidelines for a successful system design using XM1210 modules. The XM1210 is a multi-GNSS receiver that is capable of tracking GPS and Glonass systems simultaneously. The module provides an external antenna interface that supports both active and passive GNSS antennas.
  • Page 11: Product Highlights And Features

    Function Description Product Highlights and Features • 24 tracking / 48 acquisition-channel GPS and GLONASS receiver • Supports QZSS and SBAS (WAAS, EGNOS, MSAS, GAGAN) • Sensitivity: -161 dBm • Update Rate: 1 Hz (default) • High accuracy 1-PPS timing (25ns RMS) and the pulse width is 100ms •...
  • Page 12: I2C

    Product Technical Specification The I2C interface is a serial input and output port, operating as a slave device. • Slave receiving • Slave address: 0x55 • Speed grades: Standard-mode 100kbit/s, Fast-mode 400kbit/s A USB version 2.0 FS compatible interface can be used for communication as an alternative to the UART.
  • Page 13: Specifications

    2: Specifications Mechanical Dimensions Dimension: (Unit: mm, Maximum height: 2.3 mm) Figure 2-1: Mechanical Dimensions PCB Copper Pad Definition (Unit: mm, Tolerance: ±0.1mm) Figure 2-2: PCB Copper Pad Rev 2.3 Mar.19 41112759...
  • Page 14: Pin Configuration

    Product Technical Specification Pin Configuration Figure 2-3: Pin Configuration Pin Assignment Table 2-1: Pin Assignment Name Description and Note Active Reset Recommendation Low / Voltage for Unused Pad State High Domain Ground Mandatory connection RF_IN GNSS RF signal input Mandatory connection Ground Mandatory connection Ground...
  • Page 15: Description Of I/O Pins

    Specifications Table 2-1: Pin Assignment (Continued) Name Description and Note Active Reset Recommendation Low / Voltage for Unused Pad State High Domain USB_VCC USB supply voltage input 3.3V Left open Not connected Left open Serial data output for 3.3V O, PU Left open NMEA output (TTL) Serial data input for...
  • Page 16: Table 2-2: Nreset

    Product Technical Specification Pin11: I2C_SCL • · Can be used to transmit and receive clock and communicate with the host. · If not used, keep this pin floating. Pin12: USB_DN • · Dedicated Full Speed v2.0 (DN pin of the USB connector) Pin13: USB_DP •...
  • Page 17: Specifications

    Specifications Table 2-4: WAKE UP Pin Modes (Continued) Mode Function BootROM Enter BootROM mode to upgrade firmware using these steps: The WAKE UP pin must be initially connected to ground. Power up the module’s main power. The WAKE UP pin can be removed from ground. Use “SWGNSSTool”...
  • Page 18: Absolute Maximum Ranges

    Product Technical Specification Table 2-5: Specification Data (Continued) Description Current Consumption GPS and GLONASS @ 3.3V,1Hz Update Rate Acquisition: 40mA (TYP) Tracking: 35mA (TYP) Backup Power 10μA (TYP) Consumption@ 3.3V Power Saving Sleep mode: 7mA (TYP) Deep sleep mode: 300μA (TYP) Main power down mode: 15μA (TYP) NRESET Current @ 3.3V 75μA (TYP)
  • Page 19: Protocols

    3: Protocols NMEA Output Sentences Table 3-1 lists all NMEA output sentences specifically developed and defined by Allystar. Table 3-1: Position Fix Indicator Option Description Time, position and fix type data. GNSS receiver operating mode, active satellites used in the position solution and DOP values.
  • Page 20: Gga-Time, Position And Related Data Of Navigation Fix

    Product Technical Specification Table 3-4: NMEA v4.10 Output Sentence for GPS and GNSS System GPGGA GPGSA GPGSV GPRMC GPZDA GPGST GNSS GNGGA GNGSA GPGSV GNRMC GNZDA GNGST (GPS and GLONASS) GLGSV GNSS GNGGA GNGSA GPGSV GNRMC GNZDA GNGST (GPS and Beidou) BDGSV a.
  • Page 21: Gsa - Gnss Dop And Active Satellites, Including Gps (Gpgsa), Glonass (Glgsa), Beidou (Bdgas) And, Gps And Glonass Or Gps And Beidou (Gngsa)

    Protocols Table 3-5: GGA Data Format (Continued) Name Example Units Description Geoidal Separation 17.2 meters Units meters Units of geoids separation Age of Diff. Corr. second Null fields when DGPS is not used Checksum <CR> <LF> End of message termination Table 3-6: Position Fix Indicator Value Description...
  • Page 22: Table 3-7: Gsa Data Format For Nmea V3.01

    Product Technical Specification (Beidou satellite) $BDGSA,A,3,06,13,03,17,01,09,,,,,,,1.20,0.78,0.90,4*07 NMEA version 4.10 (GPS satellite) $GPGSA,A,3,193,199,15,24,194,13,05,29,195,02,,,1.89,1.06, 1.56,1*1D (GPS and GLONASS satellites) $GNGSA,A,3,193,195,17,19,199,06,128,09,28,23,05,194,1.32, 0.81,1.03,1*35 $GNGSA,A,3,01,02,24,08,13,,,,,,,,1.32,0.81,1.03,2*06 (GPS and Beidou satellites) $GNGSA,A,3,13,193,02,199,05,195,128,15,06,194,30,19,1.18, 0.76,0.90,1*3D $GNGSA,A,3,06,13,03,17,01,09,,,,,,,1.18,0.76,0.90,4*0D Table 3-7: GSA Data Format for NMEA v3.01 Name Example Units Description Message ID $GNGSA GSA protocol header Mode 1...
  • Page 23: Table 3-9: Gsa Data Format For Nmea V4.10

    Protocols Table 3-8: GSA Data Format for NMEA v4.00 (Continued) Name Example Units Description Satellite Used SV on Channel 1. See Table 3-12 Satellite Used SV on Channel 2. See Table 3-12 ..…. …..Satellite Used SV on Channel 12 PDOP 1.21 Position Dilution of Precision...
  • Page 24: Table 3-10: Mode 1

    Product Technical Specification Table 3-10: Mode 1 Value Description Manual—forced to operate in 2D or 3D mode 2D Automatic—allowing to switch to 2D/3D mode automatically Table 3-11: Mode 2 Value Description Fix not available 2D (<4 SVs used) 3D (≥4 SVs used) Table 3-12: Satellite ID Version GLONASS...
  • Page 25: Gsv- Satellites In View, Including Gps (Gpgsv), Glonass (Glgsv), Beidou (Bdgsv) And, Gps And Glonass Or Gps And Beidou (Gngsv)

    Protocols GSV— Satellites in View, Including GPS (GPGSV), GLONASS (GLGSV), Beidou (BDGSV) and, GPS and GLONASS or GPS and Beidou (GNGSV) Table 3-14 explains the NMEA (version 3.01 / 4.00 / 4.10) sentences below: NMEA version 3.01 (GPS Satellite) $GPGSV,4,1,16,193,67,34,43,199,62,163,30,15,60,339,42,24,56, 170,32*4C (GPS and GLONASS satellites) $GNGSV,6,3,24,6,48,343,32,41,40,243,36,88,37,358,42,66,36,...
  • Page 26: Table 3-14: Gngsv Data Format For Nmea V3.01

    Product Technical Specification Table 3-14: GNGSV Data Format for NMEA v3.01 Name Example Units Description Message ID $GNGSV GSV protocol header Number of Messages (Depending on the number of satellites tracked, multiple messages of GSV data may be required) Message Number Satellites in View Satellite ID Channel 1.
  • Page 27: Table 3-16: Gpgsv Data Format For Nmea V4.10

    Protocols Table 3-15: GPGSV Data Format for NMEA v4.00 (Continued) Name Example Units Description Elevation degrees Channel 4 (Maximum 90) Azimuth degrees Channel 4 (True, Range 0 to 359) SNR (C/No) dB-Hz Range 0 to 99, (null when not tracking) Checksum <CR>...
  • Page 28: Rmc-Recommended Minimum Navigation Information

    Product Technical Specification Table 3-17: Satellite ID (Continued) Version GLONASS Beidou QZSS SBAS 4.00 01-32 65-96 01-36 193-199 40-54 4.10 01-32 01-24 01-36 193-199 127-141 Table 3-18: Signal ID (for NMEA v4.10 only) System GLONASS Beidou RMC—Recommended Minimum Navigation Information Table 3-19 explains the NMEA (version 3.01 / 4.00 / 4.10) sentences below: NMEA version 3.01 / 4.00...
  • Page 29: Table 3-19: Rmc Data Format For Nmea V3.01 And V4.00

    Protocols Table 3-19: RMC Data Format for NMEA v3.01 and v4.00 Name Example Units Description Message ID $GNRMC RMC protocol header UTC Time 115332.000 hhmmss.sss Status A: data valid or V: data not valid Latitude 4006.20852 ddmm.mmmm N/S Indicator N North or S South Longitude 11628.14483 dddmm.mmmm...
  • Page 30: Zda-Time And Date

    Product Technical Specification Table 3-20: RMC Data Format for NMEA v4.10 (Continued) Name Example Units Description Magnetic Variation degrees E/W Indicator E East or W West Mode A: Autonomous mode D: Differential mode E: Estimated mode Navigation Status S: Safe C: Caution U: Unsafe V: Invalid...
  • Page 31: Gst-Position Error Statistics

    Protocols GST—Position Error Statistics Table 3-22 explains the NMEA (version 3.01 / 4.00 / 4.10) sentences below: (GPS satellite) $GPGST,054634.000,11,,,,3.5,4.6,12*4E (GPS and GLONASS satellites) $GNGST,055116.000,4.1,,,,1.9,2.3,4.4*5D (GPS and Beidou satellites) $GNGST,055116.000,4.1,,,,1.9,2.3,4.4*5D Table 3-22: GST Data Format Name Example Units Description Message ID $GNGST GST protocol header UTC Time...
  • Page 32: Nmea Command Protocols

    · 2 = Warm Start · 3 = Hot Start Table 3-23: NMEA Command Protocol Example Command Response Cold Start None $PHD,06,40,U,BB,1*3A<CR><LF> Note: Please refer to AirPrime XM1210 and XA12xx Software User Guide for more details. Rev 2.3 Mar.19 41112759...
  • Page 33: Reference Design

    4: Reference Design This section introduces the reference schematic design for best performance. Reference Schematic Design for Using UART0 + I2C / UART0 + USB The XM1210 provides several interfaces to process GNSS NMEA data (by specified firmware): 1. UART0 + I2C—both interfaces can support NMEA output. Refer to Figure 4-1.
  • Page 34: Reference Schematic Design For Using Uart0 + Usb

    Product Technical Specification Notes: 1. Ferrite bead, L1, is added for power noise reduction. Use one with an equiv- alent impedance (600Ω at 100MHz; IDC 200mA). 2. Place bypass capacitors, C1, C2 and C5, as close to the module as possible. 3.
  • Page 35: Reference Schematic Design For Using A Patch (Passive) Antenna

    3. Damping resistors, R1 and R2, can be modified based on system application for EMI. 4. Pull high resistors, R3 and R4, can be modified based on system application for I2C. 5. If you need more support and information on antenna implementation, please contact Sierra Wireless Sales. Rev 2.3 Mar.19 41112759...
  • Page 36: Reference Schematic Design For Using An Active Antenna

    Product Technical Specification Reference Schematic Design for Using an Active Antenna Please connect the external antenna to RF_IN (Pin2) Figure 4-4: Active Antenna Application Notes: 1. Ferrite bead, L1, is added for power noise reduction. Use one with an equiv- alent impedance (600Ω...
  • Page 37: General Rules For Circuit Design

    5: General Rules for Circuit Design This section provides rules to obtain the best performance when using the GNSS module. Circuit Design Power Supply A low ripple voltage and stable power supply is required for the GNSS modules to perform optimally. An unstable power source will significantly impact GNSS RF reception performance.
  • Page 38: Uart0 / I2C / Usb Serial Interface

    Product Technical Specification If the VBACKUP pin isn’t connected to any coin battery, the GNSS module will execute cold start procedure whenever the system is restarted. Figure 5-2: Rechargeable Coin Battery with VBACKUP UART0 / I2C / USB Serial Interface UART 0 (RX/TX) 1.
  • Page 39: Antenna Compliance Design

    General Rules for Circuit Design USB (DP/DN) 1. USB supports version 2.0 full speed specifications as a peripheral interface which can also be used for communications as an alternative to UART. 2. The USB_DP and USB_DM pair must be traced by 90Ω (TYP) differential impedance.
  • Page 40: Figure 5-5: Pcb Trace Design For Antenna Impedance Matching

    Product Technical Specification Designing an External Passive Patch Antenna with a GNSS Module 1. In general, a 50Ω patch antenna will work well with the GNSS module. The antenna can be connected to the Antenna IN pin with a 50Ω impedance trace.
  • Page 41: Table 5-1: Gps/Glonass External Antenna

    General Rules for Circuit Design The power supply needs to be externally provided and should be directly connected to the external antenna via a choke coil. (Reference choke coil: LQG15HS33NJ02D from Murata.) External Antenna Specification Refer to the various specifications listed in the tables below when selecting an external antenna.
  • Page 42: 1Pps

    Product Technical Specification Table 5-3: Tri-Frequency External Antenna (Continued) Characteristic Specification Center Frequency 1582±5MHz Power Supply 3.3V DC Current 10±3mA (at 3.3±0.1V) Beidou Gain (1561.098MHz) 25±3dB (at 3.3±0.1V) GPS Gain (1575.42MHz) 27±3dB (at 3.3±0.1V) GLONASS Gain (1602MHz) 27±3dB (at 3.3±0.1V) Output VSWR 2.0 (typ) Impedance...
  • Page 43: 1.8V Boost To 3.3V Application

    General Rules for Circuit Design LED Indicator for 1PPS Signal An LED indicator with a 330Ω resistor in series can be connected to indicate the 1PPS signal. Figure 5-8: 1PPS Signal Design for IO 1.8V Boost to 3.3V Application There are two considerations to use a 3.3V GNSS module in a 1.8V system: power supply translation and signal level shift.
  • Page 44: Figure 5-10: Output Voltage Vs. Output Current

    Product Technical Specification Figure 5-10: Output Voltage vs. Output Current For signal level shift, when your host system is 1.8V and the GNSS module is 3.3V, the host system can control the GNSS module by using a signal level shift circuit (refer to Figure 5-11 below).
  • Page 45: Layout Guidelines

    General Rules for Circuit Design Layout Guidelines Please follow the layout guidelines during the design process. Layout Underneath the GNSS Module In general, GNSS modules have high receiving sensitivity at around -161dBm. During hardware integration, try to avoid noise or harmonics in the following bands to prevent unnecessary reception degradation: •...
  • Page 46: Trace

    Product Technical Specification Trace 1. USB differential signals should be traced closely and be of equal length for better noise immunity and minimum radiation. 2. Apply a 50Ω RF trace impedance for correct impedance matching. 3. Any right angle turn in trace routing should be done with two 135 degree turns or an arc turn.
  • Page 47: Troubleshooting

    6: Troubleshooting How to Check the Working Status of the GNSS Module The first thing to check for is the NMEA sentence output through TX using various application tools. For example: you may use the Windows tool HyperTerminal, or you may use another GNSS application program.
  • Page 48: Co-Design Layout Guide

    7: Co-Design Layout Guide Type 1: Co-Design Between XM1110 and XM1210 The following provides the necessary guidelines to successfully design XM1210 applications which are compatible with XM1110 modules. Figure 7-1: Module Pin Configuration Note: A red asterisk (*) indicates a different pin assignment. The following table enumerates pin assignments that are different between the XM1210 and XM1110.
  • Page 49 Co-Design Layout Guide Table 7-1: Pin Assignment Differences (Continued) XM1110 (MT3333) XM1210 (HD8021) SPI serial clock Not connected SPI serial chip select WAKE UP Wake up from power saving Refer to section 3.2.2 of the AirPrime XM Series Customer Process Guidelines for PCB layout recommendations for migrating between XM1110 and XM1210.
  • Page 50: Super Capacitor Design

    8: Super Capacitor Design About Super Capacitors Super capacitors have a lifetime similar to that of aluminum electrolytic capacitors. The service life of a super capacitor is greatly dependent on the operating temperature, humidity, applied voltage, current, and backup time. Therefore, the service life is determined based on the backup time set by the customer.
  • Page 51: Antenna Matching

    9: 50Ω Antenna Matching We used the AppCAD tool to simulate 50Ω impedance for the RF PCB layout. Table 9-1: Antenna Matching RF Line Width (W) PCB FR4 Dielectric Copper Thickness Thickness Parameters per ounce 1.8mm 0.035mm Figure 9-1: Dimensions Notice: For multi-layer layouts, you can place a ground layer in the second layer to minimize the trace width in a specific PCB (such as FR4) and impedance.
  • Page 52: Uart To Rs232 Interface

    Typically, an RS232 or USB interface is required to connect the PC to the Sierra Wireless GNSS module for communication. Most Sierra Wireless modules use a set of communication ports in TTL-logic. A bridge IC may be needed for RS232 signal conversion.
  • Page 53: Uart To Usb Interface

    11: UART to USB Interface If the Sierra Wireless module you have purchased does not come with a USB interface, it is possible to connect the module to an external USB IC. To further enhance the transferring speed, use one that is capable of USB version 2.0. Once the driver for the chosen USB Bridge IC is successfully installed in Windows or another operating system, the USB Bridge IC will automatically be recognized as a COM port.
